Graco 26A231 Manual de lista de piezas

3A4497A

Instructions-Parts

26A231 Air Control

Box Kit

Interfaces Air Control Management for Spray Devices used with a ProMix®PD2K Dual

Panel Electronic Proportioner. For professional use only.

26A231 - Air Control Module

100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure

Important Safety Instructions

Read all warnings and instructions in this manual

and in the PD2K Proportioner manuals, the Gun

Flush Box manual, and the Gun Air Shutoff Kit

manual. Save all instructions.

Related Manuals

23A4497A

Contents

Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Pressure Relief Procedure . . . . . . . . . . . . . . . . . 3

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Mount the Enclosure . . . . . . . . . . . . . . . . . . . . . . 3

Install the Cable . . . . . . . . . . . . . . . . . . . . . . . . . 4

Install the Pressure Switch . . . . . . . . . . . . . . . . . 6

Connect the Gun Flush Box . . . . . . . . . . . . . . . . 7

Connect Air Supply to Module . . . . . . . . . . . . . . 7

Replace the Cover . . . . . . . . . . . . . . . . . . . . . . . 7

Ground the Enclosure . . . . . . . . . . . . . . . . . . . . . 7

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 12

Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 12

Related Manuals

See the following manuals for additional information on

the ProMix PD2K Proportioner and Gun Flush Box Kits.

Overview

Air Control Module 26A231 provides electrical and air

connections to enable a ProMix PD2k Dual Panel pro-

portioner to operate two manual spray devices, as well

as, one or two gun flush boxes, or one or two air shutoff

valves. See FIG. 1 for the identification label.

Order Gun Flush Box Kit(s) 15V826 separately (see the

Gun Flush Box Kit manual). Each 15V826 Kit includes

one gun flush box and related parts. The pressure

switch included in Gun Flush Box Kit 15V826 will be

installed in this interface module.

Order Air Shutoff Kit(s) 15V823 separately (see the Gun

Air Shutoff Kit manual). Each 15V823 kit includes one

air cutoff valve and related parts.

Manual Description

3A4186 ProMix PD2K Dual Panel Proportioner

Operation Manual, Manual Systems

332457 ProMix PD2K Proportioner Installation

Manual, Manual Systems

3A2800 ProMix PD2K Proportioner Repair-Parts

Manual, Manual Systems

312784 Gun Flush Box Kit Instruction-Parts

Manual

310745 Gun Air Shutoff Kit Instruction-Parts

Manual

FIG. 1. Air Control Module Identification Label

Artwork No. 294573 Rev. B

GRACO INC.

P.O. Box 1441

Minneapolis, MN

55440 U.S.A.

.7 7

MAX AIR WPR

MPa bar PSI

ProMix®PD2K AIR CONTROL MODULE

100

PART NO. SERIES SERIAL MFG. YR.

Installation

3A4497A 3

Installation

Pressure Relief Procedure

Follow the Pressure Relief Procedure whenever

you see this symbol.

1. Relieve pressure from the air inlet supply before

connecting air to inlet (13) of the enclosure. See

Parts on page 8.

2. Follow the Pressure Relief Procedure in the applica-

ble manuals. See Related Manuals, page 2.

Location

Install the air control module enclosure (1) within 15 ft

(4.5 m) of the PD2K Dual Panel Control Enclosure, to

ensure that the cable (23) will reach between the two

enclosures.

Mount the Enclosure

1. See Dimensions, page 9.

2. Ensure that the wall and mounting hardware are

strong enough to support the weight of the equip-

ment, fluid, hoses, and stress caused during opera-

tion.

Using the equipment as a template, mark the mounting

holes on the wall at a convenient height for the operator

and so equipment is easily accessible for maintenance.

3. Drill mounting holes in the wall. Install anchors as

needed.

4. Bolt equipment securely.

The equipment mush be grounded to reduce the risk

of static sparking. Static sparking can cause fumes to

ignite or explode. Grounding provides an escape wire

for the electric current.

This equipment stays pressurized until pressure is

manually relieved. To help prevent serious injury from

pressurized fluid, such as skin injection or splashing

fluid, follow the Pressure Relief Procedure when

you stop spraying and before cleaning, checking, or

servicing the equipment. When turned off, all air

valves bleed to atmosphere.

Installation

43A4497A

Install the Cable

1. Loosen the captive screws and remove the front

cover from the enclosure.

2. The cable (23) has bare wires at both ends. Thread

the shortest end (4 in. [102 mm]) into the enclosure

through the strain relief bushing (7). See FIG. 2.

3. Connect the cable wires to the left side of the termi-

nal strip (12), as indicated by the label (37). See

FIG. 2 and Table 1.

4. Connect the other end of the cable (5 in. [127 mm])

to the appropriate terminal blocks of the EFCM in

the PD2K Dual Panel Control Enclosure. See FIG. 3

and Table 2.

FIG. 2. Connect Cable to Terminal Strip

37 12

TI14279a

Table 1: Terminal Strip Wire Connections

Pin No. Cable Wire Colors Pin No. Switch Wires

1 Black 1 Air Flow Switch 1 +

2 White 2 Air Flow Switch 1 -

3 Red 3 Air Flow Switch 2 +

4 Green 4 Air Flow Switch 2 -

5 Orange 5 Pressure Switch 1 +

6 Blue 6 Pressure Switch 1 -

7 White/Black 7 Pressure Switch 2 +

8 Red/Black 8 Pressure Switch 2 -

9 Green/Black 9 Solenoid 1, + (12V), Red

10 Orange/Black 10 Solenoid 1, - (COM), Black

11 Blue/Black 11 Solenoid 2, + (12V), Red

12 Red/White 12 Solenoid 2, - (COM), Black

Installation

3A4497A 5

FIG. 3. Enhanced Fluid Control Module

EFCM Connectors 5-7

Table 2: EFCM Terminal Connections

Pin No.

Cable Wire

Colors Pin No.

EFCM

Connector

1Black 1 6

2White 2 6

3Red 3 6

4Green 4 6

5Orange 9 7

6Blue 107

7 White/Black 11 7

8 Red/Black 12 7

9Green/Black5 5

10 Orange/Black 6 5

11 Blue/Black 7 5

12 Red/White 8 5

Installation

63A4497A

Install the Pressure Switch

NOTE: The Air Control Module Kit does not include a

pressure switch (PS). The pressure switch is supplied

with the gun flush box kit. Install the pressure switch in

the interface module as follows.

1. Each gun flush box kit includes one pressure switch

(PS). The Air Control module can accommodate 1

or 2 pressure switches. Install the switch(es) in the

left side of the enclosure. See FIG. 4.

2. Connect the wires from PS#1 to the right side of the

terminal strip (12) pins 5 (+) & 6 (-), as indicated by

the label (38). See FIG. 5 and Table 1.

3. If using a second gun flush box, connect the wires

from PS#2 to the right side of the terminal strip (12)

pins 7 (+) & 8 (-), as indicated by the label (38). See

FIG. 5 and Table 1.

FIG. 4. Install Pressure Switch (two shown)

PS#1

PS#2

TI14282a

Pressure switch is part of gun flush box kit;

not included with Air Control Module Kit.

FIG. 5. Connect Pressure Switch to Terminal Strip

3812

TI14279a

Installation

3A4497A 7

Connect the Gun Flush Box

NOTE: Use 5/32 in. (4 mm) OD tubing to connect the

gun flush box air ports to the interface module air ports,

as follows. See FIG. 7.

1. From the Pport to the air supply.

2. From the A port to the pressure switch air input.

3. From the C port to the gun flush box solenoid out-

put.

4. From the S port to the atomizing air safety shutoff

valve pilot port. See the gun flush box manual for

details on the safety shutoff valve.

5. From the AFS to the atomizing air safety shutoff

valve IN port. See the gun flush box manual for

details on the safety shutoff valve.

Connect Air Supply to Module

Connect a 1/4 in. (6 mm) OD tube between a clean, dry

air supply (filtered to 10 microns) and the module air

inlet fitting (13). See Parts on page 8.

Replace the Cover

Reinstall the cover on the enclosure and secure with the

four captive screws.

Ground the Enclosure

Connect a ground wire (Y) from the enclosure’s ground

screw (6) to a true earth ground. See FIG. 6.

FIG. 6. Ground the Enclosure

TI14277a

FIG. 7: Gun Flush Box to Air Control Module Air Connections

TI14278a

AFS

GUN FLUSH BOX

INTERFACE MODULE

AIR SAFETY

SHUTOFF VALVE

TI13110b

Parts

83A4497A

Parts

Part No./Description

5,17

37 38

TI14279a

31,34

33,34

Ref. Part Description Qty

1 15V531 ENCLOSURE 1

2 15U918 LABEL, product 1

3 118435 GROMMET 1

4 121628 SCREW, self-sealing 2

5 104644 PLUG, screw 2

6 -- SCREW, ground 1

7 -- BUSHING, strain relief 1

8 -- MANIFOLD, GFB solenoid 1

9 -- RAIL; 3 in. (76 mm) 1

10 116804 BLOCK, end, terminal 2

11 -- COVER, end, terminal 2

12 -- TERMINAL, rail mount 12

13 115671 CONNECTOR, tube; 1/4 in. OD 1

14 C06061 MUFFLER, sintered; 1/8 diam. 1

15 111328 CONNECTOR, tube; 5/32 in. OD 2

16 -- SCREW, machine, truss-hd 2

17 104640 GASKET 2

18 103832 SCREW, machine 2

19 186620 LABEL, symbol, ground 1

23 15V819 CABLE, GFB interface (not

shown)

25 598095 TUBE, nylon; 5/32 in. OD; 50 ft.

(not shown)

29 104641 BULKHEAD 2

30 111763 ELBOW, 1/4 in npt. 2

31 119159 SWITCH, air flow 2

32 113029 NIPPLE, 1/4 in. x 1/4 in. npt 2

33 121324 VALVE, solenoid; .25W 2

34 112514 FERRULE, wire; AWG-18 8

37 -- LABEL, cable wire connections 1

38 -- LABEL, switch wire connections 1

39 125946 PLUG, hole; 1/2 in. 2

Ref. Part Description Qty

Dimensions

3A4497A 9

Dimensions

TI14276a TI14278a

6.75 in.

(171.5 mm)

7.50 in.

(190.5 mm)

6.28 in.

(159.5 mm)

4.00 in.

(101.6 mm)

4.00 in.

(101.6 mm)

Mounting Holes

Dimensions

10 3A4497A

Tabla de contenidos

Otros manuales de Unidad de control de Graco

Graco

Graco PM5 238513 Manual de operación

Graco

Graco Series A Manual de usuario

Graco

Graco 24R021 Manual de lista de piezas

Graco

Graco Compact Dyna-Star 25P686 Manual de usuario

Graco

Graco E-Flo 24P821 Manual de operación

Graco

Graco Airgard 224-040 Manual de operación

Graco

Graco B52100 Manual de lista de piezas

Graco

Graco SDP8 Series Manual del propietario

Graco

Graco Cleanshot 244162 Manual de usuario

Graco

Graco 202844 Evenflo Manual de usuario

Graco

Graco Dyna-Star 77X540 Manual de usuario

Graco

Graco M5 Manual de usuario

Graco

Graco LDP5 Manual de usuario

Graco

Graco EnDure Manual de usuario

Graco

Graco Gun Flush Box 570046 Manual de operación

Graco

Graco 208390 Manual de usuario

Graco

Graco Therm-O-Flow 194485 Manual de operación

Graco

Graco 24J415 Manual de lista de piezas

Graco

Graco C Series Hoja de datos

Graco

Graco 239850 Manual de operación

Graco

Graco PD44 Guía de solución de problemas

Graco

Graco Control Architecture Module Manual del propietario

Graco

Graco Therm-O-Flow 25C994 Manual de usuario

Graco

Graco Uniblock Series Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario

Flyron

Flyron FN-BC04 Manual de usuario
