Genius I-LOOK 1321 Manual de usuario

-i-

Table of Contents

i-Look 1321 Features 1

Installing the i-Look 1321 2-3

About Genius Application-WebCAM Mate 3

1. Main Menu 4-10

2. Picture Mode 11-13

3. Video Mode 14-15

4. Security Mode 15-18

Using MSN Messenger,Yahoo Messenger,AOL 18-20

CrazyTalk Avatar Creator 20-43

CrazyTalk CamSuite 44-70

Trouble shooting for web camera 71

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in

charge of waste management.

i-Look 1321 provide Mega-Pixel High-Definition video. i-Look

1321 also feature low-noise CMOS imaging technology that

achieves superior signal-to-noise ratio and low-light sensitivity,

lets you enjoy the clarity of web video.

1.SnapShot Button

You can press the snapshot button to

take still images.

2.Lens

Adjust the focus by twisting the lens.

3.LED Indicator

i-Look 1321 is connected to the

computer's USB port and the LED will

light up when performing video

application.

4.Microphone

5.Swivel and Clipping Base

The adjustable clipping base fits easily

to almost anything - notebook panel,

CRT, and LCD monitors.

i-Look 1321 Features

English

-2-

You need to install device drivers and applications before using your

webcam.

Do not connect your webcam to your computer before

installing the drivers.

1. Installing the i-Look 1321 driver Windows Vista/XP/2000/Me/98SE

Environment

a. Insert the i-Look 1321 Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install DirectX from the CD if your pc didn’t have it on your system or

the version was older.

NOTE

If the Autorun screen doesn’t start, please follow these steps

zClick on “Start Menu”

zType D:\SETUP.EXE, then click the Enter key.

(Assume your CD-ROM is in Drive D)

2. Follow the instructions on the screen to complete the installation.

3. Insert the i-Look 1321’s USB cable to your desktop or laptop USB

port.

4. Restart your computer after all the applications have been

installed.

Installing the i-Look 1321

English

-3-

5. The software and hardware installation is now complete. You can

install the software you would like to use for video conferencing or

chat with your friends.

NOTE

The web camera can work properly with any video chat software that

supports a video feature.

To remove the driver installation in Windows 98SE/Me/2000/XP/Vista Environment:

Please go to the taskbar and follow “Start ÆProgram Æi-Look 1321 ÆClick

“Uninstall”, then follow the on-screen instructions to remove the driver.

You can use Genius WebCAM Mate software to capture the real-time image,

record or execute the simply security function.

To run the Genius WebCAM Mate software, please go to the task bar and

follow “Start”( Click “Program”( Choose “i-Look 1321”( Click “i-Look 1321”.

Or you may execute the software by simply clicking the shortcut of “i-Look

1321”.

NOTE

After installing the driver of i-Look 1321, the system will

automatically create a file (C:\WINDOWS\Album or

C:\WINNT\Album)to save the images you take using the Genius

Application.

About Genius Application-WebCAM Mate

English

-4-

1. Main Menu

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

English

-5-

Item Mode Description

Resolution

Selection

Resolution selections according to

device.

RGB24: 1280x1024, 1024x768,

800x600, 640x480, 352x288, 320x240,

176x144, 160x120 pixels

I240: 1280x1024, 1024x768, 800x600,

640x480, 352x288, 320x240, 176x144,

160x120 pixels

Property page Preference setting to view your setting

and properties.

Exit Exit the Genius UI.

English

-6-

Property page

Setting

Item Description

-You can flip the image horizontally or vertically by choosing

“Image Mirror” or “Image Flip”.

-When the light is not sufficient, you may click on “Low Light”

to get a clear image.

English

-7-

Item Description

You can adjust different values for different circumstances and

environment

When you want a still image capture, you can drag the bar to

select a resolution you want.

-VGA: 640 x 480;

-SVGA: 800 x 600

-XGA: 1024 x 768

-SXGA1280 x 960

You may adjust values toward image appearance. Before

adjusting values, you have to unclick “Auto” to unlock.

-Press “Reset” to return to the default settings.

-Press “Restore” to return to the previous settings.

Select the correct frequency according to the country where you

are using the web camera. (Before doing this, you will need to

select “Indoor”.)

-If your web camera is located in backlight position, you may

click “Backlight compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on

“B/W Mode”.

English

-8-

Effect

Item Description

There will be 26 different kinds of video effects/frames for you to

select. The effects can also be applied to the video chat software,

like MSN Messenger.

You can directly connect to this effect page from the web camera

settings in the video chat software.

English

-9-

Item Description

Besides the 26 kinds of video effects/frames in section 1, you also

can bring in your customized frame. Please note that, in the

customized frame, you must have the color in Pantone number

255 in the area, where you want your image show up.
