Gigabyte GA-G31M-ES2L Manual de usuario

GA-G31M-ES2L

GA-G31M-ES2C

LGA775 socket motherboard for Intel® Core™processor family/

Intel® Pentium™processor family/Intel® Celeron™ processor family

User's Manual

Rev. 2401

12ME-G31MES2L-2401R

Motherboard

GA-G31M-ES2L

GA-G31M-ES2C

May 20, 2010

Motherboard

GA-G31M-ES2L/GA-G31M-ES2C

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specifications and features in this manual may be made by GIGABYTE

without prior notice. No part of this manual may be reproduced, copied, translated, transmitted,

or published in any form or by any means without GIGABYTE's prior written permission.

Documentation Classications

In order to assist in the use of this product, GIGABYTE provides the following types of documentations:

For detailed product information, carefully read the User's Manual.

For instructions on how to use GIGABYTE's unique features, read or download the information

on/from the Support&Downloads\Motherboard\Technology Guide page on our website.

For product-related information, check on our website at:

http://www.gigabyte.com

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 4 -

Table of Contents

GA-G31M-ES2L/GA-G31M-ES2C Motherboard Layout.................................................5

Chapter 1 Hardware Installation .....................................................................................6

1-1 Installation Precautions ................................................................................... 6

1-2 ProductSpecications..................................................................................... 7

1-3 Installing the CPU and CPU Cooler................................................................. 9

1-3-1 Installing the CPU ....................................................................................................9

1-4 Installing the Memory .................................................................................... 10

1-4-1 DualChannelMemoryConguration....................................................................10

1-5 Installing an Expansion Card......................................................................... 10

1-6 Back Panel Connectors ..................................................................................11

1-7 Internal Connectors ....................................................................................... 13

Chapter 2 BIOS Setup ..................................................................................................22

2-1 Startup Screen............................................................................................... 22

2-2 The Main Menu.............................................................................................. 22

2-3 Standard CMOS Features ............................................................................. 23

2-4 Advanced BIOS Features.............................................................................. 24

2-5 Integrated Peripherals ................................................................................... 26

2-6 Power Management Setup ............................................................................ 28

2-7 PnP/PCICongurations................................................................................. 30

2-8 PC Health Status ........................................................................................... 30

2-9 MB Intelligent Tweaker(M.I.T.) ....................................................................... 31

2-10 Load Fail-Safe Defaults ................................................................................. 33

2-11 Load Optimized Defaults ............................................................................... 33

2-12 Set Supervisor/User Password ..................................................................... 34

2-13 Save & Exit Setup.......................................................................................... 34

2-14 Exit Without Saving........................................................................................ 35

Chapter 3 Drivers Installation .......................................................................................35

3-1 Installing Chipset Drivers............................................................................... 35

Regulatory Statements..................................................................................................36

- 5 -

GA-G31M-ES2L/GA-G31M-ES2C Motherboard Layout

KB_MS CPU_FAN

LGA775

ATX

GA-G31M-ES2L/GA-G31M-ES2C

CD_IN

F_AUDIO

AUDIO

B_BIOS

PCIE_1

DDRII2

DDRII1

BAT

F_PANEL

ATX_12V

Intel®G31

Intel®ICH7

SATAII1

SATAII3

SATAII0

SATAII2

PCI1

CODEC

IDE

CLR_CMOS

M_BIOS

COMA

VGA

USB

PCIE_16

SPDIF_O

F_USB1

F_USB2

SYS_FAN

FDD

AR8131j

AR8132k

iTE

IT8718

R_USB

LAN

PWR_LED

PCI2

Box Contents

GA-G31M-ES2L or GA-G31M-ES2C motherboard

Motherboard driver disk User's Manual

One IDE cable Two SATA cables

I/O Shield

The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

jOnly for GA-G31M-ES2L.

kOnly for GA-G31M-ES2C.

Hardware Installation - 6 -

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

• Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

• When connecting hardware components to the internal connectors on the motherboard,

make sure they are connected tightly and securely.

• When handling the motherboard, avoid touching any metal leads or connectors.

• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic com-

ponents such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,

keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.

•

Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

• Before unplugging the power supply cable from the motherboard, make sure the power sup-

ply has been turned off.

• Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

• Before using the product, please verify that all cables and power connectors of your hard-

ware components are connected.

• To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

• Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

• Do not place the computer system on an uneven surface

• Do not place the computer system in a high-temperature environment.

• Turning on the computer power during the installation process can lead to damage to sys-

tem components as well as physical harm to the user.

• If you are uncertain about any installation steps or have a problem related to the use of the

product,pleaseconsultacertiedcomputertechnician.

Chapter 1 Hardware Installation

- 7 - Hardware Installation

1-2 Product Specications

jOnly for GA-G31M-ES2L.

kOnly for GA-G31M-ES2C.

CPU wSupport for an Intel® Core™2 Extreme processor/Intel® Core™2 Quad processor/

Intel

® Core™2 Duo processor/Intel® Pentium® processor/Intel® Celeron® processor

in the LGA 775 package

(Go to GIGABYTE's website for the latest CPU support list.)

wL2 cache varies with CPU

Front Side Bus w1333/1066/800 MHz FSB

Chipset w

North Bridge: Intel® G31 Express Chipset

w

South Bridge: Intel®ICH7

Memory w2 x 1.8V DDR2 DIMM sockets supporting up to 4 GB of system memory (Note 1)

wDual channel memory architecture

wSupport for DDR2 800/667 MHz memory modules

(Go to GIGABYTE's website for the latest supported memory speeds and

memory modules.)

Onboard Graphics wIntegrated in the North Bridge:

- 1 x D-Sub port

Audio   w Realtek ALC883/888B codec

w HighDenitionAudio

w 2/4/5.1/7.1-channel (Note 2)

    w Support for S/PDIF Out

w

Support for CD In

LAN wAR8131 chip (10/100/1000 Mbit)j

wAR8132 chip (10/100 Mbit)k

Expansion Slots w1 x PCI Express x16 slot

w1 x PCI Express x1 slot

w2 x PCI slots

Storage Interface wSouth Bridge:

- 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices

- 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices

wiTE IT8718 chip:

      - 1xoppydiskdriveconnectorsupportingupto1oppydiskdrive

USB wSouth Bridge:

- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets

connected to the internal USB headers)

Internal w1 x 24-pin ATX main power connector

Connectors w1 x 4-pin ATX 12V power connector

w 1xoppydiskdriveconnector

w1 x IDE connector

w4 x SATA 3Gb/s connectors

w1 x CPU fan header

w1 x system fan header

Hardware Installation - 8 -

Internal w1 x front panel header

Connectors w1 x front panel audio header

w1 x CD In connector

w1 x S/PDIF Out header

w2 x USB 2.0/1.1 headers

w1 x power LED header

w1 x chassis intrusion header

Back Panel w1 x PS/2 keyboard port

Connectors w1 x PS/2 mouse port

w

1 x parallel port

w1 x serial port

w1 x D-Sub port

w4 x USB 2.0/1.1 ports

w1 x RJ-45 port

w3 x audio jacks (Line In/Line Out/Microphone)

I/O wiTE IT8718

Hardware Monitor wSystem voltage detection

wCPU temperature detection

wCPU/System fan speed detection

wCPU overheating warning

wCPU/System fan fail warning

wCPU fan speed control (Note 3)

BIOS w 2x4Mbitash

wUse of licensed AWARD BIOS

wSupport for DualBIOS™

wPnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features wSupport for @BIOS

wSupport for Q-Flash

wSupport for Xpress BIOS Rescue

wSupport for Download Center

wSupport for Xpress Install

wSupport for Xpress Recovery2

wSupport for EasyTune(Note 4)

wSupport for Easy Energy Saver (Note 5)

wSupport for Time Repair

w Support for ON/OFF Charge

wSupport for Q-Share

Bundled Software wNorton Internet Security (OEM version)

Operating System wSupport for Microsoft®Windows®7/Vista/XP

Form Factor wMicro ATX form factor; 24.4cm x 19.4cm

- 9 - Hardware Installation

(Note 1) Based on standard PC architecture, a certain amount of memory is reserved for system usage and

therefore the actual memory size is less than the stated amount. For example, 4 GB of memory size

will instead be shown as 3.xx GB during system startup.

(Note2) Tocongure7.1-channelaudio,youneedconnectwiththeportofHDAudiostandardviafront

panel and enable the multi-channel audio feature through the audio driver.

(Note 3) Whether the CPU fan speed control function is supported will depend on the CPU you install.

(Note 4) Available functions in EasyTune may differ by motherboard model.

(Note 5) Due to the hardware limitation, you must install the Intel® Core™2 Extreme/Core™2 Quad/

Core™2 Duo/Pentium Dual-Core/Celeron Dual-Core/Celeron 400 Series CPU to enable support for

Easy Energy Saver

1-3 Installing the CPU and CPU Cooler

Read the following guidelines before you begin to install the CPU:

• Make sure that the motherboard supports the CPU.

(Go to GIGABYTE's website for the latest CPU support list.)

• Always turn off the computer and unplug the power cord from the power outlet before installing

the CPU to prevent hardware damage.

• Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may

locate the notches on both sides of the CPU and alignment keys on the CPU socket.)

• Apply an even and thin layer of thermal grease on the surface of the CPU.

• Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and dam-

age of the CPU may occur.

• SettheCPUhostfrequencyinaccordancewiththeCPUspecications.Itisnotrecommended

thatthesystembusfrequencybesetbeyondhardwarespecicationssinceitdoesnotmeetthe

standard requirements for the peripherals. If you wish to set the frequency beyond the standard

specications,pleasedosoaccordingtoyourhardwarespecicationsincludingtheCPU,graph-

ics card, memory, hard drive, etc.

1-3-1 Installing the CPU

A. Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.

Notch Notch

Alignment Key

LGA775 CPU

LGA775 CPU Socket

Pin One Corner of the CPU Socket

Triangle Pin One Marking on the CPU

Hardware Installation - 10 -

1-4 Installing the Memory

Read the following guidelines before you begin to install the memory:

•Make sure that the motherboard supports the memory. It is recommended that memory of the

same capacity, brand, speed, and chips be used.

(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)

•Always turn off the computer and unplug the power cord from the power outlet before installing

the memory to prevent hardware damage.

•Memory modules have a foolproof design. A memory module can be installed in only one direc-

tion. If you are unable to insert the memory, switch the direction.

1-4-1 Dual Channel Memory Conguration

This motherboard provides two DDR2 memory sockets and supports Dual Channel Technology.

The two DDR2 memory sockets are divided into two channels and each channel has one memory socket as

following:

Channel 0: DDRII1

Channel 1: DDRII2

DDRII1

DDRII2

Due to chipset limitation, read the following guidelines before installing the memory in Dual Channel mode.

1. Dual Channel mode cannot be enabled if only one DDR2 memory module is installed.

2. When enabling Dual Channel mode with two memory modules, it is recommended that memory of

the same capacity, brand, speed, and chips be used.

1-5 Installing an Expansion Card

Read the following guidelines before you begin to install an expansion card:

•Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

•Always turn off the computer and unplug the power cord from the power outlet before installing

an expansion card to prevent hardware damage.

Otros manuales para GA-G31M-ES2L

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de Gigabyte

Gigabyte

Gigabyte GA-F2A85X-UP4 Manual de usuario

Gigabyte

Gigabyte Z790 AERO G Manual de usuario

Gigabyte

Gigabyte GA-G41MT-S2 Manual de usuario

Gigabyte

Gigabyte GA-K8N51PVMT-9-RH Manual de usuario

Gigabyte

Gigabyte MA10-ST Series Manual de usuario

Gigabyte

Gigabyte GA-Z68X-UD4-B3 Manual de usuario

Gigabyte

Gigabyte GA-H77N-WIFI Manual de usuario

Gigabyte

Gigabyte GA-C621-WD12 Manual de usuario

Gigabyte

Gigabyte GA-B75TN Manual de usuario

Gigabyte

Gigabyte GA-H97-DS3H Manual de usuario

Gigabyte

Gigabyte GA-B85M-DS3H Manual de usuario

Gigabyte

Gigabyte GA-8IPE1000 Pro-G Manual de usuario

Gigabyte

Gigabyte GA-C7V7-RH Manual de usuario

Gigabyte

Gigabyte MUQ77EI Manual de usuario

Gigabyte

Gigabyte GA-6VXD7 Manual de usuario

Gigabyte

Gigabyte GA-Z68XP-UD3-iSSD Manual de usuario

Gigabyte

Gigabyte K8S760M Series Manual de usuario

Gigabyte

Gigabyte GA-F2A55-DS3 Manual de usuario

Gigabyte

Gigabyte GA-K8N51GMF-9-RH Manual de usuario

Gigabyte

Gigabyte MCH37AM Manual de usuario

Gigabyte

Gigabyte GA-P67A-UD3P Manual de usuario

Gigabyte

Gigabyte GA-X58A-OC Manual de usuario

Gigabyte

Gigabyte GA-6OMM7 Manual de usuario

Gigabyte

Gigabyte GA-M68MT-D3P Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
