Gigabyte U2440 Manual de usuario

English

Congratulations on your purchase of the GIGABYTE Notebook.

This manual will help you to get started with setting up your notebook. The nal product

conguration depends on the model at the point of your purchase. GIGABYTE reserves

the right to amend without prior notice. For more detailed information, please visit our

website at www.gigabyte.com

Using GIGABYTE Notebook for the First Time

1Connect the power cord to the AC adapter.

2Connect the AC adapter to the DC-in jack on the right side of the notebook.

3Connect the power cord to the power outlet.

Switching on the Power

After you turn on the U2440 for the very first time, do not turn it off until the

operating system has been configured. Please note that the volume for the

audio will not function until Windows® Setup has completed.

Booting Up the U2440 for the First Time

Depending on your conguration, the Microsoft® Windows® Boot Screen will be

the rst screen that you will see as the notebook starts up. Follow the on-screen

prompts and instructions and enter your personal information to complete the

setup of the Windows®Operating System.

English

2Your GIGABYTE Notebook Tour

Top View

Left View

1 2

7 6

2 3 4 51

1Webcam 

2Microphone

3Display panel

4Audio Speakers

5Keyboard

6Touchpad and buttons

7Status indicators 

8Power Switch

9Flash Memory Card Reader

Webcam on or off indicator

Battery charge Indicator

Drive Activity Indicator

Wireless Indicator

Capital Lock Indicator

1power DC input

2LAN Port

3Display (Monitor) output

4HDMI Port

5USB 3.0 Port

English

Base View

Right View

1Headphone output Jack

2Microphone input Jack

3USB Ports(2.0)X 2

4Optical Drive

5Kensington Lock Port

1HDD & Memory

Compartment

2 4 531

English

The computer employs hotkeys or key combinations to access most of the

computer’s controls like screen brightness and volume output. To activate

hotkeys, press and hold the <Fn> key before pressing the other key in the

hotkey combination.

Hotkey Function Description

Fn+F1 Zz Icon Places the Notebook in suspend mode.

Fn+F2 Wireless LAN/BT Enables/disables the Wireless LAN/BT

function.

Fn+F4 Lightning Toggles the Notebook between various

power management modes.

Fn+F5 Dim Sun Decreases the display brightness

Fn+F6 Bright Sun Increases the display brightness

Fn+F7 LCD on & off Toggles the Display Panel On and off

Fn+F8 LCD /Monitor Toggles between the Notebook LCD display

and an external monitor in this series.

Fn+F9 Crossed-out

Touchpad

Toggles the Built-in touchpad LOCKED and

UNLOCK.

Fn+F10 Speaker Toggles the speakers on & off

(only in Windows OS)

Fn+F11 Speaker Down Decrease the speaker volume

Fn+F12 Speaker Up Increase the speaker volume

Pressing the hot keys to adjust BIOS setup, system recovery and boot option

menu.

Hotkey Function Description

ESC BIOS setup Enter BIOS setup

F9 system recovery Enter system recovery

F11 boot option Enter boot option menu

Hotkeys

System Setup

English

Recovery Guide

System Recovery (Restore your laptop operating system)

When something is going wrong with the laptop operating system, the storage of the

laptop has a hidden partition containing a full back up image of the operating system that

can be used to restore the system to factory default settings.

Caution



Once the “Recovery” is selected, your

personal data and les will be deleted after

the laptop starts restoring, and the operating

system will be reset to factory default

settings.

The recovery will be activated and you will see

the option buttons on the window. Click on

“Recovery” to start it.

All ready to go

Make sure your PC is plugged in. This will take a few minutes.

A progress indicator bar will show on the

window when the recovery process is running.

Please make sure the AC-adapter is plugged in

and do not turn off the laptop.

Note

˙If the storage has been switched or the partition deleted, the recovery option will no

longer be available and a recovery service will be needed.

˙The recovery function is only available on devices with O/S preinstalled. Devices with

DOS do not have the recovery function.

Launch System Recovery

The system recovery feature is preinstalled before the laptop is shipped from the

factory. The option menu allows you to launch the Windows recovery tool to reinstall the

operating system to factory default.

The brief introduction below will show you how to start the recovery tool and restore your

system.

Windows 7 Recovery Guide

Turn off and restart the laptop.

During the laptop turn on process, press and

hold F9 key to launch the tool.

English

Reboot the laptop after the system recovery is

complete.

Windows 8 Recovery Guide

Choose your keyboard layout.

You can press “See more keyboard layouts” to

see next page of languages.

There are two options for system recovery

˙Refresh your PC

You can refresh your laptop to improve the system stability without

losing your les.

˙Reset your PC

If you want to remove all of your files, you can reset your PC

completely.

Caution: All personal data and les will be lost.

During the laptop turn on process, press and

hold F9 key to launch the tool.

Turn off and restart the laptop.

Choose “Troubleshoot” to enter the recovery settings.

(Also you can choose “Continue” to exit recovery system and continue

to Windows 8 for les or data backup.)

English

Appendix

■ Warranty & Service:

Warranty and service and related information please refer to the warranty card

or GIGABYTE service website as the below link:

http://www.gigabyte.com/support-downloads/technical-support.aspx

■ FAQ:

FAQ (Frequent Asked Questions) please refer to the below link:

http://www.gigabyte.com/support-downloads/faq.aspx
