Golmar M700 Manual de usuario

USER MANUAL |M700 |3

SISTEMASDECOMUNICACIÓN,S.A.

CONTENT

1 GENERALDESCRIPTION

1.1 Monitor screens Status

2 MENU ICONS DESCRIPTION AND FUNCTIONALITIES

2.1 View Entries

2.2 Call Porter

2.3 Intercom call

2.4 Missed calls / Picture recording

2.5 Text Messages

3 COMMUNICATIONSTATUSDESCRIPTION

3.1 Incoming call from a video entry panel

3.2 Incoming call from an apartment

3.3 Incoming call from a concierge station M201/ C

3.4 Communication

4 CAUTIONSAND MAINTENANCE

SISTEMASDECOMUNICACIÓN,S.A.

M700 User Manual – Rev FW1.21

2.6 Screen Clean Lock

2.7 User Guide

USER MANUAL |M700 |5

SISTEMASDECOMUNICACIÓN,S.A.

|M700 | USER MANUAL

M700

1.- GENERALDESCRIPTION

M700 is an advanced and future proof monitor which is being engined with latest IP

technology. The monitor is constructed in ASA plastics, glass and aluminium.

M700 monitors are operated through a 7 inch. capacitive touch glass screen. The real

feel of touch and the big icons makes M700 monitors user friendly even for elderly people.

M700 monitor is equipped with high fidelity loudspeaker and microphone. Thanks to its eco

cancelling driver and algoritm,a very clear ad free of interferences audio will be reproduced.

1.1 Monitor screens Status

It can be differentiated three basic status of the monitor screen:

a.- Stand by: The monitor is off, the screen is black.

b.- Main Menu, The screen is ON and displays icons.

c.-

d.- Communication status (described on point 3).

2.- MENU ICONSDESCRIPTION AND FUNCTIONALITIES

2.1 View Entries

When tracking from a camera is activated, the screen will show the following information:

Panel label from the panel that is being activated.

Arrows right and/ or left in case there is more than one panel, being possible to move

through them activating one by one.

Icon to activate the audio communication with the selected panel camera.

M700 User Manual – Rev FW1.21

Notification, the monitor with the screen off blinks the red LED plced at the bottom

left.

When this button is pressed a pop up list appears showing all available

cameras. The available cameras are these from which we can receive a call. We shall

select the camera that we would like to activate by pressing the name from the list.

When this button is pressed a pop up list appears showing all available

cameras. The available cameras are these from which we can receive a call. We shall

select

User Manual – Rev FW1.21

2.- MENU ICONSDESCRIPTION AND FUNCTIONALITIES

2.2 Call Porter

showing the available concierges to be called. If your apartment block doesn’t

has any concierge this icon will be highlighted in red when pressed.

USER MANUAL |M700 |7

SISTEMASDECOMUNICACIÓN,S.A.

|M700 | USER MANUAL

2.- MENU ICONSDESCRIPTION AND FUNCTIONALITIES

2.3 Intercom call

How to call a monitor: Scroll and navigate among the available monitors by

dragging the list with the finger, until the desired appartment appears on screen.

Press shortly over the label of the desired apartment. A call will instantly start.

If the apartment monitor starts the call, it will show the call process on screen.

In case the apartment is busy or the targeted monitor can not be reached the

monitor label will be highlighted in red.

Press on the intercom call button again in order to come back to main menu.

M700 User Manual – Rev FW 1.21

By pressing the button with the this icon, a list will pop-up and be displayed

To start a call, simply drag with the finger to move along the list of

available concierges or move through the arrows up and down. Once the

desired concierge appears on screen press shortly over. A call will be

generated.

To go back to main menu, press again the icon from the concierge.

Two icons refer to an intercom call. Call inside, refers to these monitors which

are in our own apartment. Call outside, refers to these monitors which are out

from our apartment and with which we have authorization from the

administrator to stablish an intercom call.

2.- MENU ICONSDESCRIPTION AND FUNCTIONALITIES

2.4 Missed calls and picture recording

By pressing the missed calls button, last picture will appear on screen.

Each image corresponds to a Missed call being generated when an incoming

call has not been answered from the monitor.

There are two methods to know that there are pictures from missed calls

unchecked:

– The monitor automatically blinks the red LED at the bottom left part.

Once the images are checked the monitor will not blink until new images are

stored.

– On the main menu, the icon of the missed calls will display a number in orange

notifying the number of images that have been unchecked. Once checked this

number will disappear.

To delete an image, simply press the bin button once the image is displayed.

2.- MENU ICONSDESCRIPTION AND FUNCTIONALITIES

2.5 Text Messages

By pressing the Messages button a list of text messages will appear.

TextMessagesaresentbytheconciergeorbuildingadministratorlocallyorremotely.

There are two methods to know that there are text messages unchecked:

– The monitor blinks the red LED at the bottom left.

– On the main menu, the icon of the Text messages will display a number

notifying the number of messages that have been unchecked. Once

checked this number will disappear.

USER MANUAL |M700 |9

SISTEMASDECOMUNICACIÓN,S.A.

|M700 | USER MANUAL

M700 User Manual – Rev FW 1.21 M700 User Manual – Rev FW 1.21

It is possible to move through the stored messages by dragging the list

with the finger.

To delete a message, simply press the bin button linked to the corrresponding message.

3.- COMMUNICATION STATUSDESCRIPTION

3.1 Incoming call from a video entry panel

When a call is generated to the apartment, the monitor starts to ring. It rings 6

times while the video image will appear on screen. It is shown as well the panel

label fromwhich thecall is comingin order to identify the entrypanel of thecall.

At this point it is possible to:

Start the Audio communication: by pressingthe Answer button.

Activate the lock: without need of starting the communication. If enabled in the

configuration of the monitor, two locks can be activated. Lock no.1 is activated

with a short press. If the monitor has been programmed accordingly a

secondarylock can be activated by pressingthe second lock button.

Cancel the call: By pressing the cross the incoming call will be ended

independently if Audio communication started or not. It is possible to finish

the Audio communication once started by simply pressing the cross.

MutetheRingtone:ThemonitorStopsringingbut theincomingcall still is up.

3.- COMMUNICATION STATUSDESCRIPTION

3.2 Incoming call from an apartment

When a call is generated to the apartment, the monitor starts to ring. It is shown

as well the apartment label from which the call is coming in order to identify the

calling apartament.

At this point it is possible to:

Start the Audio communication: by pressingthe Answer button..

Cancel the call: By pressing the cross the incoming call will be ended

independently if Audio communication started or not. It is possible to f nish

the Audio communication once started by simply hanging off the handset

(M201 model only)

Mute the Ring tone: The monitor Stops ringing but the incoming call still is

on hold.

3.3 Incoming call from a concierge station M201/ C

The operation is exactly the same as described for Incoming calls from an

apartment in the previous point.

USER MANUAL |M700 |13

SISTEMASDECOMUNICACIÓN,S.A.

|M700 | USER MANUAL

M700 User Manual – Rev FW1.21

3.- COMMUNICATION STATUSDESCRIPTION

3.4 Communication

Once the communication is started it is possible to:

Activate the lock: without starting the communication. Depending on the

configuration of the monitor two locks can be activated. Lock no.1 is activated

with a short press. If the monitor has been programmed accordingly a

secondary lock can be activated by pressing this button during three seconds.

Finish the call: By pressing the cross.

4.- SPECIFICATIONS, CAUTIONS ANDMAINTENANCE

A-Specifications

B - Cautions

This product is an electronicvideo monitor.

Do not through liquids over the unit. Anyliquid coming into the product maycause

failure or f re.

Do not expose the unit at a high temperatures, corrosive environments or high

humidity grade.

Do not hang neither place any other product on it. The bracket might brake as is

designed tu support its own weight. Puling, pushing or climbing on it may cause the

monitor to fall.

This is a professional product. We strongly recommend follow the installation

specif cations and leave the installation to a Golmar certif ed installer.

C- Maintenance

The product is manufactured in high quality materials. Do not use chemical

products or abrasives or cleaning agents. Clean the product with a soft cloth dampened

with asmall amount of water.

USER MANUAL |M700 |15

SISTEMASDECOMUNICACIÓN,S.A.

|M700 | USER MANUAL

Characteristics Values standard

Power consumption idle: 2W, fully ac

Voltage 48VDC IEEE800.3AF

Screen 7 inch. full touch capacitive. .

Temperature range

Humidity:

-20° to 70°

10% ~ 90% non-condensing

Dimensions and weight 227 (W) 139 (H) 15 (D)mm | 700 gr. (packed)

Construction ASA plastics, capacitive glass and Aluminium

M700 User Manual – Rev FW1.21 M700 User Manual – Rev FW1.21

Disable the monitor microphone. This option mutes the panel loudspeaker in

order to get privacy in the apartment at any time during the communication.

Adjust the volume of the communication.

|M700 | USER MANUAL

NOTES

Other warnings:

The actual design and specif cation of the product might change with no prior notif cation.

The actual appearance of the product may differ from the images used in this manual.
