EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate this equipment
and before connecting the power supply.
Please keep the following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of re, electrical shock and
injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any openings or empty slots
in the unit, as you may damage parts inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any weight to be placed
upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or openings in the unit
housing that provide ventilation and allow for sufcient space for air to circulate around
the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 14/09/15 Preliminary Release
EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
CONTENTS
1. Introduction......................................................................................1
2. Applications .....................................................................................1
3. Package Contents............................................................................1
4. System Requirements.....................................................................1
5. Features............................................................................................2
6. Operation Controls and Functions ................................................3
6.1 Front Panel...................................................................................3
6.2 Rear Panel....................................................................................5
6.3 OSD Menu....................................................................................6
6.4 Remote Control .......................................................................... 11
6.5 RS-232 Protocols .......................................................................12
6.6 Telnet & RS-232 Commands......................................................13
6.7 Telnet Control .............................................................................18
6.8 Web GUI Control ........................................................................20
7. Connection Diagram......................................................................22
8. Specifications ................................................................................23
9. Acronyms .......................................................................................25
1
EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
1
1. INTRODUCTION
The 6 by 2 HDMI matrix which allows HDMI signal from any of its six sources to be routed
to and displayed on any of its two connected HDMI displays simultaneously with View All
Mode and Picture-in-picture(PIP) supported. With fast switching technology the device can
greatly eliminate the time required by swapping or turning ON/OFF the connected displays.
It supports 4Kx2K, 3D, 36-bit Deep Color, Hi-Def lossless audio and other features dened
by HDMI specications. The management of source/sink scenarios can be operated easily
through on-panel buttons, IR remote control, RS-232 or Ethernet protocol.
2. APPLICATIONS
• Home Theater/Entertainment
• Lecture Room/Hall Presentation
• Show Room/Demo Room
• Public Commercial Display
• Information Board
3. PACKAGE CONTENTS
• 6 by 2 HDMI 4Kx2K Matrix
• Remote Control with Battery
• Left & Right Rack Ears
• 5V/2.6A DC Power Adaptor
• IR Receiver Cable
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipments such as Blu-ray/DVD/PS3 player or Set-Top-Box and output
HDMI TV/Display and or audio amplier with connection cables.
2
EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
2
5. FEATURES
• HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant
• Support six HDMI inputs and two HDMI outputs
• Displays any of six (6) High-Denition sources on two (2) HDTV displays simultaneously
with fast switch
• When in Preview mode, the system will be treated as Switcher (two HDMI output same
images at the same time)
• In Preview mode, it support View All (1 Main video source and 5 Sub video sources) and
PIP (1 Main video source and 1 Sub video source). 3D and 4K2K sources inputs are not
supported for sub-windows
Note: View All is TDM (Time Division Multiplexing display)
• 3DTV Pass-Through
• Supports HDTV resolutions up to 4Kx2K (3840x2160@24/25/30 & 4096x2160@30Hz,
50/60 @YUV420)
• Supports Optical audio extraction
• Supports Optical audio sampling rate output up to 192kHz
• Supports data rate from 300Mbps to 3Gbps and Deep Color up to 1080p 36-bit
• Supports individual EDID or common EDID
• Supports LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH (Pass through),
Dolby TrueHD and DTS-HD Master Audio
• Supports 6 sets of Matrix preset functions for input/output setting
• Input port HDCP support Standard and Apple mode. The Apple mode selection to
guarantees the use of Apple devices
• Compliant with DVI source
Note: Support HDMI to DVI conversion when HDMI source is non-deep color and color
space RGB.
Not support HDMI to DVI conversion when HDMI source is deep
color and color space YCbCr 444/422
• Supports OSD on output B under Preview Mode
3
EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
6X2 HDMI MATRIX FAST SWITCH CDPS-6H2HFS
IN 1IN 2IN 3IN 4IN 5IN 6 MUTE TAKE
OUT A OUT B CANCEL
ENTER
MENU
PRESET
ALL
MODE
LOCK
+
-
4K UHD
1 2 5 6 8 1113 153
4 7 9 10 12 14
1POWER: Press this button to turn ON the device and the LED will illuminated.
2IR Window: This IR Receiver receives the IR signal from the package included remote
control only.
3IN 1~6: Press these IN buttons to select an input from the 6 input sources.
4OUT A/B: Press these buttons once a time along with an IN buttons to select an input
source for an output display. i.e. OUT A→IN1→TAKE or OUT B→IN6→TAKE.
5MUTE: Press this button to mute both video and audio on OUT A or B.
6TAKE: Press this button to conrm the selection of an IN and an OUT button.
7CANCEL: Press this button to cancel the IN/OUT selection.
8ENTER: Press to conrm the selection.
9MENU: Press to enter into the menu.
10 +/-: Press these buttons to move up/down under menu selection.
11 PRESET: (PV MUTE: Preview ON/OFF)
•When select the MODE in Preview mode, press the button to turn ON/OFF the Sub
video windows.
•When select the MODE in Matrix mode, press “PRESET” to switch between Normal
and Preset mode.
•Normal mode:
Press OUT A or OUT B or ALL and then press IN 1~6 or MUTE to select the input
sources. After the selection, press “TAKE” to conrm the selection or press
“CANCEL” to cancel the selection.
•Preset mode:
Press “PRESET”, the OLED menu will show Preset then select IN 1~6. Preset 1~6
after the selection, press “TAKE” to conrm the selection or press “CANCEL” to
cancel the selection.
4
EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
4
12 All: (SWAP)
Press this button to select all outputs to display with an input source. When in PIP
mode, press to swap between Main video source and Sub video source.
13 MODE: Press to switch between Preview or Matrix mode.
•Preview mode: From MENU option select View All (1 Main video sources and 5 Sub
video sources) or PIP mode (1 Main video sources and 1 Sub video sources).
Note: Under Preview mode, OSD display on output B only.
•View All: Press IN 1~6 or MUTE to select the Main channel. From OLED menu
select “Preview Position” for Sub screens position.
Note: All sub screens will be display rotatively for about 0.5 second and those
screens that are not rotatived will be freezed.
•PIP: Press OUT A (Main) or OUT B, then press IN1~6 or MUTE to select Main or
Sub video source. Press “ALL” or Remote Control “ SWAP” to exchange Main/Sub
video source.
Note: When both Main and Sub select the same input source, Sub will be
muted.
•Matrix mode: Press OUT A or OUT B or OUT A & B and then press IN 1~6 or MUTE to
select the input sources. After the selection, press “TAKE” to conrm the selection or press
“CANCEL” to cancel the selection.
14 LOCK: Press this button to lock all button functions on the panel. Press 3 seconds to
relieve the lock function.
15 LCM: Displaying Input and Outputs selection and menu selection.
5
EGE-UHD-642FS
6×2 4K UHD HDMI Matrix with Fast Switching
5
CONTROLSERVICE
HDMI IN HDMI OUT S/PDIF OUT
AB
123456AB RS232 IR IN DC 5V
1 4 5 6 7 8
2 3
6.2 Rear Panel
1HDMI IN: Connect from source equipments such as Blu-ray/DVD/PS3 players, Set-Top-
Box or any HDMI equipped source device for input signal sending.
2HDMI OUT: Connect to HDMI TV/display or HD Amplier for output image and or audio
display.
3S/PDIF OUT: Connect to audio sound system or Amplier for digital output sound.
4SERVICE: This slot is reserved for rmware update use only.
5CONTROL: Connect from PC/Laptop with active internet service for Web GUI control
with RJ-45 terminated cable.
6RS232: Connect from PC/Laptop for RS-232 command sending to control the device.
7IR IN: Connect the IR Receiver included in the package for IR signal receive from the
included remote control.
8DC 5V: Connect the adaptor with power cord included in the package and connect to
AC wall outlet for power supply.
