Graco Contender Slim Manual de usuario

GRACO CONTENDER SLIM

Type: Convertible

Last date made: Current

First made: 2021

Weight limits: 5 to 40 lbs. rear facing,

22 to 65 lbs. forward facing; forward facing not

recommended for children under two.

Harness: 5-point harness

P. 1 of 2

Harness: Shoulder straps are attached to a splitter plate behind seat. Pull

strap end in front of seat to tighten harness. Lift lever at lower front of seat

and pull on shoulder straps to loosen. Harness covers MUST be used for

forward-facing child weighing 25 lbs. or less.

Harness slots: There is one set of slots, which may be raised or lowered

to one of eight positions by grasping handle at top of headrest (diagram 1).

Be sure headrest is locked into place once adjusted. When head

support is in lowest position, pull flap forward (diagram 2).

Crotch strap: Adjustable. The crotch strap is sewn to a metal anchor

which must lie flat against underside of seat. To change slots, turn metal

anchor sideways, feed up through shell of restraint, and reinsert through

desired slot. Crotch strap should be close to, but not underneath child. If

lower anchor strap/safety belt is in rear-facing belt path, be sure it is in

front of buckle strap when buckle is in inner-most position and behind

when in the outer-most position (diagram 3).

Angle adjustment: Reclined position (diagram 4)

must be used for rear-facing; upright position

(diagram 5) must be used for forward-facing. Ball in

level indicator on side of restraint must be entirely in

light blue in rear-facing mode for 0-3 month old, or entirely in blue area for child over 3 months

(diagram 6). A rolled towel may be used to achieve proper recline if needed.

SEE PAGE 2

4 5 6

Important: This information sheet is not a substitute for complete manufacturer’s directions and current recall list. #450 (c)

SafetyBeltSafe U.S.A., 27943 Seco Canyon Rd., Ste 301 Santa Clarita CA 91350 (800) 745-SAFE ©SafetyBeltSafe U.S.A. 3/22

Belt path: If LATCH is not in use, secure hooks to locations provided at

sides and rear of seat (diagram 7). May be installed using Ford or

Lincoln inflatable safety belt.

Rear-facing:The vehicle belt is routed under child’s legs through

blue slots on each side of shell. Route safety belt between crotch strap

slots (diagram 3, pg. 1).

Forward-facing:The vehicle belt is routed through slots behind

seat, indicated by orange labels.

LATCH: Attach to vehicle lower anchors, using appropriate belt path.

Discontinue use of lower anchors at 45 lbs. If vehicle manufacturer states

lower weight limit for LATCH anchors, use vehicle belt. Lower anchors

may be used in center seating position when position is designated as a

LATCH location in vehicle owner's manual and when spacing between

anchors is 11 inches or greater (refer to Safe Ride News LATCH

manual). To move the LATCH strap from one belt path to another, pull

strap out of belt path such that both connectors are on the same side

(diagram 8). Unsnap seat pad at front and feed lower connector with

adjuster closest to it through appropriate belt path. Secure seat pad.

Tether: Yes, for forward-facing use only. If tether is not in use, attach hook

to location provided on either side of back of seat (diagram 9).

OTHER: Body support (diagram 10) must be used if child’s shoulders

are below lowest set of slots, and may only be used in rear-facing

mode.

When forward-facing, harness covers MUST be used for child

weighing 25 lbs. or less.

Infant head support may only be used in rear-facing mode.

Cup holder is optional and can be used on either side.

Restraint expires seven years from date of manufacture.

P. 2 of 2

Graco Contender Slim

Important: This information sheet is not a substitute for complete manufacturer’s directions and current recall list. #450 (c)

SafetyBeltSafe U.S.A., 27943 Seco Canyon Rd., Ste 301 Santa Clarita CA 91350 (800) 745-SAFE ©SafetyBeltSafe U.S.A. 3/22

www.gracobaby.com

Read This Instruction Manual

CONVERTIBLE CAR SEAT

Contender™Slim

FAILURE TO PROPERLY USE THIS

CHILD RESTRAINT INCREASES THE

RISK OF SERIOUS INJURY OR DEATH

IN A SUDDEN STOP OR CRASH.

Do not install or use this child restraint

until you read and understand the

instructions in this manual.

NWL0001276815C 8/21

2-A Car Seat Features

1 Important Pages 6-23

2 Features Pages 24-29

1-A A Quick Guide to Your Manual

1-B Welcome to the Graco Family!

1-C Right Mode of Use

1-D Before You Begin

If You Need Help

Certification

Car Seat’s Useful Life

Vehicle Seat Protection

Warm Weather Use

1-E Safety Warnings

4-A Forward-Facing Use

4-B Install Forward-Facing with LATCH

4-C Install Forward-Facing with Vehicle Seat Belt

4 Forward-Facing Pages 45-58

3-A Rear-Facing Use

3-B Install Rear-Facing with Lower Anchor Attachment

3-C Install Rear-Facing with Vehicle Seat Belt

3 Rear-Facing Pages 30-44

5-A Securing Child 5-Point Harness

5 Securing Child Pages 59-66

7-A Moving the Lower Anchor Attachment

7 Moving the Lower Anchor Attachment

Pages 69-71

6-A Accessories

6 Accessories Pages 67-68

8-A How to Uninstall Lower Anchor Connectors and Tether

8-B Choosing Vehicle Seat Location

8-C Unsafe Vehicle Seat Locations

8-D Vehicle Seat Belts

8 Vehicle Information Pages 72-82

9-A Cleaning Seat Pad

9-B Cleaning Buckle

9-C Cleaning Harness, Lower Anchor Attachment and Tether

9 Care & Cleaning Pages 83-86

1-A A Quick Guide to Your Manual

This car seat is for children: Rear-Facing: 5-40 lb (2.2-18 kg)

Forward Facing: 22-65 lb (10-30 kg)

• Children less than 22 lb (10 kg) MUST use this car seat rear-facing. Review section 1-C for more

information.

Note: Preterm or low birth weight infants may be at special risk in a vehicle or aircraft. According to the

AAP, these infants may suffer breathing issues if improperly reclined in a car seat. When rear-facing, use

the corrected age for preemies. Graco advises that you have your physician or hospital staff evaluate your

infant and recommend the proper car seat or car bed before you and your infant leave the hospital.

Get to Know Your Car Seat

What Seating Location Should I Use?

Review section 2-A to see all of the features of this infant car seat.

The best seating location for this infant car seat is one that:

• Is recommended by your vehicle owner’s manual, and

• Results in a secure installation of this car seat.

Some vehicles have specific requirements for where the car seat can be installed, so be sure to check your

vehicle owner’s manual for available seating positions, if any.

Review section 8-B, 8-C and 8-D of this manual AND your vehicle owner’s manual.

This car seat is for children: Rear-Facing: 5-40 lb (2.2-18 kg)

Forward Facing: 22-65 lb (10-30 kg)

• Children less than 22 lb (10 kg) MUST use this car seat rear-facing. Review section 1-C for more

information.

Note: Preterm or low birth weight infants may be at special risk in a vehicle or aircraft. According to the

AAP, these infants may suffer breathing issues if improperly reclined in a car seat. When rear-facing, use

the corrected age for preemies. Graco advises that you have your physician or hospital staff evaluate your

infant and recommend the proper car seat or car bed before you and your infant leave the hospital.

Which Installation Method Should I Use?

This car seat can be installed in your vehicle using either the vehicle seat belt OR the lower anchor attachment.

Both are equally safe to use. INSTALL USING ONLY ONE METHOD.

Vehicle Seat Belt: Review section 8 and your vehicle owner’s manual to learn how to install your car seat

with the vehicle seat belts.

LATCH or Lower Anchor Attachment: The LATCH system or lower anchor attachment allows you to securely

attach your safety seat in your car without using the vehicle seat belt and possibly to get a better fit. All 2003

and newer model year vehicles are required to have a LATCH system, although some manufacturers began

including LATCH earlier. Some vehicle owner manuals use the term ISOFIX to identify the LATCH system.

According to accident statistics, children are safer when properly restrained

in the rear seating positions than in the front seating positions. The center

of the back seat can be the safest during a possible side impact.

NEVER place this child restraint rear-facing in a vehicle seating location

that has an active front air bag.

In the event there is no back seat, review your vehicle owner’s manual to see how to

use your child restraint.

LATCH consists of lower anchors and a tether anchor, which are built in to your vehicle,

and a lower anchor attachment and a tether that are built into your car seat. The lower

anchor attachment is used INSTEAD of the vehicle’s seat belt to secure the child seat to the

vehicle. The tether is used IN ADDITION to the lower anchor attachment OR the vehicle’s

seat belt to secure a forward-facing car seat to the vehicle.

Review your vehicle owner’s manual for exact location and use.

What is LATCH?

Vehicle Tether

Anchor Points

Vehicle Lower

Anchor Points

Typical seat in a passenger

vehicle. Other vehicle types may

have different lower anchor and

tether anchor locations.

Vehicle Seat Bight
