Genesys GL3520 Guía
USB 3.0 Hub Controller
Design Guide
Revision 2.11
Jan. 06, 2015
Genesys Logic, Inc.
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 2
GLI Confidential
Copyright
Copyright © 2015 Genesys Logic, Inc. All rights reserved. No part of the materials shall be reproduced in any
form or by any means without prior written consent of Genesys Logic, Inc.
Ownership and Title
Genesys Logic, Inc. owns and retains of its right, title and interest in and to all materials provided herein.
Genesys Logic, Inc. reserves all rights, including, but not limited to, all patent rights, trademarks, copyrights
and any other propriety rights. No license is granted hereunder.
Disclaimer
All Materials are provided “as is”. Genesys Logic, Inc. makes no warranties, express, implied or otherwise,
regarding their accuracy, merchantability, fitness for any particular purpose, and non-infringement of
intellectual property. In no event shall Genesys Logic, Inc. be liable for any damages, including, without
limitation, any direct, indirect, consequential, or incidental damages. The materials may contain errors or
omissions. Genesys Logic, Inc. may make changes to the materials or to the products described herein at
anytime without notice.
Genesys Logic, Inc.
12F., No. 205, Sec. 3, Beixin Rd., Xindian Dist. 231,
New Taipei City, Taiwan
Tel : (886-2) 8913-1888
Fax : (886-2) 6629-6168
http ://www.genesyslogic.com
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 3
GLI Confidential
Revision History
Revision
Date
Description
1.00
07/15/2010
First formal release
1.10
12/30/2010
Add Ch5 System Design Guideline, p.17~19
1.20
02/22/2011
Add Figure 3.1, p.7
Modify 3.2.8 SS Trace Swap, p.11
1.30
03/08/2011
Modify 3.2.8 SS Trace Swap, p.12
Add 5.4 ESD Protection, p.20
1.40
04/12/2011
Add 3.1.2 2-Layer PCB, p.8
Modify Ch4 The Example of Differential Traces and Impedance, p.18
1.50
04/22/2011
Add Ch6 ESD Protection, p.22
1.60
05/18/2011
Add Figure 5.4 Hub Trace on Mother Board, p.22
1.70
05/19/2011
Update 3.2.8 SS Trace Swap, p.13
1.80
07/08/2011
Add Note for 3.2.8 SS Trace Swap, p.13, 14
1.90
02/02/2012
1.2V DC to DC Converter layout note, p.16
Co-Layout Circuits layout note, p20
GL3521 Circuits layout note, p21
2.00
10/02/2013
Updated CH2 Circuit Design and PCB Layout Guidelines
Updated CH3 System Design Guidelines
2.10
01/05/2015
Updated Figure 3.4, p.25
2.11
01/06/2015
Correct page number in 2.10 Revision History
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 4
GLI Confidential
Table of Contents
1. INTRODUCTION..............................................................................................................6
2. CIRCUIT DESIGN AND PCB LAYOUT GUIDELINES .............................................6
2.1 AC Coupling Capacitors...........................................................................................6
2.2 PCB Layer and Material...........................................................................................7
2.2.1 4-Layer PCB...................................................................................................7
2.2.2 2-Layer PCB...................................................................................................7
2.3 Differential Pairs Trace.............................................................................................7
2.3.1 Differential Pair Impedance..........................................................................7
2.3.2 Differential Trace...........................................................................................7
2.3.3 Differential Trace Length Preliminary Guidelines.....................................7
2.3.4 Trace Bend......................................................................................................8
2.3.5 Reference Plane..............................................................................................8
2.3.6 Signal Return Path.........................................................................................9
2.3.7 Differential Pair Layout ..............................................................................11
2.3.8 Avoid Stub on Differential Traces..............................................................12
2.3.9 SS Trace Swap..............................................................................................12
2.4 Circuit and Component Placement........................................................................14
2.4.1 Decoupling Capacitors.................................................................................14
2.4.2 RTERM Resistor..........................................................................................14
2.4.3 Crystal Circuit..............................................................................................15
2.4.4 Reset Circuit.................................................................................................15
2.5 Power Source............................................................................................................16
2.6 Power Trace of Charging Downstream Port.........................................................17
2.7 Thermal Reduction..................................................................................................17
2.8 Trace Width and Adjacent Space Gap ..................................................................18
2.8.1 USB 3.0..........................................................................................................18
2.8.2 USB 2.0..........................................................................................................18
2.8.3 Recommend Width and Space for USB 2.0 & USB3.0 Trace..................18
2.9 GL3520/GL3521 Co-Layout Notice .......................................................................19
2.10 GL3521 Layout Notice.............................................................................................20
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 5
GLI Confidential
3. SYSTEM DESIGN GUIDELINES.................................................................................22
3.1 System Design Overview .........................................................................................22
3.2 Channel Description –with a Cable.......................................................................23
3.3 Channel Description –without a Cable.................................................................24
3.4 Hub Trace on Mother Board..................................................................................25
4. ESD PROTECTION........................................................................................................26
4.1 Hub............................................................................................................................26
4.2 Hub with External Charger IC...............................................................................26
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 6
GLI Confidential
1. INTRODUCTION
The purpose of this document is to provide suggestions for the design of circuit and PCB layout regarding the
USB 3.0 Hub Controllers of Genesys Logic Inc.
2. CIRCUIT DESIGNAND PCB LAYOUT GUIDELINES
2.1 AC Coupling Capacitors
PHY is a component where the transmitter and receiver are located and operated together. The AC coupling
capacitors are associated with the transmitter.
Differential Pairs
Capacitor
USB 3.0 SS TX P/N
0.1uF
The AC coupling Capacitor should be placed by closing to Connector. The capacitor body size should be less
than or equal to 0603 (0402 is recommended). And AC coupling capacitor must be placed symmetrically. (as
shown in Fig. 2.1)
Perferred example
Bad example
Figure 2.1
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 7
GLI Confidential
2.2 PCB Layer and Material
2.2.1 4-Layer PCB
Four (4) layers and FR4 PCB are recommended to use. Besides, the traces of differential signals must be
entirely routed over ground plane.
PCB Layer
Trace Net Name
Top
SS Differential Pair Trace (Hub IC should be placed in the same layer)
Inner 1
GND
Inner 2
POWER,GND
Bottom
HS Difference Pair , Control Signal
2.2.2 2-Layer PCB
PCB Layer
Trace Net Name
Top
SS Differential Pair Trace (Hub IC should be placed in the same layer)
Bottom
HS Difference Pair , Control Signal
2.3 Differential Pairs Trace
2.3.1 Differential Pair Impedance
The differential impedance requirement must be 90 Ohm ± 10 % and trace width / spacing may be different
by PCB material characteristic base on PCB Vendor suggest.
2.3.2 Differential Trace
Keep the trace length of SS TX/RX or HS D+/D- from USB connector to chip as short as possible. And the
differential pairs trace routing must be symmetrical. USB 3.0 & USB 2.0 differential trace MUST use different
layer to avoid cross routing. Make the differential signal trace GND plane via holes as more as possible to keep
GND plane solid with adjacent GND layer.
2.3.3 Differential Trace Length Preliminary Guidelines
Differential Pairs
Signal Referencing
Trace Mismatch Tolerance
Maximum Total Length
USB 3.0
SSTXP/N, SSRXP/N
Ground
≦5mil
9 inches
USB 2.0
DP/DM
Ground
≦50mil
9 inches
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 8
GLI Confidential
2.3.4 Trace Bend
When traces are encountered, please use 45
bends (or turns) of traces. The inner air gap of a bend, Ashould
be
≧
20 mils and the angles between traces should be greater than 135 degrees. (
135
)and the length of
Band Cshould be minimized.
Pad
Pad
A
C
B
α
Figure 2.2
2.3.5 Reference Plane
Make sure that the differential trace layer and adjacent layer are with solid GND plane.
The differential pair trace must be kept in the outer layer, and have a continual full ground plane at neighbor
layer for reference. (See Fig. 2.3)
Figure 2.3
Top Layer
USB HUB Controller
Full Ground Layer (Better)
SS Traces on Top Layer
Power or Ground Layer
USB Connector
Bottom Layer
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 9
GLI Confidential
A differential pair should avoid discontinuation in the reference plane, such as splits and voids. When a
signal need changes layers, must keep the same reference plane and the ground stitching via should be
placed by closing to the signal via. A minimum of 2 stitching via per pair of signals is recommended. Never
route a trace so that it straddles a plane split. (See Fig. 2.4)
Power Plane
Ground Island
L3 Vcc layer
Differential pair at Bottom layer
Signal Via
Place Stitching Vias close to Signal Via
(Space within <= 50 mils)
Place Stitching Vias to Ground layer along edge of Ground island
Plane void
Bottom Signal
Top Signal
Layer3 Power Plane
Layer3 Ground Island
Figure 2.4
2.3.6 Signal Return Path
An incorrect signal return path is one of the most common sources for noise coupling and EMI problems.
Figure 2.5 Return Current tries to follow the Signal Path
Source
Sink
Signal: Source to Sink
Signal Return Path: Sink to Source
USB 3.0 Hub Design Guide
©2015 Genesys Logic, Inc. - All rights reserved. Page 10
GLI Confidential
A signal should not be routed over a split plane as the return path is not able to follow the signal trace. If a
plane is split between a sink and source, route the signal trace around it. If the forward and return paths of a
signal are separated, the area between them acts as a loop antenna.
Figure 2.6Avoid Routing over Split Planes
