Grandstream Networks GXV-3000 Manual de usuario

GXV-3000 IP Video Phone

Quick Installation Guide

Updated – Fall 2006

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 2 -

Download the GXV-3000 Users Manual @ www.grandstream.com

GXV-3000 IP Video Phone

Quick Installation Guide

WARNING: Please DO NOT power cycle the GXV when LED lights are

flashing during system boot up or firmware upgrade. You may corrupt firmware

images and cause the unit to malfunction.

WARNING: use only the power adapter included in the GXV package. Using

an alternative non-qualified power adapter may possibly damage the unit.

Overview

The GXV-3000 IP Video Phone is a next generation IP video phone based on

SIP standard and H.264 video codec, the codec of choice for high-quality video.

The GXV-3000 supports real-time (up to 30fps) high-quality video at very

modest bandwidth level (as low as 32kbps, up to 1Mbps). The phone allows

nearly all viewing angles via a large 5.6 inch TFTP adjustable LCD screen and

a VGA camera, creating high-quality videoconferences from your desk.

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 3 -

Download the GXV-3000 Users Manual @ www.grandstream.com

Equipment Packaging

Unpack and check all accessories.

1. One GXV-3000 Main Case

2. One Handset

3. One Phone Cord

4. One Universal Power Adaptor

5. One Ethernet Cable

6. Two Wall Mount Sustaining Brackets

7. Quick Installation Guide

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 4 -

Download the GXV-3000 Users Manual @ www.grandstream.com

Connect the GXV-3000 Video Phone

Please use the equipment included in the packaging. Using

any other power source may damage the product.

1. Connect the handset and main phone case with the phone

cord.

2. Connect the LAN port of the phone to the RJ-45 socket of a

hub/switch or a router (LAN side of the router) using the

Ethernet cable.

3. Connect the 12V DC output plug to the power jack on the

phone; plug the power adapter into an electrical outlet.

4. The LCD will display provisioning or firmware upgrade

information. Before continuing, wait for the date/time icon to

light up. (date/time display “1900-01-02, 00:00” without a

live network connection).

5. Using the phone embedded web server or keypad

configuration menu, you can further configure the phone

using either a static IP or DHCP.

LAN/WAN RJ45

10/100Mbps ports

2x USB

orts

Power

ack

Video/Audio jack

Headset jack

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 5 -

Download the GXV-3000 Users Manual @ www.grandstream.com

Configure the GXV using the Web Browser

•If DHCP is enabled in your network, the phone’s IP address

will be displayed.

•Type the IP address from the display in the URL of your

browser (PC must be on the same network). This enables

you to further configure the GXV.

Additional information needed to configure the phone via the

web browser:

1. IP address, subnet mask and gateway IP or available

DHCP

2. SIP server and/or Outbound Proxy FQDN or IP address

3. User subscriber information: User ID, Authentication ID,

Password (provided by your VoIP service provider)

4. GXV-3000 supports “Plug N Call” if your ITSP (Internet

Telephony Service Provider) provides this automatic

provisioning service. Ensure the phone has an internet

connection (either DHCP or static IP in your internet ready

network), then power up the phone.

5. Please contact your ITSP for additional settings that may

be necessary to configure the phone.

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 6 -

Download the GXV-3000 Users Manual @ www.grandstream.com

Configure the GXV using the Keypad

1. Be sure the phone is idle.

2. Press the “OK” button to enter the keypad MENU to

configure the phone.

3. Follow the flow chart to configure the basic features of the

phone – for example the IP address if using a static IP.

Using the Keypad

1. To select/confirm a selection on the LCD, press the OK

key.

2. To browse the menu on the LCD, use the UP and DOWN

arrow keys.

3. To select an input, uses the LEFT and RIGHT arrow keys

to move the cursor then select input.

4. To delete a selection, move the cursor to the appropriate

selection then use the MUTE/DEL key.

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 7 -

Download the GXV-3000 Users Manual @ www.grandstream.com

GXV-3000 Quick Provisioning Guide

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030

www.grandstream.com info@grandstream.com GXV-3000 Quick Install Guide, p. - 8 -

Download the GXV-3000 Users Manual @ www.grandstream.com

Grandstream Networks, Inc. Corporate Headquarters

www.grandstream.com

info@grandstream.com

1297 Beacon Street. 2dFloor

Brookline,MA 02446

Tel: +1 (617) 566 – 9300

Fax: +1 (617) 247 – 1987

About Grandstream Networks. Grandstream Networks, Inc. is an award-winning designer and manufacturer

of next generation IP voice & video products for broadband networks. Grandstream’s products deliver superb

sound and picture quality, rich telephony features, full compliance with industry standards, and broad

interoperability with most service providers and 3rd party SIP based VoIP products. Grandstream is

consistently recognized in the VoIP industry for their innovation, affordability and superior value in their

products. Grandstream Networks is a private company headquartered in Brookline, MA with offices in Los

Angeles, Dallasand China. For more information, please visit www.grandstream.com

VoIPon www.voipon.co.uk [email protected] Tel: +44 (0)1245 808195 Fax: +44 (0)1245 600030
