Whenyou installing AGPcard,please make surethefollowing

notice isfullyunderstood and practiced.IfyourAGPcardhas

"AGP4X/8X(1.5V)notch"(showbelow),please make sureyour

AGPcardisAGP4X/8X(1.5V).

Caution:AGP2XcardisnotsupportedbyIntel®845(GE/PE)/845(E/

G)/850(E)/E7205 /865(G/PE/PL/P)/875P/848P.You might

experiencesystemunabletobootup normally.Please insertanAGP

4X/8Xcard.

Example1:Diamond VipperV770 golden fingeriscompatiblewith2X/4X

mode AGPslot. It can be switched between AGP2X(3.3V)or4X(1.5V)

mode byadjusting the jumper.The factorydefaultforthiscardis

2X(3.3V).The GA-8I865P(-G)(oranyAGP4X/8Xonly)motherboards

mightnotfunction properly,ifyou install thiscardwithoutswitching the

jumperto4X(1.5V)mode init.

Example2:SomeATiRage 128 Prographics cardsmade by"PowerColor",

the graphics cardmanufacturer&someSiS305 cards,theirgolden finger

iscompatiblewith2X(3.3V)/4X(1.5V)mode AGPslot, buttheysupport2X

(3.3V)only.The GA-8I865P(-G)(oranyAGP4X/8Xonly)motherboards

mightnotfunction properly,If you install thiscardinit.

Note:Although Gigabyte'sAG32S(G)graphics cardisbased on ATiRage

128 Prochip,the design ofAG32S(G)iscompliancewithAGP4X(1.5V)

specification.Therefore,AG32S(G)will workfine withIntel®845(GE/PE)/

845(E/G)/850(E)/E7205 /865(G/PE/PL/P)/875P/848Pbased

motherboards.

AGP4X/8Xnotch

MTheauthorassumes no responsibilityforanyerrors

oromissionsthatmay appearinthisdocumentnor

does theauthormake acommitmenttoupdatethe

information containedherein.

MThird-partybrandsand names arethepropertyof

theirrespective owners.

MPlease do notremove anylabelson motherboard,this

may voidthewarrantyofthismotherboard.

MDuetorapidchangeintechnology,someofthe

specificationsmightbeoutofdatebeforepublication

ofthisbooklet.

Jun.04,2004

MotherBoard

GA-8I865P-G/GA-8I865P

FCC Part15,SubpartB,Section 15.107(a)and Section 15.109

(a),Class BDigitalDevice

DECLARATIONOFCONFORMITY

PerFCC Part2Section 2.1077(a)

ResponsiblePartyName:

Address:

Phone/Fax No:

hereby declaresthattheproduct

ProductName:

Conformstothefollowing specifications:

Thisdevice complieswithpart15 oftheFCC Rules.Operation is

subjecttothefollowing twoconditions:(1)Thisdevice maynot

causeharmfuland(2)thisdevicemustacceptanyinferencereceived,

including thatmaycauseundesiredoperation.

RepresentativePerson’sName:

Signature:EricLu

SupplementaryInformation:

ModelNumber:

17358 RailroadStreet

CityofIndustry,CA 91748

G.B.T.INC.(U.S.A.)

(818)854-9338/(818)854-9339

Motherboard

GA-8I865P-G/GA-8I865P

Date:

ERICLU

Jun.04,2004

USER'SMANUAL

GA-8I865P(-G)

P4Titan SeriesMotherboard

Pentium®4ProcessorMotherboard

Rev.1001

12ME-8I865PG-1001

-2-GA-8I865P(-G)Motherboard

English

TableofContent

Warning ..............................................................................................4

Chapter1Introduction .........................................................................5

FeaturesSummary.......................................................................................... 5

GA-8I865P(-G)MotherboardLayout .............................................................. 7

Block Diagram.................................................................................................. 8

Chapter2HardwareInstallation Process ............................................ 11

Step 1:Install the CentralProcessing Unit(CPU)....................................... 12

Step 1-1:CPUInstallation ........................................................................................... 12

Step 1-2:CPUCooling Fan Installation ...................................................................... 13

Step 2:Install memorymodules................................................................... 14

Step 3:Install expansion cards..................................................................... 17

Step 4:Install I/OPeripheralsCables.......................................................... 18

Step 4-1:I/OBack PanelIntroduction .......................................................................... 18

Step 4-2:Connectors&JumperSetting Introduction .................................................... 20

Chapter3BIOSSetup ....................................................................... 31

The MainMenu (Forexample:BIOSVer.:E3)........................................... 32

StandardCMOSFeatures............................................................................. 34

Advanced BIOSFeatures.............................................................................. 37

Integrated Peripherals.................................................................................. 38

PowerManagementSetup ............................................................................ 42

TableofContent

English

-3-

PnP/PCIConfigurations................................................................................. 44

PCHealthStatus........................................................................................... 45

Frequency/Voltage Control............................................................................ 46

Load Fail-SafeDefaults................................................................................. 49

Load Optimized Defaults............................................................................... 49

SetSupervisor/UserPassword..................................................................... 50

Save&ExitSetup .......................................................................................... 51

ExitWithoutSaving ...................................................................................... 51

Chapter4TechnicalReference.......................................................... 53

FlashBIOSMethod Introduction ................................................................... 53

2-/4-/6-/8-ChannelAudioFunction Introduction .................................... 64

Jack-Sensing and UAJIntroduction ............................................................. 70

Xpress RecoveryIntroduction ....................................................................... 72

Chapter5Appendix.......................................................................... 75

-4-GA-8I865P(-G)Motherboard

English

Warning

Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To

protectthemagainstdamage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou

workon yourcomputer.

1.Unplug yourcomputerwhenworking onthe inside.

2.Useagrounded wriststrapbeforehandling computercomponents.Ifyou donothave

one,touchbothofyourhandstoasafelygrounded objectortoametalobject, suchas

the powersupplycase.

3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,or

othercomponents.

4.Placecomponentsonagrounded antistaticpadoron the bag thatcamewiththe

componentswheneverthe componentsareseparated fromthe system.

5.EnsurethattheATXpowersupplyisswitched offbeforeyou plug inorremovetheATX

powerconnectoron themotherboard.

Ifthe motherboardhasmountingholes,buttheydon'tline upwiththe holeson the baseand there

areno slotstoattachthe spacers,do notbecomealarmed you can still attachthe spacerstothe

mounting holes.Justcutthe bottomportion ofthe spacers(the spacermaybe alittlehardtocutoff, so

be carefulofyourhands).Inthiswayyou can still attachthe motherboardtothe basewithoutworrying

aboutshortcircuits.Sometimesyou mayneed tousethe plasticspringstoisolatethe screwfromthe

motherboardPCBsurface,becausethe circuitwiremaybe nearbythe hole.Becareful,don'tletthe

screwcontactanyprinted circuitwriteorpartson the PCBthatarenearthefixing hole,otherwiseitmay

damage the boardorcauseboardmalfunctioning.

Installing themotherboardtothechassis…

Introduction-5-

English

Chapter1Introduction

Features Summary

tobe continued......

CPU—Socket478 forIntel®Pentium®4(Northwood,Prescott)

withHTTechnology

—Intel®Pentium®4400/533/800(Note1)MHzFSB

—2nd cache dependson CPU

Chipset—NorthBridge:Intel®865P

—SouthBridge:Intel®ICH5

Memory—4184-pinDDR DIMM sockets

—SupportsDualchannelDDR400(Note2)/DDR333/DDR266 DIMM

—Supports128MB/256MB/512MB/1GBunbuffered DRAM

—Supportsup to4GBDRAM(Max)(Note3)

Slots—1AGPslotsupports8X/4X(1.5V)mode

—5PCIslots

On-BoardIDE—2IDEbusmaster(UDMA33/ATA66/ATA100)IDEportsforup

to4ATAPIdevices

—Can connectup to4IDEdevices

On-BoardFloppy—1Floppyportsupports2FDD with360K,720K,1.2M,1.44M

and 2.88Mbytes

On-BoardPeripherals—1ParallelportsupportsNormal/EPP/ECPmode

—2Serialports(COMA&COMB)

—8USB 2.0/1.1ports(4xRear,4xFrontbycable)

—1IrDAconnectorforIR/CIR

—1FrontAudioconnector

—1PS/2keyboard

—1PS/2mouse

Due tochipset(Intel865P)architecturelimitation,aFSB 533 Pentium4processorwill support

DDR333 and DDR266 memorymodule.AFSB 400 Pentium4processorwill onlysupportDDR

266memorymodule.

(Note1)AnFSB800 CPUcan be supported through overclocking inBIOS.

(Note2)When FSB800 isselected asCPUfrequency,memorywill automaticallyadjusttoDDR400.

(Note3)Due tostandardPCarchitecture,acertainamountofmemoryisreserved forsystem

usage and thereforethe actualmemorysizeisless than the stated amount.

Forexample,4GBofmemorysizewill instead be shownas3.xxGBmemoryduring

systemstartup.

-6-GA-8I865P(-G)Motherboard

English

On-BoardLAN(*)—BuildinMarvell 8001 Chipset(10/100/1000 Mbit)

—1RJ45 port

On-BoardSound —ALC850 CODEC(UAJ)

—SupportsJack Sensing function

—Supports2/4/6/8channelaudio

—SupportsLine In/Line Out/MICconnection

—Surround Back Speaker(useofSurround-Kittoselect)

—SPDIFIn/Out

—CD In/Gameconnector

SerialATA—2SerialATAconnectors(SATA0/SATA1)

—Controlled byICH5

HardwareMonitor—CPU/SystemFan Revolution detect

—CPU/SystemFan Fail Warning

—CPUOverheatWarning

—SystemVoltage Detect

I/OControl—IT8712

PS/2Connector—PS/2Keyboardinterfaceand PS/2Mouseinterface

BIOS—Licensed AWARD BIOS

—SupportsQ-Flash

AdditionalFeatures—SupportsEasyTune

—Supports@BIOS

Overclocking —OverVoltage (DDR/AGP/CPU)byBIOS

—OverClock (DDR/AGP/CPU/PCI)byBIOS

FormFactor—ATXsizeformfactor;30.5cmx23.0cm

(*)OnlyforGA-8I865P-G.
