Gigabyte GA-K8NE Manual de usuario

GA-K8NE

AMD Socket 754 Processor Motherboard

User's Manual

Rev. 2004

12ME-K8NE-2004R

* The WEEE marking on the product indicates this product must not be disposed of with user's other household waste

and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!!

* The WEEE marking applies only in European Union's member states.

Sep. 20, 2005

Motherboard

GA-K8NE

Motherboard

GA-K8NE

Sep. 20, 2005

The trademarks mentioned in the manual are legally registered to their respective companies.

Notice

The written content provided with this product is the property of Gigabyte.

No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any

means without Gigabyte's prior written permission. Specifications and features are subject to

change without prior notice.

Product Manual Classification

In order to assist in the use of this product, Gigabyte has categorized the user manual in the

following:

For quick installation, please refer to the "Hardware Installation Guide" included with the

product.

For detailed product information and specifications, please carefully read the

"Product User Manual".

For detailed information related to Gigabyte's unique features, please go to "Technology

Guide" section on Gigabyte's website to read or download the information you need.

For more product details, please click onto Gigabyte's website at www.gigabyte.com.tw

- 4 -

Table of Contents

GA-K8NE Motherboard Layout ...................................................................................... 6

Block Diagram ................................................................................................................ 7

Chapter 1 Hardware Installation .................................................................................... 9

1-1 Considerations Prior to Installation .................................................................... 9

1-2 Feature Summary .......................................................................................... 10

1-3 Installation of the CPU and Heatsink .............................................................. 12

1-3-1 Installation of the CPU ......................................................................................... 12

1-3-2 Installation of the Heatsink .................................................................................. 13

1-4 Installation of Memory .................................................................................... 13

1-5 Installation of Expansion Cards ...................................................................... 15

1-6 I/O Back Panel Introduction ........................................................................... 16

1-7 Connectors Introduction .................................................................................. 17

Chapter 2 BIOS Setup ................................................................................................ 27

The Main Menu (For example: BIOS Ver. : F1b)...................................................... 28

2-1 Standard CMOS Features ............................................................................. 30

2-2 Advanced BIOS Features .............................................................................. 32

2-3 Integrated Peripherals ..................................................................................... 34

2-4 Power Management Setup ............................................................................. 37

2-5 PnP/PCI Configurations ................................................................................. 39

2-6 PC Health Status ........................................................................................... 40

2-7 MB Intelligent Tweaker(M.I.T.) ....................................................................... 43

2-8 Top Performance ............................................................................................. 44

2-9 Load Optimized Defaults ................................................................................. 44

2-10 Set Supervisor/User Password ..................................................................... 45

2-11 Save & Exit Setup ......................................................................................... 46

2-12 Exit Without Saving ....................................................................................... 46

- 5 -

Chapter 3 Drivers Installation ...................................................................................... 47

3-1 Install Chipset Drivers .................................................................................... 47

3-2 SoftwareApplication ....................................................................................... 48

3-3 Software Information ....................................................................................... 48

3-4 Hardware Information ..................................................................................... 49

3-5 Contact Us ..................................................................................................... 49

Chapter 4 Appendix ................................................................................................... 51

4-1 Unique Software Utilities ................................................................................ 51

4-1-1 EasyTune 5 Introduction ..................................................................................... 52

4-1-2 Xpress Recovery Introduction ........................................................................... 53

4-1-3 Flash BIOS Method Introduction ........................................................................ 56

4-1-4 Serial ATA BIOS Setting Utility Introduction ...................................................... 65

4-1-5 2- / 4- / 6- / 8- Channel Audio Function Introduction ...................................... 71

4-2 Troubleshooting ............................................................................................... 75

- 6 -

GA-K8NE Motherboard Layout

ATX

MS/KB

LPT

COMA

IDE2 IDE1

ATX_12V

Socket 754

USB

LAN

SPDIF_O

SPDIF_I

COMB

IT8712

nVIDIA®

nForceTM 4(-4X)

PCI1

PCI2

F_USB2

F_USB1

SATAII0

SYS_FAN

F_PANEL

PCI3

CD_IN

PCIE_16

SATAII2

F_USB3

DDR3

DDR2

DDR1

FDD

CODEC

BIOS

GA-K8NE

CPU_FAN

BAT

CLR_CMOS

AUDIO1

F_AUDIO

Marvell phy

AUDIO2

PCIE_1

PCIE_2

PWR_LED

SATAII1

SATAII3

- 7 -

Block Diagram

(Note) Because of CPU limitations, if you want to install DDR400 memory modules in your system, please

install either one double-sided or two single-sided DDR400 memory modules. The DDR400 speed

will drop down to DDR333 if you install two double-sided or three single-sided DDR400 memory

modules.

Line-Out

MIC

Line-In

SPDIF In

SPDIF Out

Side Speaker Out

Center/Subwoofer Speaker Out

Surround Speaker Out

nVIDIA®

nForce4(-4X)

24MHz

33MHz

4 Serial ATA

ATA33/66/100/133

IDE Channels

PCICLK

(33MHz)

3PCI

PCI Bus

10 USB

Ports

Floppy

PS/2 KB/Mouse

LPT Port

PCI-ECLK

(100MHz)

LPC BUS

CODEC

2 PCI Express x 1

RJ45

PCI Express x 1 Bus

PCI-ECLK

(100MHz)

BIOS

PCI Express x 16

DDR 400(Note)/333/266/200MHz DIMM

DDR RAM

AMD K8

Socket 754

CPU

CPUCLK+/-(200MHz)

Hyper Transport Bus

IT8712

COM Ports

x 1 x 1

Marvell

phy

- 8 -

Hardware Installation- 9 -

English

1-1 Considerations Prior to Installation

Preparing Your Computer

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please

follow the instructions below:

1. Please turn off the computer and unplug its power cord.

2. When handling the motherboard, avoid touching any metal leads or connectors.

3. It is best to wear an electrostatic discharge (ESD) cuff when handling electronic components

(CPU, RAM).

4. Prior to installing the electronic components, please have these items on top of an antistatic

pad or within a electrostatic shielding container.

5. Please verify that the power supply is switched off before unplugging the power supply

connector from the motherboard.

Installation Notices

1. Prior to installation, please do not remove the stickers on the motherboard. These stickers

are required for warranty validation.

2. Prior to the installation of the motherboard or any hardware, please first carefully read the

information in the provided manual.

3. Before using the product, please verify that all cables and power connectors are connected.

4. To prevent damage to the motherboard, please do not allow screws to come in contact with

the motherboard circuit or its components.

5. Please make sure there are no leftover screws or metal components placed on the motherboard

or within the computer casing.

6. Please do not place the computer system on an uneven surface.

7. Turning on the computer power during the installation process can lead to damage to system

components as well as physical harm to the user.

8. If you are uncertain about any installation steps or have a problem related to the use of the

product, please consult a certified computer technician.

Instances of Non-Warranty

1. Damage due to natural disaster, accident or human cause.

2. Damage as a result of violating the conditions recommended in the user manual.

3. Damage due to improper installation.

4. Damage due to use of uncertified components.

5. Damage due to use exceeding the permitted parameters.

6. Product determined to be an unofficial Gigabyte product.

Chapter 1Hardware Installation

GA-K8NE Motherboard - 10 -

English

CPU Socket 754 for AMD AthlonTM 64 processor (K8)

1600MH/z system bus

Supports core frequencies in excess of 3000+ and faster

Chipset nVIDIA®nForce4(-4X) Chipset

Supported on the Win 2000/XP operating systems

Memory 3 DDR DIMM memory slots (supports up to 3GB memory)

Supports DDR 400 (Note 1)/333/266/200 DIMM

Slots 1 PCI Express x 16 slot

2 PCI Express x 1 slots

3 PCI slots

IDE Connections 2 IDE connection (UDMA 33/ATA 66/ATA 100/ATA 133), allows connection of

4 IDE devices

Supported on the Win 2000/XP operating systems

FDD Connections 1 FDD connection, allows connection of 2 FDD devices

Onboard SATA 4 Serial ATA ports from nVIDIA®nForce4(-4X) controller (SATAII0_1, SATAII2_3)

Supported on the Win 2000/XP operating systems

Peripherals 1 parallel port supporting Normal/EPP/ECP mode

1 serial port (COMA), onboard COMB connection

10 USB 2.0/1.1 ports (rear x 4, front x 6 via cable)

1 front audio connector

1 PS/2 keyboard port

1 PS/2 mouse port

Onboard LAN Onboard Marvell 88E1111/88E1115 chip (10/100/1000 Mbit)

1 RJ 45 port

Supported on the Win 2000/XP operating systems

Onboard Audio ALC850 CODEC (UAJ)

Supports 2 / 4 / 6 / 8 channel audio (Note 2)

Supports Line In ; Line Out (Front Speaker Out) ; MIC ; Surround Speaker Out

(Rear Speaker Out) ; Center/Subwoofer Speaker Out ;

Side Speaker Out connection

Supports SPDIF In/Out connection

CD In

I/O Control IT8712

1-2 Feature Summary

(Note 1) Because of CPU limitations, if you want to install DDR400 memory modules in your system,

please install either one double-sided or two single-sided DDR400 memory modules. The

DDR400 speed will drop down to DDR333 if you install two double-sided or three single-sided

DDR400 memory modules.

(Note 2) To set up an 8 channel audio configuration, you must use Audio Combo Kit (optional device).
