GoMax Electronics CV-117 Manual de usuario

DVI Passive Extender

over Single Cat.X

User Manual

rev: 111208

Made in Taiwan

V-

-1

The CV-117 DVI Passive Extender over Single Cat.X has been tested for conformance to safety

regulations and requirements, and has been certified for international use. However, like all

electronic equipments, the CV-117 should be used with care. Please read and follow the safety

instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

●Follow all instructions and warnings marked on this unit.

●Do not attempt to service this unit yourself, except where explained in this manual.

●Provide proper ventilation and air circulation and do not use near water.

●Keep objects that might damage the device and assure that the placement of this unit is on a

stable surface.

●Use only the power adapter and power cords and connection cables designed for this unit.

●Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device

before cleaning.

TABLE OF CONTENTS

INTRODUCTION.................................................................................................................1

FEATURES.........................................................................................................................1

PACKAGE CONTENTS......................................................................................................1

SPECIFICATIONS..............................................................................................................2

HARDWARE INSTALLATION.............................................................................................3

CONNECTION DIAGRAM ..................................................................................................3

DVI OVER SINGLE CAT5 SERIES LINEUP.......................................................................4

NOTICE..............................................................................................................................5

WARRANTY .......................................................................................................................6

INTRODUCTION

The CV-117 DVI Passive Extender over Single Cat.X DVI Passive Extender over Single Cat.X

extends your PC DVI transmission distance up to 30m (100ft) with resolution 1024x768 @60Hz. With

CV-117, users can transmit high quality digital video of PC applications through one cost effective

CAT-5/5e LAN cable to the remote monitor or projector, instead of using short and expensive DVI cables.

With embedded EDID inside the extender, your PC will continue to send the digital video even when the

monitor is not connected. The user can then disconnects the monitor, place it in a remote location and

reconnect it without rebooting the operating system.

The CV-117 includes two identical units: transmitting and receiving units. The transmitting unit is

connected to your PC DVI output and the receiving unit is connected to the monitor or projector. While

successfully connected, the two LED lights on each RJ45 connector will blink. The transmission distance

between the transmitting and receiving units can be up to 30m (100ft) under XGA (1024x768@60Hz) or

15m (50ft) under UXGA (1600x1200@60Hz). With compact size and requiring no power, CV-117 is the

most cost effective choice for bringing your impressive digital video to the remote display.

FEATURES

●DVI 1.0 compliant

●Extends the transmission length from the sources up to 30m (100ft) under XGA (1024x768@60Hz) or

15m (50ft) under WUXGA (1920x1200@60Hz)

●Identical units work at both transmitting and receiving end

●Easy to install

●No external power required

●Compact size

●Direct plug-in

●Perfectly integrated with other DVI over Cat.X series products

PACKAGE CONTENTS

●2x CV-117

●1x User Manual

The length depends on the characteristics and quality of the cables. Higher resolutions and

longer transmission distances require low skew cables (<25ns/100m) for best performance.

Unshielded CAT6 with metal RJ45 connectors is recommended.

SPECIFICATIONS

Model Name

CV-117

Technical

Role of usage

Transmitter [TX]

Receiver [RX]

DVI compliance

DVI 1.0

HDCP compliance

Single-link 165MHz [4.95Gbps]

Video bandwidth

Up to WUXGA [1920x1200@60Hz] & UXGA [1600x1200@60Hz]

Video support

1920x1200@60Hz –15m [50ft]

1024x768@60Hz –25m [80ft]

Video transmission over

category cable

No audio for DVI signal

Input TMDS signal

1.2 Volts [peak-to-peak]

Input DDC signal

5 Volts [peak-to-peak, TTL]

PCB stack-up

4-layer board [impedance control —differential 100Ω; single 50Ω]

Input

1x DVI

1x RJ45

Output

1x RJ45

1x DVI

DVI connector

DVI-D [29-pin male, digital only]

RJ45 connector

WE/SS 8P8C with 2 LED indicators

Mechanical

Housing

Plastic molding

Dimensions

[L x W x H]

Model

[TX/RX] 50 x 40 x 20mm [2” x 1.6” x 0.8”]

Package

170 x 115 x 40mm [6.7” x 4.5” x 1.6”]

Carton

450 x 370 x 300mm [1’6” x 1’3” x 11.8”]

Weight

Model

50g [1.8 oz]

Package

180g [6.3 oz]

Fixedness

Direct plug-in

Power supply

None

Power consumption

0.1 Watt [max]

Operation temperature

0~40°C [32~104°F]

Storage temperature

-20~60°C [-4~140°F]

Relative humidity

20~90% RH [no condensation]

HARDWARE INSTALLATION

1. Connect one of the CV-117 to your DVI source.

2. Connect the other CV-117 to your DVI display.

3. Make sure the CAT-5/5e/6 cable is tightly connected between the DVI source and the display with the

CV-117.

4. The installation is done.

CONNECTION DIAGRAM

DVI OVER SINGLE CAT5 SERIES LINEUP

CV-15

CV-17

CV-117

CV-117E

WP-117A

Output to display

HDMI

DVI

Transmission over CAT5

at 1024x768@60Hz

25m [80ft]

60m [200ft]

25m [80ft]

30m [100ft]

Transmission over CAT5

at 1920x1200@60Hz

15m [50ft]

40m [130ft]

15m [50ft]

Power requirement

TX-No / RX-Yes

Equalization

Yes

EDID learning

Yes

NOTICE

1. The CV-117 may not be compatible with the DVI sources and displays that feature resolutions not in

the aspect ratio of 4:3, 16:9 and 16:10.

2. All DVI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz UTP

cable and ASTRODESIGN Video Signal Generator VG-859C.

3. The transmission length is largely affected by the type of Cat-5/5e/6 cables, the type of HDMI sources,

and the type of HDMI display. The testing result shows solid UTP cables (usually in the form of 300m

[1,000ft] bulk cables) can transmit a lot longer signals than stranded UTP cables (usually in the form of

fixed length patch cords). Shielded STP cables are better suited than unshielded UTP cables. A solid

UTP Cat-5e cable shows longer transmission range than stranded STP Cat-6 cable. For long

extension applications, solid UTP/STP cables are the only viable choice.

4. EIA/TIA-568-B termination (T568B) for Cat-5/5e/6 cables is recommended for better performance.

5. To reduce the interference among the unshielded twisted pairs of wires in Cat-5/5e/6 cable, one can

use shielded STP cables to improve EMI problems, which is worsen in long transmission.

6. Because the quality of the CAT5/6 cables has the major effect on how long the transmission limit can

achieve and how good is the received picture quality, the actual transmission range is subject to one's

choice of Cat-5/5e/6 cables. For desired resolutions greater than 1080i or 1280x1024, a Cat-6 cable is

recommended.

Performance Guide for HDMI over Category Cable Transmission

Performance rating

Type of category cable

Wiring

Shielding

CAT5

CAT5e

CAT6

Solid

Unshielded (UTP)







Shielded (STP)





Stranded

Unshielded (UTP)





Shielded (STP)





Termination

Please use EIA/TIA-568-B termination (T568B) at any time

WARRANTY

The SELLER warrants the CV-117 DVI Passive Extender over Single Cat.X free from defects in

the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized

dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at

its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster,

abuse or any unauthorized modifications including static discharge and power surge. This warranty is

offered by the SELLER for its BUYER with direct transaction only. This warranty is void if the warranty

seal on the metal housing is broken.

Unit that fails under conditions other than those covered will be repaired at the current price of parts

and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of reshipment

to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume the risk of loss

or damage in transit. Under no circumstances will a unit be accepted without a return authorization

number.

The warranty is in lieu of all other warranties expressed or implied, including without limitations, any

other implied warranty or fitness or merchantability for any particular purpose, all of which are expressly

disclaimed.

Proof of sale may be required in order to claim warranty. Customers outside Taiwan are responsible

for shipping charges to and from the SELLER. Cables and power adapters are limited to a 30 day

warranty and must be free from any markings, scratches, and neatly coiled.

The content of this manual has been carefully checked and is believed to be accurate. However, The

SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The

SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting

from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the

technical information contained herein regarding the CV-117 features and specifications is subject to

change without further notice.
