Grindmaster AMW 67710 Manual de usuario

Item # _______________________________

Project _______________________________

Date _________________________________

Tamper Resistant Coffee Urn - Twin 10 gallon

High Capacity: Two Independent Brewing Systems

High Security: No Exposed Fasteners

Model 67710

Electric

• Will Exceed High Volume Demand Burst, Two

Independent Brewing Systems

Two independent brewing heads brew into the 10 gallon (38L) liners

simultaneously or independently. Brew heads are mounted under

hinged lockable covers.

• Innovative Indicators Eliminate Exterior Parts

Indicator lights replace gauge glasses. Water hot light replaces

thermometer. Completely internal air agitation system for each liner.

• Designed For Safety

Eliminates potential burn hazard with two layers of high density

fiberglass insulated body.

• Flanged Feet

Urn can be fastened to counter top to prevent tipping or movement

• Tamper Resistant

All adjustable controls (timer, thermostats, sprayover flow control), are

inside a lockable control box. Master on/off switch is behind a stainless

steel, lockable panel. Control switches and pilot lights are protected

behind a tamper resistant, one inch thick Lexan® cover plate.

• Longer Average Life

Internal frame is all A.I.S.I. type 304, 18-8 stainless steel.

• Saves Steps In Brewing

Two permanent stainless steel brew baskets, so filter paper is eliminated.

Features:

Coffee Urn - Tamper Resistant

High Security / High Capacity

Coffee Brewing Equipment

Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines

Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems

Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only)

P.O. Box 35020 • Louisville, KY 40232 • USA

www.grindmaster.com • email: info@grindmaster.com

PRINTED IN USA

0807 Form # AM-204-03

67710

Productivity, 50°F Inlet 40 gal. per hour

Productivity, 130°F Inlet 80 gal. per hour

Dimensions 40-1/2” W X 22” D X 34-1/4” H, (51” H With Cover Open)

Electrical Options

all models 15 KW

120/240V 1 Phase 3 Wire 63 Amps

120/208V 1 Phase 3 Wire 72 Amps

240V 3 Phase 3 Wire 36 Amps

120/208V 3 Phase 4 Wire 42 Amps

480V 3 Phase 3 Wire 18 Amps

PERMANENT BREW BASKET

(NO FILTERS REQUIRED) BREW START AND STOP BUTTONS

40 1/2”

2 3/4”

INTERNAL ELECTRONIC

LEVEL INDICATOR

SIGNALS TO

OPERATOR WHEN

THERE IS LESS THAN

ONE HALF GALLON

OF COFFEE

REMAINING IN

THE LINER

9 3/4”

34 1/4”

FLANGED FEET WITH

SCREW HOLES TO

FASTEN TO COUNTER

DRAIN

1 1/2”

HOT WATER COFFEE

COFFEE

3 1/2”

FAUCETS ARE NONREMOVABLE

WITHOUT TOOLS

22”

9 1/4”

23 5/8”

11”

4”

DRAIN

3/8” WATER INLET

ELECTRICAL

INPUT

HINGED NON-REMOVABLE

STAINLESS STEEL ENCLOSURE

INTERNALLY HOUSING (2)

SPRAY- ARMS AND BYPASS

VALVE FOR INDEPENDENT OR

SIMULTANEOUS BREWING TO

EACH LINER - MAY BE PADLOCKED

HEAVY DUTY REINFORCED

CONTROL BOX WHICH

INTERNALLY HOUSES ALL

ELECTRICAL CONTROLS -

ACCESS COVER IS

PADLOCKED

ALL TUBING AND FASTENERS

INTERNAL FOR AUTOMATIC AIR

AGITATION (SYSTEM MIXES

COFFEE TO KEEP BREW FRESH)
