Global Sat ET-332 Manual de usuario

ET-332

Specifications are subject to be changed without notice.

Page 1 of 15

Version 1.3.1

GPS Engine Board

ET-332

Globalsat Technology Corporation

16F., No. 186, Jian-Yi Road, Chung-Ho City, Taipei Hsien 235,

Ta i wa n

Tel: 886-2-8226-3799/ Fax: 886-2-8226-3899

service@globalsat.com.tw

www.globalsat.com.tw

USGlobalSat, Inc.

1308 John Reed Court, City of Industry, CA 91745

Tel: 626-968-4145 / Fax: 626-968-4373

oem@usglobalsat.com

www.usglobalsat.com

ET-332

Specifications are subject to be changed without notice.

Page 2 of 15

Version 1.3.1

1. Product Information

Product Part I.D. ET-332

Product Description:

The ET-332 GPS engine board is low cost but maintains high reliability and accuracy making it an

ideal choice for integration with OEM/ODM systems.

Product Features:

9SiRF Star III/ LP Single

9Very high sensitivity (Tracking Sensitivity: -159dBm)

9Compact PCB allows for easier integration into space limited environments.

9Supports the NMEA 0183 data protocol

9Foliage Lock for weak signal tracking

9All-in-view 20-channel parallel processing

9Snap Lock 100mc re-acquisition time

9Enhanced algorithm for navigation stability

9Superior urban canyon performance

9WAAS / EGNOS MSAS support

9Built-in SuperCap to maintain system data for rapid satellite acquisition

9RoHS compliant

Product Specifications

GPS Receiver

Chipset SiRF Star III/LP Single

Frequency L1, 1575.42 MHz

Code 1.023 Mhz chip rate

Protocol Electrical Level: TTL level,

Output Voltage Level: 0V~2.85V

Baud Rate: 4800 bps

Output Message: NMEA 0183 GGA, GSA,

GSV, RMC (VTG, GLL optional)

Channels 20

Sensitivity -159dBm

Cold Start 42 seconds average

ET-332

Specifications are subject to be changed without notice.

Page 3 of 15

Version 1.3.1

Warm Start 38 seconds average

Hot Start 1 second average

Reacquisition 0.1 second average

Accuracy Position: 10 meters, 2D RMS

5 meters, 2D RMS, WAAS

enabled

Velocity: 0.1 m/s

Time: 1us synchronized to GPS time

Maximum Altitude 18,000 meter (60,000 feet) max

Maximum Velocity 515 meter/second (1000 knots) max

Maximum Acceleration 4G

Jerk 20m/sec **3

Interface

I/O Connector Type

External Antenna Port

Physical Characteristics

Dimensions 1.6” x 1.4” x 0.4” (40.5 x 35 x 10 mm)

DC Characteristics

Power Supply 3.8V ~ 6.5V DC Input

Backup Voltage 2.5 ~ 3.6V 10uA backup current

Power Consumption 42mA (Continuous Mode)

25mA (Trickle Power Mode)

Environmental Range

Humidity Range 5% to 95% non-condensing

Operation Temperature -40F to +176F (-40C to +85C)

ET-332

Specifications are subject to be changed without notice.

Page 4 of 15

Version 1.3.1

2. Technical Information

Physical Characteristics

ET-332

Specifications are subject to be changed without notice.

Page 5 of 15

Version 1.3.1

Pin Assignment

Pin Name Description Type

1 GND Ground

2 VBAT Backup Battery Input

3 VDC 3.8V~6.5V DC Power Input Input

4 PBRES Push Button Reset Input (Active Low) Input

5 GPIO1 (Reserved)

6 TXA Serial Data Output A (GPS Data) Output

7 RXA Serial Data Input A (Command) Input

8 GND Ground

9 GND Ground

10 SELECT (Reserved)

11 TIMEMARK 1PPS Time Mark Output Output

12 GND Ground

ET-332

Specifications are subject to be changed without notice.

Page 6 of 15

Version 1.3.1

Pin Explanation

VCC: (DC power input) This is the main DC supply for a 3.8V ~ 6.5V power module board.

VBAT: This is the battery backup input that powers the SRAM and RTC when main power is removed.

Typical current draw is 10uA. Without an external backup battery, the module/engine board will execute a

cold star after every turn on. To achieve the faster start-up offered by a hot or warm start, a battery

backup must be connected. To maximize battery lifetime, the battery voltage should be between 2.5v and

3.6v.

PBRES: (Push Button Reset) This pin provides an active-low reset input to the engine board. It causes

the engine board to reset and start searching for satellites.

SELECT: Do not connect (do not use)

TX: This is the main transmit channel for outputting navigation and measurement data to user’s

navigation software or user-written software. Output TTL level, 0V ~ 2.85V

RX: This is the main receive channel for receiving software commands to the engine board from

SiRfdemo software or from user-written software. (NOTE:When not in use this pin must be kept “HIGH”

for operation. From Vcc connect a 470 Ohm resistor in series with a 3.2v Zener diode to Ground. Then,

connect the Rx input to Zener’s cathode to pull the input “HIGH”.)

TIME MARK (1PPS): This pin provides one pulse-per-second output from the engine board that is

synchronized to GPS time

GND: GND provides the ground for the engine boards. Be sure to connect all grounds

Mounting

Recommended mounting methods:

a. Use industrial grade double-sided foam tape. Place it on the bottom side of the engine board.

b. A recessed cavity in your housing design with a foam pad to eliminate shifting or movement.

c. Use provided mounting holes on the GPS engine board PCB.

3. Software Commands

NMEA Output Command

GGA-Global Positioning System Fixed Data

Table B-2 contains the values for the following example:

$GPGGA,161229.487,3723.2475,N,12158.3416,W,1,07,1.0,9.0,M,,,,0000*18

ET-332

Specifications are subject to be changed without notice.

Page 7 of 15

Version 1.3.1

Table B-2 GGA Data Format

Name Example Units Description

Message ID $GPGGA GGA protocol header

UTC Time 161229.487 hhmmss.sss

Latitude 3723.2475 ddmm.mmmm

N/S Indicator N N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

Position Fix Indicator 1 See Table B-3

Satellites Used 07 Range 0 to 12

HDOP 1.0 Horizontal Dilution of Precision

MSL Altitude19.0 meters

Units M meters

Geoid Separation1meters

Units M meters

Age of Diff. Corr. second Null fields when DGPS is not used

Diff. Ref. Station ID 0000

Checksum *18

<CR><LF> End of message termination

SiRF Technology Inc. does not support geoid corrections. Values are WGS84 ellipsoid heights.

Table B-3 Position Fix Indicator

Value Description

0 Fix not available or invalid

1 GPS SPS Mode, fix valid

2 Differential GPS, SPS Mode , fix valid

3 GPS PPS Mode, fix valid

GLL-Geographic Position-Latitude/Longitude

Table B-4 contains the values for the following example:

$GPGLL,3723.2475,N,12158.3416,W,161229.487,A*2C

Table B-4 GLL Data Format

Name Example Units Description

Message ID $GPGLL GLL protocol header

Latitude 3723.2475 ddmm.mmmm

N/S Indicator n N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

ET-332

Specifications are subject to be changed without notice.

Page 8 of 15

Version 1.3.1

UTC Position 161229.487 hhmmss.sss

Status A A=data valid or V=data not valid

Checksum *2C

<CR><LF> End of message termination

GSA-GNSS DOP and Active Satellites

Table B-5 contains the values for the following example:

$GPGSA,A,3,07,02,26,27,09,04,15,,,,,,1.8,1.0,1.5*33

TableB-5GSADataFormat

Name Example Units Description

Message ID $GPGSA GSA protocol header

Mode1 A See Table B-6

Mode2 3 See Table B-7

Satellite Used107 Sv on Channel 1

Satellite Used102 Sv on Channel 2

Satellite Used1Sv on Channel 12

PDOP 1.8 Position dilution of Precision

HDOP 1.0 Horizontal dilution of Precision

VDOP 1.5 Vertical dilution of Precision

Checksum *33

<CR><LF> End of message termination

1. Satellite used in solution.

TableB-6Mode1

Value Description

M Manual-forced to operate in 2D or 3D mode

A 2D automatic-allowed to automatically switch 2D/3D

TableB-7Mode2

Value Description

1 Fix Not Available

2 2D

3 3D

GSV-GNSS Satellites in View

Table B-8 contains the values for the following example:

$GPGSV,2,1,07,07,79,048,42,02,51,062,43,26,36,256,42,27,27,138,42*71

ET-332

Specifications are subject to be changed without notice.

Page 9 of 15

Version 1.3.1

$GPGSV,2,2,07,09,23,313,42,04,19,159,41,15,12,041,42*41

TableB-8GSVDataFormat

Name Example Units Description

Message ID $GPGSV GSV protocol header

Number of Messages12 Range 1 to 3

Message Number11 Range 1 to 3

Satellites in View 07

Satellite ID 07 Channel 1(Range 1 to 32)

Elevation 79 degrees Channel 1(Maximum90)

Azimuth 048 degrees Channel 1(True, Range 0 to 3

SNR(C/No) 42 dBHz Range 0 to 99,null when not tr

……. …….

Satellite ID 27 Channel 4 (Range 1 to 32)

Elevation 27 Degrees Channel 4(Maximum90)

Azimuth 138 Degrees Channel 4(True, Range 0 to 3

SNR(C/No) 42 dBHz Range 0 to 99,null when not tr

Checksum *71

<CR><LF> End of message termination

Depending on the number of satellites tracked multiple messages of GSV data may be required.

ET-332

Specifications are subject to be changed without notice.

Page 10 of 15

Version 1.3.1

RMC-Recommended Minimum Specific GNSS Data

Table B-9 contains the values for the following example:

$GPRMC,161229.487,A,3723.2475,N,12158.3416,W,0.13,309.62,120598,,*10

Table B-9 RMC Data Format

Name Example Units Description

Message ID $GPRMC RMC protocol header

UTC Time 161229.487 hhmmss.sss

Status A A=data valid or V=data not valid

Latitude 3723.2475 ddmm.mmmm

N/S Indicator N N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

Speed Over Ground 0.13 knots

Course Over Ground 309.62 degrees True

Date 120598 ddmmyy

Magnetic Variation2degrees E=east or W=west

Checksum *10

<CR><LF> End of message termination

SiRF Technology Inc. does not support magnetic declination. All “course over ground” data are

Geodetic WGS48 directions.

VTG-Course Over Ground and Ground Speed

$GPVTG,309.62,T,,M,0.13,N,0.2,K*6E

Table B-9 VTG Data Format

Name Example Units Description

Message ID $GPVTG VTG protocol header

Course 309.62 degrees Measured heading

Reference T True

Course degrees Measured heading

Reference M Magnetic

Speed 0.13 knots Measured horizontal speed

Units N Knots

Speed 0.2 Km/hr Measured horizontal speed

Units K Kilometers per hour

Checksum *6E

<CR><LF> End of message termination

Otros manuales para ET-332

Tabla de contenidos

Otros manuales de GPS de Global Sat

Global Sat

Global Sat TR-102 Manual de usuario

Global Sat

Global Sat TR-101 Manual de usuario

Global Sat

Global Sat MobileDefender 4 Manual de usuario

Global Sat

Global Sat GS-Traq TR-206 Manual de usuario

Global Sat

Global Sat ET-333 Manual de usuario

Global Sat

Global Sat EB-3531 Manual de usuario

Global Sat

Global Sat GA-5718 Manual de usuario

Global Sat

Global Sat GH-505 Manual de usuario

Global Sat

Global Sat EM-318-02 Manual de usuario

Global Sat

Global Sat GV-370 Manual de usuario

Global Sat

Global Sat TR-600 Manual de usuario

Global Sat

Global Sat ND-100S Manual de usuario

Global Sat

Global Sat ET-318 Manual de usuario

Global Sat

Global Sat ET-333 Manual de usuario

Global Sat

Global Sat BT-368 Manual de usuario

Global Sat

Global Sat MR-350 Manual de usuario

Global Sat

Global Sat DG-200 Manual de usuario

Global Sat

Global Sat EM-408 Manual de usuario

Global Sat

Global Sat EM-406a Manual de usuario

Global Sat

Global Sat LT-300 Series Manual de usuario

Global Sat

Global Sat USB GPS Dongle ND-100 Manual de usuario

Global Sat

Global Sat SiRF star III BT-359 Manual de usuario

Global Sat

Global Sat ET-316A Manual de usuario

Global Sat

Global Sat BT-368i Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario
