Gene Cafe CBR-101A Manual de usuario
COFFEE BEAN ROASTE R
MODEL CBR-101A
INNOVATIVE OFF -AXIS ROTATION
•To ensure safe, trouble-free operation, please carefully read this manual
•Warranty information contained in this manual.Do not discard.
Service Manual
(Rev. 01)
REV. 01 _ 070315
SAFETY COVER
Requirements
1
2
3
4
Process Picture Instruction
Disassembly
●Make sure that unpug the power cord before the
assembly and disassembly.
●After open the safety cover, lift the chamber maked
in this picture.
●After close the safety cover,remove it maked
in this picture.
Assembly Opposite operation of disassembly.
BASE PANEL/SIDE COVER
Requirements
1. DRIVER (+.-)
2. Screw: x 2
3
4
Gene Cafe Replacement Instructions
Model : Gene Café (CBR-101)
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
Process Picture Instruction
Disassembly
●Unscrew them indicated in the picture.
●Remove the base panel to use a tool indicated
in the picture.
●Pull out the side cover as indicated in the picture
by green arrow.
Causion) The process by reassembling, make sure
the direction of side cover.
Assembly opposite operation of disassembly.
TOP CABINET
Requirements
1
2
3
4
Process Picture Instruction
●Remove the eight screw at bottom of the roaster
as indicated in the picture.
●Screw: x (6pc)
Screw: x (2pc)
(L) (R)
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
Disassembly
●Lift the top cabinet with both hand as indicated here
by the green arrow.
●Remove the connector with hands.
in this picture.
●To assembly the top cabinet, Hold the top cabinet with
hand maked in the picture, and the Control Lead Wire
to locate between transformer and Boss.
●To assembly with bottom cabinet, make sure to match
the side of both as indicated in this picture.
Assembly opposite operation of disassembly.
BOTTOM CABINET
TOP CABINET
TRASFORMER
BOSS
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
DAMPER OUT ASS'Y
Requirements
1
2
3
4
Process Picture Instruction
Disassembly
●In the main PCB, remove the "Temp Sen(1)"
by long nose.
●Rescrew them as indicated in this picture and then,
Remove the bottom cabinet as lift the damper out Ass'y.
●With minus driver, Remove the motor gear from
motor shaft as indicated by this picture.
Assembly opposite operation of disassembly.
DAMPER IN ASS'Y
Requirements
1
2
3
4
Process Picture Instruction
●In the main PCB, remove the "Temp Sen(2)"
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
Disassembly
by long nose.
●Rescrew them as indicated in this picture.
●With minus driver, Remove the motor gear from
motor shaft as indicated by this picture.
●To reassembly, Damper out ass'y apply by silicone
as indicated by this picture.
●Make sure that the bearing have to match as
by this picture.
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
●Lead wire of Temp sensor(2) have to through
heater box ass'y and bottom cabinet boss as indicated
by this picture.
Assembly opposite operation of disassembly.
HEAT BOX ASS'Y
Requirements
1
2
3
4
Process Picture Instruction
Disassembly
●In the Power PCB, remove the connection of heater
by long nose.
●Rescrew them as indicated in this picture.
●the line of heater and temperture sensor need to
under the Damper In Ass'y as indicated by this picture.
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
Disassembly
● To assembly, Insert as indicated by this picture.
●Screw the bolt as indicated by this picture
Assembly opposite operation of disassembly.
REED SENSOR PCB
Requirements
1
2
3
4
Process Picture Instruction
●In the main PCB, remove the "REED SENS"
by long nose.
●Rescrew them as indicated in this picture.
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
Disassembly
●To assembly, make sure that, the REED SENSOR
located left side of PCB.
Assembly opposite operation of disassembly.
FAN
Requirements
1
2
3
4
Process Picture Instruction
Disassembly
●In the main PCB, remove the "FAN" connector
by long nose.
●Rescrew them as indicated in this picture and then,
Remove the FAN as lift from bottom cabinet.
●Make sure to match the FAN as indicated in this
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
Assembly opposite operation of disassembly.
POWER CORD
Requirements
1
2
3
4
Process Picture Instruction
Disassembly
●Remove the Twe connector as indicated in this picture
from the main PCB and FUSE HOLDER.
●Rescrew them as indicated in this picture
●With Cord Pusher, Push the cord push and then
as indicate by the arrow.
Assembly opposite operation of disassembly.
GS-DOC-0704-CS Innovative off-axis rotation Genesis Co., Ltd.
