ULTRA HIGH RESOLUTION NIGHTVISION CAMERA
with 3D DNR
ZD9221
USER MANUAL
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ISO14001
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
their own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
This installation should be made by a qualified service person and
should conform to all local codes.
CAUTION : To prevent electric shock and risk of fire hazards:
☞Do NOT use power sources other than those specified.
Precautions
Do not install the camera in
extreme temperature conditions.
Do not touch the front lens of the
camera.
Do not install or use the camera in an
environment where the humidity is high.
Do not drop the camera or subject
it to physical shocks.
Do not expose the camera to
radioactivity.
Do not install the camera under
unstable lighting conditions.
Never keep the camera pointed
directly at strong light.
Only use the camera in conditions
where temperatures are between
-20°C and +50°C. Be especially careful
to provide ventilation when operating
under high temperatures.
This is one of the most important parts
of the camera. Be careful not to leave
fingerprints on the lens cover.
Do not install or use the camera in an
environment where the humidity is
high.
It can cause malfunctions to occur.
If exposed to radioactivity the CCD
will fail.
Severe lighting change or flicker can
cause the camera to work improperly.
Severe lighting change or flicker can
cause the camera to work improperly.
NOTE
* If the camera is exposed to
spotlight or an object reflecting strong light, smear or blooming may
occur.
* please check that the power satisfies the normal specification before
connecting the camera.
SPECIFICATIONS
MODEL
1/3” Sony Super HAD CCD ll
NTSC, PAL
NTSC=811(H) * 508(V) / PAL=795(H) * 596(V)
NTSC=768(H) * 494(V) / PAL=752(H) * 582(V)
NTSC=15.734KHz(H) & 59.94Hz(V) / PAL=15.625KHz(H) & 50.00Hz(V)
2:1 Interlace
Internal
600TV Lines
CDS OFF: 0.15 Lux, CDS ON: 0.00002 Lux
More than 52dB
CVBS: 1.0Vp-p / 75Ω
NTSC=(1/60sec~1/120,000sec) / PAL=(1/50sec~1/120,000sec)
Available
On / Off (Level adjustable)
BLC / HLC / OFF
Colour / BW / AUTO / EXT
Low / High / Off
ATW / Outdoor / Indoor / Manual / AWC (1,700°K ~ 11,000°K)
Auto / Off (Selectable x2 ~ x512)
On / Off (8 Programmable Zones)
On / Off (12 Programmable Zones)
On / Off (Level adjustable)
On / Off (x1 ~ x16)
On / Off
On / Off (Level adjustable)
On / Off / V-Rev / H-Rev
DC 12V / AC 24V-Dual Voltage
CDS ON:1.5A Max
DC Auto Iris Varifocal Lens(9mm-22mm)
~20 ~ +50 Deg C. RH95% MAX.
~20 ~ +60 Deg C. RH95% MAX.
195mm(W) * 155mm(H) * 260mm(D)
2300g
ZD9221
Image Pick-Up Device
TV System
Total Pixels
Effective Pixels
Scanning Frequency
Scanning System
Synchronisation
Resolution
Minimum Illumination
S/N Ratio
Video Output
Electronic Shutter Speed
OSD
SSDR
BLC
Day & Night
Gain Control
White Balance
SENS-UP
Motion Detection
Privacy Masking
SSNR III (Digital Noise Reduction)
Digital Zoom
DIS (Digital Image Stabilizadion)
Sharpness
Filp / Mirror
Power Supply
Power Consumption
Lens
Operational Temp.
Storage Temp.
Dimension
Weight
600TV Lines
DC Auto Iris Varifocal
Lens (9mm-22mm)
True Day/Night Capability
ICR-IR Cut Filter Removable
IP 66
Ultra High Resolution Nightvision Camera with 3D DNR
Built-in 70-power infrared LEDs with CDS Sensor
Camera OSD Control
Specification
Anti Vandal
Hood Camera
IP66
Registant
Weather
Function
DC 12V / AC 24V
LENS
DC VARIFOCAL
Shutter
High Speed
Resolution
Horizontal
Backlight
Compensation
600
BLC
Auto White
Balance
DAY & NIGHT
CCD
1/3"
0.00002Lux
Minimum
Illumination
Auto
Gain
Control
FILTER CHANGE
NIGHTDAY
OSD
Motion
Detection
2x ~ 512x
HOW To Install
Camera Adjustment
General Features
Dimensions
SETTING
* 1/3" SONY Super HAD CCD
*
Ultra High Resolution : Colour - 600TV Lines / B/W - 700 TV Lines
* Max. Sens-Up (×512), 0.00002 Lux of Min. lllumination
* Convenient OSD Control Function
* ×16 Digital Zoom
* Free Area Selectable Function of BLC and MD
* Privacy Colour Masking for 12 Area Selection
* ICR-IR Cut Filter Removable
* Max 70% of Disk Saving Effect with Super DNR
* DC 12V / AC24V(Dual Voltage)
①Connect Video & Power Line (12V DC/24V AC Regulated Power).
② Position the camera for the correct angle of view.
③ Loosen the locking screws and focus the camera.
④ Re-tighten the locking screws.
Settings can be made using the OSD button located in the
body housing.
OSD Control Board
1.LENS
2.EXPOSURE
3.WHITE BAL
4.SSNR
5.BACKLIGHT
6.DNR3
7.DAY/NIGHT
8.SPECIAL
9.EXIT
MAIN SETUP
DC
ATW
OFF
OFF
ON
AUTO
SAVE
1.BRIGHTNESS
2.SHUTTER
3.AGC
4.SENS-UP
5.RETURN
EXPOSURE SETUP
25
- - -
HIGH
OFF
1.IMAGE ADJ
2.MONITOR
3.CAM TITLE
4.SYNC
5.MOTION DET
6.PRIVACY
7.COMM ADJ
8.LANGUAGE
9.RETRUN
SPECIAL
LCD
OFF
INT
OFF
OFF
OFF
ENGLISH
1
Contents
◑Contents
◑Safety Instructions
◑General Features
◑OSD Control Button
◑Camera Menu Set Up
1. Menu Set Up
2. Lens Setting
3. Exposure Setting
4. White Balance Setting
5. SSNR Setting
6. Backlight Setting
7. DNR3 Setting
8. Day/Night Setting
9. Special Setting
10. Exit Setting
◑Trouble Shooting
1
2
3
4
5
5
5
6
7
8
9
10
11
12
17
18
2
Precautions for use
Please read this manual thoroughly before using the camera to become familiar with the
correct operational procedures.
Cautions When Using
Do not open the camera body and touch any electrical parts to avoid possible electric shocks.
Do not insert objects into the camera body to prevent fire hazards and electric shock.
Do not touch the camera with wet hands - to avoid an electric shock.
Do not disconnect the power cord from a power plug when still connected to the outlet.
Always disconnect the power by removing the plug from the power socket.
lf the camera emits a burning smell, immediately disconnect it from the power source and
report the problem to your distributor.
Cautions When Install
Only apply power after installation of the product.
Do not install the camera in a position facing directly at a strong light source.
Do not install or use the camera in areas of high humidity.
Do not install near any cooling or heating equipment.
Do not install the camera in dusty environments.
Do not install the camera in places where the camera is subjected to physical shocks.
This products must be used with a regulated adaptor for power, such as the Genie PSU1SM.
☞
☞
☞
☞
☞
☞
☞
☞
☞
☞
☞
☞
☞
☞
Safety Instructions
3
General Features
◑ Ultra High Sensitivity
- The built-in high sensitivity COLOUR CCD produces a clear image even in 0Lux(B/W, IR-LED ON)or lower
illumination.
◑ 600TV Lines
- By adopting a diagonal 6mm(1/3") 410,000 (NTSC) pixel, 470,000(PAL) pixel SONY CCD, the camera
produces clear picture quality with a horizontal resolution of 600 TV lines for colour and a horizontal
resolution of 700TV lines for BW mode.
◑ DNR3
- The high-performance W-V DSP chip effectively removes low-light gain noise and ghosting to provide
clear images even in dark environments.
◑ Day & Night
- This camera has a function that automatically selects the mode that is appropriate for daytime or night-time
conditions.
The COLOUR mode operates in daytime conditions to provide optimum colours, and BW mode operates in
night-time conditions to enhance the definition of the image.
◑ SSNR
- For images with high contrast between bright and dark Areas from difficult lighting conditions such as
backlighting, this camera selectively illuminates darker Areas while retaining the same light level for
brighter Areas to even out the overall brightness.
◑Miscellaneous Functions
- HLC(High Light Compensation), SENS-UP, FLIP(H/V-REV), D-ZOOM, SHARPNESS, MOTION DETECTION and PRIVACY
functions are provided.
◑ Disk Saving Effects
- Up-most and advanced DNR technology camera picture quality has a disk saving effects due to Image sizes
are smaller than standard CCTV camera image.
◑ Controlled by OSD Menu
- The camera can be controlled by selecting the menu text displayed on the monitor screen.
4
OSD Control Button
1. Type A, Type B, Type C of OSD button could be used when it needs to
OSD control.
2. Type D is extra Option (wired Remote controller)
▲Up button: Moves the cursor upwards. Use this button to select an item
or adjust the parameters.
▼Down button: Moves the cursor downwards. Use this button to select an
item or adjust the parameters.
◀Left button: Moves the cursor to the left. Use this button to select or
adjust the parameters of the selected item. The parameter changes
each time this button is pressed.
▶Right button: Moves the cursor to the right. Use this button to select or
adjust the parameters of the selected item. The parameter changes each
time this button is pressed.
◎Set button: Executes selections and displays a submenu for an item with
the mark.
5
●
Menu Setup
●
Lens Setting
1. Press the Function Setup switch.
- Main setup menu is displayed on the monitor screen.
3. THE Lens mode has sub menu items as listed below.
- BRIGHTNESS : Adjusts the video brightness.
Using this function, you can control the screen brightness.
1. When the SETUP menu screen is displayed, select 'LENS' by using
the Function Setup switch so that the arrow indicates 'LENS'.
2. DC : You can adjust the minimum shutter and maximum value of ESC
shutter mode.
2. Select a desired function using the Function Setup switch.
- Place the cursor over a desired item.
3. Set up a selected item by using the Function Setup switch.
4.
To finish the setting, select 'EXIT' and press the Function Setup switch.
MAIN SETUP
MAIN SETUP
1.LENS
2.EXPOSURE
3.WHITE BAL
4.SSNR
5.BACKLIGHT
6.DNR3
7.DAY/NIGHT
8.SPECIAL
9.EXIT
1.LENS
2.EXPOSURE
3.WHITE BAL
DC
ATW
OFF
OFF
ON
AUTO
SAVE
DC
ATW
☞ NOTE
■ An item with the
◀
icon also has sub menus. To select a sub menu, select an item
with the icon and press the Function Setup switch.
■ An item with the - - - icon is unavailable due to function settings.
Tabla de contenidos
Otros manuales de Cámara de seguridad de Genie CCTV
Genie CCTV
Genie CCTV HDB2810IR Manual de usuario
Genie CCTV
Genie CCTV DNR300OZ Manual
Genie CCTV
Genie CCTV HDC201 Manual de usuario
Genie CCTV
Genie CCTV DN83TSPX Manual
Genie CCTV
Genie CCTV GMC3CH Manual de usuario
Genie CCTV
Genie CCTV LTVD52811 Manual
Genie CCTV
Genie CCTV GANPRCAM Manual de usuario
Genie CCTV
Genie CCTV ZW2812 Manual de usuario
Genie CCTV
Genie CCTV WAHD2B Manual de usuario
Genie CCTV
Genie CCTV TD-D62 Manual de usuario
Genie CCTV
Genie CCTV VRD73 Manual de usuario
Genie CCTV
Genie CCTV 1000TVL Manual de usuario
Genie CCTV
Genie CCTV Raptor II Ruggedized PTZ Manual de usuario
Genie CCTV
Genie CCTV W70MDIR Manual de usuario
Genie CCTV
Genie CCTV PIXIM VRD83SPX Manual
Genie CCTV
Genie CCTV ZD2812 Manual de usuario
Genie CCTV
Genie CCTV VRD43/12 Manual de usuario
Genie CCTV
Genie CCTV GD5324/2.9 Manual
Genie CCTV
Genie CCTV MVD83SPX/12 Manual
Genie CCTV
Genie CCTV GD103CHVAI/SMO Manual de usuario
