Gree XK46 Manual de usuario

Owner's Manual

Original Instructions

Wired Controller XK46

To Users

Thank you for selecting Gree’s product. Please read this instruction manual

carefully before installing and using the product, so as to master and correctly use the

product. In order to guide you to correctly install and use our product and achieve

expected operating effect, we hereby instruct as below:

(1) This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsibility for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

(2) This instruction manual is a universal manual , some functions are only

applicable to particular product. All the illustrations and information in the

instruction manual are only for reference, and control interface should be

subject to actual operation.

(3) In order to make the product better, we will continuously conduct

improvement and innovation. We have the right to make necessary revision

to the product from time to time due to the reason of sales or production, and

reserve the right to revise the contents without further notice.

(4) For personal injury or property loss and damage caused by improper

operation such as improper installation and debugging, unnecessary

maintenance, violation of related national laws and rules and industrial

standard, and violation of this instruction manual, etc., we will bear no

liability.

(5) The final right to interpret for this instruction manual belongs to Gree Electric

Appliances, Inc. of Zhuhai.

This marking indicates that this product should not be disposed

with other household wastes throughout the EU. To prevent

possible harm to the environment or human health from

uncontrolled waste disposal, recycle it responsibly to promote

the sustainable reuse of material resources. To return your used

device, please use the return and collection systems or contact

the retailer where the product was purchased. They can take

this product for environmental safe recycling.

Contents

1 Safety Notices (Please be sure to abide them) .................1

2 Operation Notices................................................................2

3 Display..................................................................................3

3.1 LCD of Wired Controller............................................................4

3.2 LCD Display Instruction ............................................................4

4 Buttons .................................................................................8

4.1 Button Graphics ........................................................................8

4.2 Function Instruction of Buttons .................................................8

5 Installation and Commissioning.......................................10

5.1 Installation of Wired Controller ................................................ 11

5.2 Commissioning .......................................................................20

6 Operation Instructions ......................................................36

6.1 ON/OFF ..................................................................................36

6.2 Mode Setting...........................................................................38

6.3 Temperature Setting................................................................38

6.4 Fan Setting..............................................................................40

6.5 Timer Setting...........................................................................41

6.6 Swing Setting ..........................................................................48

6.7 Quiet Setting ...........................................................................49

6.8 Sleep Setting...........................................................................52

6.9 Air Setting* ..............................................................................52

6.10 Light On/Off Setting...............................................................55

6.11 Save Setting..........................................................................56

6.12 Filter Clean Reminder Setting...............................................59

6.13 X-FAN Setting .......................................................................64

6.14 Health Setting* ......................................................................64

6.15 Absence Setting ....................................................................65

6.16 Remote Shield Function........................................................65

6.17 Child Lock Function ..............................................................66

6.18 Gate-Control Function...........................................................66

6.19 Inquiry of Indoor Temperature with One Button ....................66

7 Error Display ......................................................................67

7.1 Table of Error Codes for Outdoor Unit.....................................68

7.2 Table of Error Codes for Indoor Unit .......................................71

7.3 Table of Debugging Codes......................................................73

7.4 Table of Status Codes .............................................................75

Wired Controller XK46

1 Safety Notices (Please be sure to abide them)

WARNING:If not abide them strictly, it may cause severe damage to the

unit or the people.

NOTE:If not abide them strictly, it may cause slight or medium damage to

the unit or the people.

This sign indicates that the items must be prohibited. Improper operation

may cause severe damage or death to people.

This sign indicates that the items must be observed. Improper operation

may cause damage to people or property.

WARNING!

This product can’t be installed at corrosive, inflammable or explosive

environment or the place with special requirements, such as kitchen.

Otherwise, it will affect the normal operation or shorten the service life of the

unit, or even cause fire hazard or serious injury. As for the above special

places, please adopt special air conditioner with anti-corrosive or

anti-explosion function.

Wired Controller XK46

2 Operation Notices

The power supply for all indoor units must be unified.

Prohibit installing the wired controller at wet or sunshine places.

Do not knock, throw or frequently disassemble the wired controller.

Do not operate the wired controller with wet hands.

When the system mode priority is the master-slave mode, in one system

network, you must set one indoor unit as the master indoor unit, Other indoor

units are slave indoor units.

When the system mode priority is the master-slave mode, the operation mode

of the system is basing on that of the master indoor unit. The master indoor

unit can be set to any mode (including auto mode), while the slave indoor unit

can’t set to the mode that conflicts with the system mode.

When the system mode priority is: Cooling mode is prioritized, heating mode

is prioritized, first-set mode is prioritized, or last-set mode is prioritized. The

indoor unit can be set to any mode (excluding auto mode). The indoor unit will

automatically switch to the system mode, when the operation mode of the

indoor unit conflicts with the system operation mode.

When the system mode priority is the voting mode (indoor unit’s capacity is

prioritized / number of indoor units is prioritized). The indoor unit can be set to

any mode (excluding the auto mode). The indoor unit will be stopped, when

the operation mode of the indoor unit conflicts with the system operation

Wired Controller XK46

mode after voting.

System mode priority defaults to master-slave mode, and only certain units

have other system mode priorities.

When two wired controllers control one (or more) indoor unit(s), the address

of wired controller should be different.

Functions with “*” are optional for indoor units. If a function is not included in

an indoor unit, wired controller can’t set the function, or setting of this function

is invalid to the indoor unit.

3 Display

Fig. 3.1 Appearance of wired controller

Wired Controller XK46

3.1 LCD of Wired Controller

Fig. 3.2 LCD graphics of wired controller

3.2 LCD Display Instruction

Table 3.1 LCD display instruction

No. Symbols Instructions

1 Up and down swing function.

Current set fan speed (including auto, low speed,

medium-low speed, medium speed, medium-high speed,

high speed and turbo seven status).

3 Sleep status.

Wired Controller XK46

No. Symbols Instructions

4 Outdoor unit operates under Save mode/upper limit of

system capacitor less 100%/remote Save status.

5 * Air status, Indoor unit optional function.

6 Remind to clean the filter.

7 Quiet status (including Quiet and Auto Quiet two status).

8 Light On/Off function.

9 X-fan function.

10 * Health function, Indoor unit optional function.

11 * Fresh air control function of AHU-KI T.

12 Absence function.

13 Outdoor unit defrosting status.

14 Gate-control function.

15 Shielding status.

16 Child Lock status.

17 One wired controller controls multiple indoor units.
