Gigabyte GA-8ILFT Series Manual de usuario

USER’SMANUAL

GA-8ILFT Series

P4Titan-DDR Motherboard

Pentium®4ProcessorMotherboard

Rev.1001

12ME-8ILFT-1001

-2-GA-8ILFTSeriesMotherboard

English

TableofContent

ItemChecklist ..................................................................................4

WARNING! .......................................................................................4

Chapter1Introduction.......................................................................5

FeaturesSummary................................................................................................5

GA-8ILFTSeriesMotherboardLayout..............................................................7

Chapter2HardwareInstallation Process ............................................8

Step1:InstalltheCentralProcessingUnit(CPU)...........................................9

Step1-1CPUInstallation................................................................................9

Step1-2CPUHeatSinkInstallation................................................................ 10

Step2:Installmemorymodules.......................................................................11

Step3:Connectribboncables,cabinetwires,andpowersupply.............13

Step3-1I/OBackPanelIntroduction .............................................................. 13

Step3-2ConnectorsIntroduction ................................................................... 15

Chapter3BIOSSetup ....................................................................22

TheMainMenu(Forexample:BIOSVer.:F1)..............................................23

StandardCMOSFeatures.................................................................................25

AdvancedBIOSFeatures...................................................................................28

Integrated Peripherals.......................................................................................31

TableofContent

English

-3-

PowerManagementSetup................................................................................35

PnP/PCIConfigurations......................................................................................37

PCHealthStatus..................................................................................................38

Frequency/VoltageControl................................................................................40

LoadFail-SafeDefaults......................................................................................42

LoadOptimizedDefaults....................................................................................43

SetSupervisor/UserPassword..........................................................................44

Save&ExitSetup.................................................................................................45

ExitWithoutSaving.............................................................................................46

Chapter4TechnicalReference........................................................47

BlockDiagram.....................................................................................................47

Q-FlashIntroduction...........................................................................................48

@BIOSIntroduction ...........................................................................................50

EasyTune4TMIntroduction ...............................................................................51

Chapter5Appendix.......................................................................52

-4-GA-8ILFTSeriesMotherboard

English

þTheGA-8ILFTmotherboardþI/OShield

þIDEcablex1/Floppycablex1

þCD formotherboarddriver&utility(IUCD)

þGA-8ILFTuser’smanual

ItemChecklist

Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To

protectthemagainstdamage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou

workon yourcomputer.

1.Unplug yourcomputerwhen working on the inside.

2.Useagrounded wriststrap beforehandling computercomponents.Ifyou do nothave

one,touchbothofyourhandstoasafelygrounded objectortoametalobject, suchas

the powersupplycase.

3.Holdcomponentsbytheedgesand trynottouchthe ICchips,leadsorconnectors,or

othercomponents.

4.Placecomponentson agrounded antistaticpad oronthe bag thatcamewiththe

componentswheneverthe componentsareseparatedfromthe system.

5.EnsurethattheATXpowersupplyisswitchedoff beforeyou plug inorremovethe ATX

powerconnectoron the motherboard.

Ifthe motherboardhasmountingholes,buttheydon’tlineup withtheholesonthe baseandthereare

no slotstoattachthe spacers,do notbecomealarmed you can stillattachthe spacerstothemounting

holes.Justcutthe bottomportionofthespacers(thespacermaybe alittlehardtocutoff, sobe careful

ofyourhands).Inthiswayyou canstill attachthemotherboardtothebasewithoutworryingaboutshort

circuits.Sometimesyou mayneedtousetheplasticspringstoisolatethe screwfromthe motherboard

PCBsurface,becausethe circuitwiremaybenearbythehole.Becareful,don’tletthescrewcontact

anyprintedcircuitwriteorpartson thePCBthatarenearthe fixing hole,otherwiseitmaydamage the

boardorcauseboardmalfunctioning.

Installing themotherboardtothechassis…

WARNING!

Introduction

English

-5-

FormFactor—20.3cmx2.9cmFlexATXsizeformfactor,4layersPCB.

Motherboard—GA-8ILFTSeriesMotherboard:

GA-8ILFTand GA-8ILFT-C

CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor

—SupportIntel®Pentium®4(Northwood,0.13 m)processor

—IntelPentium®4400MHzFSB

—2nd cache dependson CPU

Chipset—Chipset82845GLHOST/AGP/Controller

—ICH4I/OControllerHub

Memory—2184-pinDDR DIMM sockets

—SupportsPC1600 DDR orPC2100 DDR SDRAM

—Supportsup to2GBDRAM(Max)

—Supportsonly2.5VDDR SDRAM

I/OControl—ITE8712

Slots—3PCIslotsupports33MHz&PCI2.2compliant

On-BoardIDE—AnIDEcontrolleronthe IntelICH4PCIchipset

providesIDEHDD/CD-ROMwithPIO,BusMaster(Ultra

DMA33/ATA66/ATA100)operation modes.

—Can connectuptofourIDEdevices

On-BoardPeripherals—1Floppyportsupports2FDD with360K,720K,1.2M,1.44M

and 2.88Mbytes.

—1ParallelportsupportsNormal/EPP/ECPmode

—1Serialports(COMA),1VGAport

—4xUSB 2.0/1.1(2xRear,2Frontbycable)

—1FrontAudioconnector

—1SerialIRQconnector

On-BoardVGA—BuiltinIntel845GLChipset

On-BoardSound —AC97 CODEC(RealTekALC201A)

—1Buzzer

—Line In/Line Out/MicIn/CD In/AUXIn/GamePort/SPDIF

Chapter1Introduction

tobe continued......

Features Summary

-6-GA-8ILFTSeriesMotherboard

English

PleasesettheCPUhostfrequencyinaccordancewithyourprocessor’sspecifications.

Wedon’trecommend youtosetthesystembusfrequencyovertheCPU’sspecification

becausethesespecificbusfrequenciesarenotthe standardspecificationsforCPU,

chipsetand mostofthe peripherals.Whetheryoursystemcan run underthesespecific

busfrequenciesproperlywill depend on yourhardwareconfigurations,including CPU,

Chipsets,SDRAM,Cards….etc.

On-BoardLAN*—BuilitinRTL8100BLChipset

—1RJ45 port

HardwareMonitor—CPU/SystemFan Revolution detect

—CPU/SystemFan Control

—CPUOverheatWarning

—SystemVoltageDetect

PS/2Connector—PS/2Keyboardinterfaceand PS/2Mouseinterace

BIOS—Licensed AWARD BIOS,2MbitFWH

AdditionalFeatures—ExternalModemwakeup

—PS/2Keyboardpasswordpoweron

—PS/2Mousepoweron

—ACRecovery

—USB KB/Mousewakeup fromS3

—Polyfuseforkeyboard,USB,gameportover-currentprotection

—Supports@BIOS

—SupportsEasyTune4

*ForGA-8ILFT Only.

Introduction

English

-7-

RTL8100BL*

AUX_IN

BIOS_WP

S_IRG

*ForGA-8ILFT Only.

GA-8ILFT Series MotherboardLayout

SPDIF

GA-8ILFT

KB_MS

COMA

LPT

GAME

LINE_IN

LINE_OUTMIC_IN

USB/

LAN*

ATX_12V

CD_IN F_AUDIO

F_PANEL

BAT1

SYS _FAN

ICH4

Intel845GL

SOCKET478

CPU_FAN

ATX_POWER

FDD

IDE1

IDE2

PCI1

PCI2

PCI3

DDR2

DDR1

AC97

ITE8712

BIOS

Buzzer

F_USB1

CLR_COMS

VGA

-8-GA-8ILFTSeriesMotherboard

English

Tosetup yourcomputer,you mustcompletethefollowing steps:

Step 1-Install theCentralProcessingUnit(CPU)

Step2-Installmemorymodules

Step 3-Connectribbon cables,cabinetwires,and powersupply

Step4-SetupBIOSsoftware

Step5-Installsupporting softwaretools

Chapter2HardwareInstallation Process

Step2

Step4

Step3

Step4

Step1

-9-HardwareInstallationProcess

English

Step1:Install theCentralProcessing Unit(CPU)

Step1-1:CPUInstallation

Pin1indicatorPin1indicator

CPUTop View CPUBottomView

SocketActuation Lever

1.Pull up the CPUsocketlever

and upto90-degree angle.

Pin1indicator

2.LocatePin1inthe socketand look

fora(golden)cutedge on the CPU

uppercorner.Theninsertthe CPU

intothesocket.

3.Press downthe CPUsocket

leverand finishCPUinstallation.

Please make suretheCPUtypeissupportedbythemotherboard.

Ifyou do notmatchtheCPUsocketPin1and CPUcutedgewell, itwill cause

improperinstallation.Please changetheinsertorientation.

-10 -GA-8ILFTSeriesMotherboard

English

Step1-2:CPUHeatSinkInstallation

1.Hookone endofthe cooler

brackettothe CPUsocketfirst. 2.Hooktheotherendofthe

coolerbrackettothe CPU

socket.

Please use Intelapprovedcooling fan.

Werecommend you toapplythethermaltapetoprovidebetterheat

conduction betweenyourCPUand heatsink.

(TheCPUcooling fanmightstick totheCPUduetothehardening ofthe

thermalpaste.During thiscondition ifyou trytoremove thecooling fan,you

mightpulltheprocessoroutoftheCPUsocketalonewiththecooling fan,and

mightdamagetheprocessor.To avoidthisfromhappening,wesuggestyou to

eitherusethermaltapeinsteadofthermalpaste,orremove thecoolingfanwith

extremecaution.)

Make suretheCPUfanpowercableispluggedintotheCPUfanconnector,

thiscompletes theinstallation.

Please refertoCPUheatsinkuser’smanualformoredetail installation

procedure.
