GXV3140 IP Multimedia Phone

Quick Start Guide

The GXV3140 is not pre-congured to support or

carry emergency calls to any type of hospital, law

enforcement agency, medical care unit (“Emergency

Service(s)”) or any other kind of Emergency Service.

You must make additional arrangements to access

Emerge ncy Services. It is Your responsibility to

purchase SIP-compliant Internet telephone service,

properly congure the GXV3140 to use that service,

and periodically test your conguration to conrm

that it works as You expect. If You do not do so, it is

Your responsibility to purchase traditional wireless

or landline telephone services to access Emergency

Services.

GRANDSTREAM DOES NOT PROVIDE

CONNECTIONS TO EMERGENCY SERVICES VIA

THE GXV3140. NEITHER GRANDSTREAM NOR

ITS OFFICERS, EMPLOYEES OR AFFILIATES MAY

BE HELD LIABLE FOR ANY CLAIM, DAMAGE, OR

LOSS, AND YOU HEREBY WAIVE ANY AND ALL

SUCH CLAIMS OR CAUSES OF ACTION ARISING

FROM OR RELATING TO YOUR INABILITY TO USE

THE GXV3140 TO CONTACT EMERGENCY

SERVICES, AND YOUR FAILURE TO MAKE

ADDITIONAL ARRANGEMENTS TO ACCESS

EMERGENCY SERVICES IN ACCORDANCE WITH

THE IMMEDIATELY PRECEDING PARAGRAPH.

Wall mount holes are available.

Push phone stand upwards.

PRECAUTIONS:

WARNING: Please DO NOT power cycle the GXV3140 when the LED light

is ashing during system boot up or rmware upgrade. Doing so may corrupt

rmware images and cause the unit to malfunction.

WARNING: Only use the power adapter included with the GXV3140. Using

an alternative non-qualied power adapter may damage the unit.

PHONE SETUP:

Installing the phone stand:

PACKAGE CONTENTS:

12V

GXV3140 IP Video Phone

Quick Start Guide

CONNECTING THE PHONE:

1. Connect the handset

with the phone cord

provided.

2. Connect the LAN port to a

hub / switch / router using the

Ethernet cable.

3. Connect the power adapter

to the 12V DC output jack on

the back of the phone.

The GXV3140 supports conguration-free Plug-and-Call through Grandstream’s

peer-to-peer SIP technology. After the phone obtains an IP address through

DHCP, it will attempt to register to the IPVideoTalk network.

If the registration is successful, the IPVideoTalk text on the LCD will turn green

and an assigned IPVideoTalk number specic to this phone will be displayed.

At this point, the phone is ready for making video calls over the IPVideoTalk

network.

1. Press F1 or the round OK button when the phone is idle to access the MENU.

2. Use the navigation arrow keys to navigate the menu. Press the round OK

button to conrm a menu selection.

3. The soft keys (F1-F4) can be used for various functions on the GXV3140. The

functions are displayed on the LCD screen. Press the soft key corresponding to

the text on the LCD screen for the desired function.

Tips For Using the Keypad:

Navigation Keys

Menu/OK key

Camera loopback

Transfer

Hold

Conference

Speaker

Send

Standard Keypad

Line

Message

Soft Keys

Phone Book

PHONE CONFIGURATION:

Congure the GXV3140 using a Web Browser:

1. Type the phone’s IP address (from the LCD display) in your PC web

browser. The phone and the PC must be on the same network.

2. The default administrator user name is “admin’ with password “admin”; the

default end-user name is “user” with password “123”.

Note: Please download the GXV3140 User Manual from :

www.grandstream.com/user_manuals/GXV3140_User_Manual.pdf

Congure the GXV3140 using the Keypad:

1. Press the “OK” button to access the keypad MENU to congure the phone.

2. Follow the MENU options to congure the various features of the GXV3140.
