Gigabyte 6VMA Manual de usuario

Table Of Contents

TABLE OF CONTENTS

1. INTRODUCTION

1.1. PREFACE..........................................................................................................1-1

1.2. KEY FEATURES...............................................................................................1-1

1.3. PERFORMANCE LIST......................................................................................1-2

1.4. BLOCK DIAGRAM.............................................................................................1-3

1.5. INTRODUCE THE PentiumII / III Processor .................................................1-4

1.6. What is AGP?....................................................................................................1-6

2. SPECIFICATION

2.1. HARDWARE .....................................................................................................2-1

2.2. SOFTWARE......................................................................................................2-2

2.3. ENVIRONMENT................................................................................................2-2

3. HARDWARE INSTALLATION

3.1. UNPACKING.....................................................................................................3-1

3.2. MAINBOARD LAYOUT.....................................................................................3-2

3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS..............................3-1

3.4. DRAM INSTALLATION.....................................................................................3-7

3.5. CPU SPEED SETUP.........................................................................................3-7

3.6. CMOS RTC & ISA CFG CMOS SRAM.............................................................3-9

3.7. SPEAKER CONNECTOR INSTALLATION......................................................3-9

3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION....................3-9

3.9. POWER LED CONNECTOR INSTALLATION.................................................3-9

3.10. IDE & ATAPI DEVICE INSTALLATION..........................................................3-9

3.11. PERIPHERAL DEVICE INSTALLATION........................................................3-9

3.12. KEYBOARD & PS/2 MOUSE INSTALLATION...............................................3-10

4. BIOS CONFIGURATION

6VMA

4.1. ENTERING SETUP...........................................................................................4-1

4.2. CONTROL KEYS ..............................................................................................4-1

4.3. GETTING HELP................................................................................................4-2

4.3.1. Main Menu.............................................................................................4-2

4.3.2. Status Page Setup Menu / Option Page Setup Menu............................4-2

4.4. THE MAIN MENU..............................................................................................4-2

4.5. STANDARD CMOS SETUP MENU..................................................................4-4

4.6. BIOS FEATURES SETUP ................................................................................4-8

4.7. CHIPSET FEATURES SETUP.........................................................................4-12

4.8. POWER MANAGEMENT SETUP....................................................................4-17

4.9. PNP/PCI CONFIGURATION ............................................................................4-21

4.10. LOAD BIOS DEFAULTS.................................................................................4-22

4.11. LOAD PERFORMANCE DEFAULTS .............................................................4-23

4.12. INTEGRATED PERIPHERALS.......................................................................4-24

4.13. SUPERVISOR/USER PASSWORD...............................................................4-29

4.14. IDE HDD AUTO DETECTION........................................................................4-30

4.15. SAVE & EXIT SETUP .....................................................................................4-31

4.16. EXIT WITHOUT SAVING ...............................................................................4-32

APPENDIX A: VIA Chipset Driver Installation

A.1. VIA Patch 95/98 Driver Ver.1.1(Win95/98 ONLY).............................................A-2

A.2. VIA AGP Driver Ver.2.9(Win95/98 ONLY)........................................................A-5

A.3. VIA PCI Routing Mimiport Driver Ver.1.3(Win98 ONLY)...................................A-8

A.4. Bus Master IDE Driver ......................................................................................A-10

APPENDIX B: Audio Driver Driver Installation

B.1. ESS Solo-1 PCI sound driver installation...........................................................B-1

APPENDIX C: Bugs & Limitations…………………………………………….C-1

Introduction

1-1

1. INTRODUCTION

1.1. PREFACE

Welcome to use the 6VMA motherboard. It is a PentiumII / III / Celeron

Processor based PC / AT compatible system with AGP/ PCI / ISA Bus, and

has been designed to be the fastest PC / AT system. There are some new

features allow you to operate the system with just the performance you want.

This manual also explains how to install the motherboard for operation, and

how to set up your CMOS CONFIGURATION with BIOS SETUP program.

1.2. KEY FEATURES

qIntel PentiumII / III / CeleronProcessor based PC / AT compatible

mainboard.

qSlot 1 supports PentiumII / III / Celeronprocessor running at 233-633

MHz.

qVIA Apollo Pro-Plus chipset, Supports AGP / SDRAM / Ultra DMA33 IDE /

Keyboard and PS/2 Mouse Power On / ACPI features.

qBuilt-in PCI ESS SOLO-1 audio chip.

qSupports external Modem Ring-On on COMA & COMB and internal

Modem Ring-On.

qSupports Wake-up on LAN (JP7).

qSupports 3xDIMMs using 3.3V SDRAM DIMM module.

qSupports 16MB - 768MB SDRAM memory on board.

q3xPCI Bus slots, 1xISA Bus slots, 1xAGP slot.

qSupports 2 channels Ultra DMA/33 IDE ports for 4 IDE Devices.

qSupports 2xCOM (16550), 1xLPT (EPP / ECP), 1x Floppy port.

qSupports1x Line in, 1x Line Out, 1x Micro in, 2x CD Line in,1x GAME Port,

1x TEL Port.

qSupports 2xUSB ports, 1xPS/2 Mouse, 1xPS/2 Keyboard.

qLicensed AWARD BIOS, 2Mbits FLASH RAM.

6VMA

1-2

q24.5 cm x 20 cm Micro-ATX form factor, 4 layers PCB.

1.3. PERFORMANCE LIST

The following performance data list is the testing results of some popular

benchmark testing programs.

These data are just referred by users, and there is no responsibility for different

testing data values gotten by users. (The different Hardware & Software

configuration will result in different benchmark testing results.)

•CPU PentiumII processor

•DRAM (128 x 1) MB SDRAM (TOSHIBA TC59S6408FTL-80H)

•CACHE SIZE 512 KB included in CPU

•DISPLAY GA-630 AGP Voodoo banshee(16MB SGRAM)

•STORAGE Onboard IDE (IBM DHEA-36481)

•O.S. Windows NT™4.0

•DRIVER Display Driver at 1024 x 768 x 64k colors x 75Hz.

VIA Bus Master IDE Driver 2.3.12

Intel PentiumII

Processor 350MHz(100x3.5) 450MHz(100x4.5)

Winbench99

CPU mark32 881 1110

FPU Winmark 1800 2300

Business Disk 3910 4220

Hi-End Disk 8530 8380

Business Graphics 161 194

Hi-End Graphics 281 354

Winstone99

Business 27.2 31

Introduction

1-3

3.3V EDO/SDRAM

DIMM Sockets

Floppy Port

Hi-End 23.2 27.2

1.4. BLOCK DIAGRAM

PS/2 Keyboard

24MHz

33MHz

100MHz

Ultra DMA/33

IDE Ports

IDE Bus

PCI Bus

ISA Bus

AGP Bus

LPT Port

COM Ports

DRAM Bus

PS/2 Mouse

USB Bus

USB Ports

14.318MHz

48MHz

14.318MHz

I/O

CHIPSET

Winbond

83977EF

Host Bus

VIA

82C693

CHIPSET

VIA

82C596A

CHIPSET

Clock

Generator

MIC

L-IN

L-OUT SOLO1

24.576MHz

14.318MHz

66MHz

Game

Port

100MHz

AGP SLOT

SLOT 1

6VMA

1-4

1.5. INTRODUCE THE Pentium



II / III Processor

Figure 1:Universal Retention Mechanism & attach Mount

Figure 2:OEM PentiumII Processor

Introduction

1-5

Figure 3: OEM PentiumIII Processor

6VMA

1-6

1.6 What is AGP

The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge

device that supports an AGP port. The main purpose of the AGP port is to

provide fast access to system memory.

The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits

at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and

side band addressing. When the 2x-data rate is used, the port can transmit

data at 533MB/sec (66.6*2*4). The read-queue can be used to pipeline reads –

removing the effects of the reads-latency. Side band addressing can be used to

transmit the data address on a separate line in order to speed up the

transaction.

Specification

2-1

2. SPECIFICATION

2.1. HARDWARE

•CPU −PentiumII/ III/ Celeronprocessor 233 –633 MHz.

−242 pins 66/100 MHz slot1 on board.

•SPEED −66/100 MHz system speed.

−66 MHz AGP bus speed. (2X mode 133MHz)

−33 MHz PCI-Bus speed.

−8 MHz AT bus speed.

•DRAM MEMORY −3 banks 168 pins DIMM module sockets on board.

−Use 16 / 32 / 64 / 128 / 256 MB DIMM module DRAM.

−16 MB~ 768MB SDRAM.

−Supports 3.3V SDRAM.

•CACHE MEMORY −32 KB 1st cache memory included in CPU.

−128KB / 512 KB 2nd cache in CPU.

−Supports DIB speed mode for L2 Cache.

•I/O BUS SLOTS −3 33MHz Master / Slave PCI-BUS.

−1 8MHz 16 bits ISA BUS.

−1 66MHz / 133MHz AGP bus.

•IDE PORTS −2 Ultra DMA 33 Bus Master IDE channels on

board.(Using IRQ14,15)

−Support Mode 3,4 IDE & ATAPI CD –ROM.

•I/O PORTS −Supports 2 16550 COM ports.

−Supports 1 LPT port.

−Supports 1 Floppy port.

−Supports 2 USB ports.

−Supports 1 PS/2 Mouse.

−Supports 1 PS/2 Keyboard.

6VMA

2-2

•Audio Ports −1x Line in

−1x Line out

−1x Micro in

−1x Game Port

−2x CD Line in

−1x TEL Port

•GREEN FUNCTION −Suspend mode support.

−Green switch & Green LED support.

−IDE & Display power down support.

−Monitor all IRQ / DMA / Display / I/O events.

•BIOS −2M bits FLASH RAM.

−Supports Plug & Play, DMI Function.

•DIMENSION −Micro ATX Form Factor, 4 layers PCB.

2.2. SOFTWARE

•DRIVER −UUCD

Bus Master IDE Driver

•BIOS −Licensed AWARD BIOS.

−AT CMOS Setup, BIOS / Chipset Setup, Green

Setup, Hard Disk Utility included.

•O.S. −Operation with MS-DOS, Windows95,

Windows98, WINDOWSNT, OS/2, NOVELL

and SCO UNIX.

2.3. ENVIRONMENT

•Ambient Temp. −0°C to +50°C (Operating).

•Relative Hum. −0 to +85% (Operating).

•Altitude −0 to 10,000 feet (Operating).

•Vibration −0 to 1,000 Hz.

•Electricity −4.9 V to 5.2 V. (Max. 20A current at 5V.)
