Gigabyte GA-8IG1000 Pro-G Manual de usuario

When you installingAGP card, please make sure the following notice

is fully understood and practiced. If your AGP card has "AGP 4X/8X

(1.5V) notch"(show below), please make sure your AGP card is AGP

4X/8X (1.5V).

Caution:AGP 2X card is not supported by Intel®845(GE/PE) / 845(E/G)

/ 850(E) / E7205 / 865(G/PE/P) / 875P. You might experience system

unable to boot up normally. Please insert an AGP4X/8X card.

Example 1: Diamond Vipper V770 golden finger is compatible with 2X/4X

modeAGPslot.ItcanbeswitchedbetweenAGP2X(3.3V)or4X(1.5V)mode

by adjusting the jumper. The factory default for this card is 2X(3.3V). The

GA-8IG1000 Series (or any AGP 4X/8X only) motherboards might not

function properly, if you install this card without switching the jumper to 4X

(1.5V) mode in it.

Example2:SomeATiRage128Prographicscardsmade by "Power Color",

thegraphicscardmanufacturer & some SiS305cards,their golden finger is

compatible with 2X(3.3V)/4X(1.5V) modeAGP slot, but they support 2X

(3.3V)only.TheGA-8IG1000Series(oranyAGP4X/8Xonly)motherboards

might not function properly, If you install this card in it.

Note :Although Gigabyte'sAG32S(G) graphics card is based onATi Rage

128 Pro chip, the design ofAG32S(G) is compliance with AGP 4X(1.5V)

specification. Therefore,AG32S(G) will work fine with Intel®845(GE/PE) /

845(E/G) / 850(E) / E7205 / 865(G/PE/P) / 875P based motherboards.

Before you install PCI cards, please remove the Dual BIOS label from PCI

slots if there is one.

AGP 4X/8X notch

0The author assumes no responsibility for any errors

or omissions that may appear in this document nor

does the author make a commitment to update the

information contained herein.

0Third-party brands and names are the property of

their respective owners.

0Please do not remove any labels on motherboard, this

may void the warranty of this motherboard.

0Due to rapid change in technology, some of the

specifications might be out of date before publication

of this booklet.

Jan. 15, 2004

Mother Board

GA-8IG1000 Pro-G/GA-8IG1000-G/GA-8IG1000

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109

(a),Class B Digital Device

DECLARATION OF CONFORMITY

Per FCC Part 2 Section 2.1077(a)

Responsible Party Name:

Address:

Phone/Fax No:

hereby declares that the product

Product Name:

Conforms to the following specifications:

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful and (2) this device must accept any inference received,

including that may cause undesired operation.

Representative Person'sName:

Signature: Eric Lu

Supplementary Information:

Model Number:

17358 Railroad Street

City of Industry, CA 91748

G.B.T. INC. (U.S.A.)

(818) 854-9338/ (818) 854-9339

Motherboard

GA-8IG1000 Pro-G/GA-8IG1000-G/

GA-8IG1000

Date:

ERIC LU

Jan. 15, 2004

USER'S MANUAL

GA-8IG1000 Series

P4 Titan Series Motherboard

Pentium®4 Processor Motherboard

Rev.3003

12ME-8IG1KG-3003

- 2 -GA-8IG1000 Series Motherboard

English

Table of Contents

Warning...................................................................................................4

Chapter 1 Introduction............................................................................5

Features Summary....................................................................................... 5

GA-8IG1000 Series Motherboard Layout..................................................... 8

Block Diagram.............................................................................................. 9

Chapter 2 Hardware Installation Process.............................................11

Step 1: Install the Central Processing Unit (CPU)...................................... 12

Step 1-1: CPU Installation ........................................................................................................ 12

Step 1-2 : CPU Cooling Fan Installation .................................................................................. 13

Step 2: Install Memory Modules................................................................. 14

Step 3: Install Expansion Cards ................................................................. 17

Step 4: Connect Ribbon Cables, Cabinet Wires, and Power Supply ......... 18

Step 4-1: I/O Back Panel Introduction ...................................................................................... 18

Step 4-2: Connectors & Jumpers Setting Introduction ............................................................. 20

Chapter 3 BIOS Setup .........................................................................35

The Main Menu (For example: BIOS Ver. : E2).......................................... 36

Standard CMOS Features.......................................................................... 38

Advanced BIOS Features........................................................................... 41

Integrated Peripherals................................................................................ 43

Power Management Setup......................................................................... 48

PnP/PCI Configurations ............................................................................. 50

PC Health Status........................................................................................ 51

Frequency/Voltage Control......................................................................... 53

Table of Content

English

- 3 -

(*)For GA-8IG1000 Pro-G only.

Select Language(*).................................................................................................................................................... 56

Load Fail-Safe Defaults.............................................................................. 57

Load Optimized Defaults............................................................................ 58

Set Supervisor/User Password .................................................................. 59

Save & Exit Setup ...................................................................................... 60

Exit Without Saving .................................................................................... 61

Chapter 4 Technical Reference ............................................................63

@BIOS™Introduction ................................................................................. 63

EasyTune™4 Introduction .......................................................................... 64

Flash BIOS Method Introduction ................................................................ 65

2- / 4- / 6- / 8-ChannelAudio Function Introduction.................................... 75

Jack-Sensing(UAJ) Introduction................................................................. 81

Xpress Recovery Introduction .................................................................... 83

Chapter 5 Appendix..............................................................................87

- 4 -GA-8IG1000 Series Motherboard

English

Warning

Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips.To

protectthemagainstdamage from static electricity,youshouldfollowsome precautions wheneveryou

workonyour computer.

1. Unplugyourcomputer whenworkingon the inside.

2. Usea grounded wriststrap before handlingcomputer components.Ifyou donot have

one,touch bothof yourhands to a safely groundedobject orto ametal object,such as

thepowersupply case.

3. Holdcomponents bythe edges andtry nottouch theIC chips, leads or connectors,or

othercomponents.

4. Placecomponents on agrounded antistaticpad oron the bagthat camewith the

componentswheneverthe componentsareseparated from thesystem.

5. Ensurethat theATXpower supplyis switchedoffbeforeyou plugin orremove theATX

owerconnectoronthe motherboard.

Ifthemotherboardhasmountingholes, buttheydon'tlineupwiththeholesonthebaseandthere

are no slots to attach the spacers, do not become alarmed you can still attach the spacers to the

mountingholes.Justcutthebottomportion ofthespacers(thespacermaybealittlehardtocutoff,so

becarefulofyourhands).Inthiswayyoucanstillattachthemotherboardtothebasewithoutworrying

aboutshort circuits.Sometimes you may need touse theplastic springsto isolatethe screw from the

motherboard PCB surface, because the circuit wire may be near by the hole. Be careful, don't let the

screwcontactanyprintedcircuitwriteorpartsonthePCBthatarenearthefixinghole,otherwiseitmay

damagetheboard orcauseboard malfunctioning.

Installing the motherboard to the chassis…

Introduction- 5 -

English

Form Factor y30.5cm x 23.0cmATX size form factor, 4 layers PCB

Motherboard yGA-8IG1000 Series Motherboard:

GA-8IG1000 Pro-G/ GA-8IG1000-G/ GA-8IG1000

CPU ySocket 478 for Intel®Micro FC-PGA2 Pentium®4 processor

ySupport Intel®Pentium®4 (Northwood, Prescott) processor

ySupport Intel®Pentium®4 Processor with HTTechnology

yIntel®Pentium®4 800/533/400MHz FSB

y2nd cache depends on CPU

Chipset yChipset Intel®865G HOST/AGP/Controller

yIntel®ICH5 I/O Controller Hub

Memory y4 184-pin DDR DIMM sockets

ySupports Dual channel DDR400/DDR333/DDR266 DIMM

ySupports 128MB/256MB/512MB/1GB unbuffered DRAM

ySupports up to 4GB DRAM (Max)(Note 1)

I/O Control yITE8712

Slots y1AGP slot supports 8X/4X mode

y5 PCI slot supports 33MHz & PCI 2.3 compliant

On-Board IDE y2 IDE bus master (UDMA33/ATA66/ATA100) IDE ports for

up to 4ATAPI devices

ySupports PIO mode3, 4 (UDMA33/ATA66/ATA100) IDE &

ATAPI CD-ROM

On-Board SerialATA yControlled by ICH5

y2 SerialATAconnectors in 150 MB/s operation mode

Chapter 1 Introduction

Features Summary

to be continued...

Due to chipset (Intel 875P/865G/865PE) architecture limitation, a FSB 800 Pentium 4 processor

will support DDR400/DDR333/DDR266 memory module. A FSB 533 Pentium 4 processor will

support DDR333 and DDR266 memory module.AFSB 400 Pentium 4 processor will only support

DDR 266 memory module.

(Note 1) Due to standard PC architecture, a certain amount of memory is reserved for system usage and

therefore the actual memory size is less than the stated amount. For example, 4 GB of memory size

will instead be shown as 3.xxGB memory during system startup.

- 6 -GA-8IG1000 Series Motherboard

English

to be continued...

(*)For GA-8IG1000 Pro-G only.

()For GA-8IG1000-G only.

On-Board Peripherals y1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M

and 2.88M bytes

y1 Parallel port supports Normal/EPP/ECP mode

y1 Serial port (COMA), 1 VGA port

y8 USB 2.0/1.1 ports (4 x Rear, 4 xFront by cable)

y1 FrontAudio connector

y3 IEEE1394 (by cable) (*)

y1 IrDA connector for IR/CIR

HardwareMonitor yCPU/Power(*)/System fan revolution detect

yCPU/Power(*)/System fan fail warning

yCPU overheat warning

ySystem voltage detect

On-Board Sound yRealtekALC850 UAJ CODEC

ySupport Jack-Sensing

yLine Out / 2 front speaker

yLine In / 2 rear speaker(by s/w switch)

yMic In / center & subwoofer(by s/w switch)

ySurround Back Speaker(by optional Surround-Kit)

ySPDIF Out / SPDIF In

yCD_In/ Game connector

On-Board LAN (*)yBuilt-in Marvell 8001 chipset

Data transfer rate 10/100/1000 supported

y1 RJ45 port

On-Board IEEE1394 (*)yTi TSB43AB23

PS/2 Connector yPS/2 Keyboard interface and PS/2 Mouse interface

BIOS yLicensedAWARD BIOS

ySupports Dual BIOS(*)/Q-Flash

ySupports Multi-Language(*)

ySupports Face Wizard(*)

Otros manuales para GA-8IG1000 Pro-G

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de Gigabyte

Gigabyte

Gigabyte Z590 D Manual de usuario

Gigabyte

Gigabyte GA-C847N-D Manual de usuario

Gigabyte

Gigabyte GA-B85-HD3-A Manual de usuario

Gigabyte

Gigabyte MZ72-HB0 Manual de usuario

Gigabyte

Gigabyte GA-Z87N-WIFI Manual de usuario

Gigabyte

Gigabyte GA-686BX Manual de usuario

Gigabyte

Gigabyte Z790 AORUS PRO X Manual de usuario

Gigabyte

Gigabyte GA-EP43T-USB3 Manual de usuario

Gigabyte

Gigabyte MW22-SE0 Manual de usuario

Gigabyte

Gigabyte GA-Q87M-D2H Manual de usuario

Gigabyte

Gigabyte GA-990FXA-UD3 Manual de usuario

Gigabyte

Gigabyte GA-AX370M-DS3H Manual de usuario

Gigabyte

Gigabyte GA-M52LT-D3P Manual de usuario

Gigabyte

Gigabyte GA-2AIEV-RH Manual de usuario

Gigabyte

Gigabyte GA-Q35M-S2 Manual de usuario

Gigabyte

Gigabyte 6CXC Manual de usuario

Gigabyte

Gigabyte GA-X99-Gaming G1 WIFI Manual de usuario

Gigabyte

Gigabyte GA-B250N Phoenix-WIFI Manual de usuario

Gigabyte

Gigabyte GA-H81N Manual de usuario

Gigabyte

Gigabyte GA-8GE667 Pro Manual de usuario

Gigabyte

Gigabyte GA-7VAXP-A Ultra Manual de usuario

Gigabyte

Gigabyte GA-P41T-D3P (rev. 1.3) Manual de usuario

Gigabyte

Gigabyte GA-H61TN Manual de usuario

Gigabyte

Gigabyte GA-H61M-S2P-B3 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
