Gefen RMT-4IR Manual de usuario

Technical Support:

Telephone 818-772-9100

800-545-6900

Fax 818-772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday through Friday.

Write To:

Gefen Inc.

c/o Customer Service

620600 Nordhoff Street

Chatsworth CA 91311

www.gefen.com -- [email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

The 4x1 DVI/ADC Switcher is a trademark of Gefen Inc.

Macintosh is a trademark of Apple Computer Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Front Panel Descriptions

Back Panel Descriptions

How To Connect The 4x1 DVI/ADC Switcher

RMT-4IR

System Speciﬁcations

Warranty

READ THESE NOTES BEFORE INSTALLING

OR OPERATING THE 4X1 DVI/ADC SWITCHER

• If two monitors are connected to the switcher, both monitors (one DVI and one ADC)

must have the same native resolution.

• The 4x1 DVI/ADC Switcher is housed in a metal box for better RF shielding.

• The 4x1 DVI/ADC Switcher has a two port USB Hub built in. The two USB ports on

the ADC monitor are active and can be used to connect additional USB peripherals.

OPERATION NOTES

INTRODUCTION

Thank you for purchasing Gefen’ s ex•tend•it 4x1 DVI/ADC Switcher series. The 4x1 DVI/

ADC Switcher switches DVI/ADC, USB and audio between any combination of four com-

puters. Now you can switch easily and reliably between any combination of four computers

using one DVI or ADC display, USB keyboard and mouse. The 4x1 DVI/ADC Switcher is

switched using the RMT-4IR. The 4x1 DVI/ADC Switcher saves space – there’s no need

to work on a desk crowded with four monitors, keyboards and mouse devices. It saves

time – there’s no need to move from one monitor to another to access different computers.

And it saves money – there’s no need to purchase additional monitors, mouse devices,

keyboards etc. The 4x1 DVI/ADC Switcher allows you to choose between any combination

of Macintosh or PC computers.

CONTENTS

The 4x1 DVI/ADC Switcher system consists of:

--- (1) 4x1 DVI/ADC Switcher

--- (1) RMT4-IR remote control

--- (2) AAA batteries

--- (1) 24 VDC power supply

--- (1) AC power cord

--- (4) DVI cables (6FT)

--- (4) USB cables (6FT)

--- (4) Audio cables (6FT)

--- (1) User Manual

1-4Indicator LED

Power LED

Infrared Eye

FRONT PANEL DESCRIPTIONS

BACK PANEL DESCRIPTIONS

POWER

INPUT

DVI IN 1 DVI IN 2 DVI OUT ADC OUT DVI IN 3 DVI IN 4 USB OUT

4 USB INPUTS

REMOTE -

RJ-45 Connecter

For RMT-4 Wired

Remote

AUDIO IN 1 AUDIO IN 2 AUDIO IN 3 AUDIO IN 4 AUDIO OUT

Connect your computers DVI, USB, and audio to the 4x1 DVI/ADC Switcher inputs

using the supplied cables.

Connect your DVI or ADC monitor to the DVI Out or ADC Out.

Connect your USB and audio devices to the USB and audio outputs.

Connect the RMT-4 remote control (if applicable).

Plug the 24v power supply into the 4x1 DVI/ADC Switcher.

Your computers must be turned on one at a time and the switcher must be selected

to the computer that is booting up. After one computer completes the startup process,

you can boot up the second computer and repeat the process with the remaining

computers.

HOW TO CONNECT THE 4X1 DVI/ADC SWITCHER

RMT-4IR

1. Remove battery cover from the back of the RMT4-IR remote.

2. Verify that dip switches 1 & 2 are in the down (OFF) position.

3. Insert the battery, hold the battery so that you can see the positive side facing up. The

side that is not marked must be facing down.

4. Test the RMT4-IR remote by pressing ONLY one button at a time. The indicator light

on the remote will ﬂash once each time you press a button. WARNING: Do not press

multiple buttons simultaneously and do NOT press buttons rapidly. These actions will

cause the remote to reset and steps 1-4 will have to be repeated.

Note: The RMT4-IR ships with two batteries. One battery is required for operation, the

second battery is complimentary.

4X1 DVI/ADC WIRING DIAGRAM

Video Ampliﬁer Bandwidth ................................................................................. 1.65 GHz

Single Link Range ......................................................................................... 1920 x 1200

Vertical Frequency Range ....................................................................................... 60 Hz

DVI Input/Output Connector Type ............................................................................. DVI-I

ADC Output Connector .................................................................................... JAE 31 pin

USB Input Connector .......................................................................................... Type “B”

USB Output Connector ........................................................................................ Type “A”

Power Consumption ................................................................................ 60 Watts (max.)

Power Supply ........................................................................................................ 24VDC

Dimensions ...................................................................................... 17”W x 1.75”H x 4”D

Rackmountable .......................................................................................... 1 Rack Space

Shipping Weight ..................................................................................................... 10 Lbs

SPECIFICATIONS
