Geemarc T-LOOP Manual de usuario

CONTENTS 2

INTRODUCTION 3

Unpacking the t-LOOP 4

INSTALLATION

Setting Up 5

Low Batteries 5

USING THE t-LOOP 6

TROUBLESHOOTING 8

SAFETY INFORMATION 9

GUARANTEE 10

RECYCLING DIRECTIVES

CONTENTS

Congratulations on purchasing your Geemarc t-LOOP ampliﬁed

powered neckloop from Sound SolutionsTM. The Geemarc t-LOOP

can be used with cellular or landline telephones together with a

hearing aid that has a t-coil. The Geemarc t-LOOP can also be used

as an ampliﬁed audio neckloop for a variety of audio devices using

the 2.5mm to 3.5mm adapter provided.

This neckloop uses an induction loop system which helps people

who use a hearing aid to hear sounds more clearly because it

reduces or cuts out background noise. The Geemarc t-LOOP

transforms the sound emitted by an telephone/audio device into an

acoustic ﬁeld compatible with hearing aids set to the T position.

Simply plug the neckloop into your telephone and you can make and

receive calls as normal without needing to hold the telephone. The

microphone in the Geemarc t-LOOP allows you to speak directly to

the caller.

Note: users of digital hearing aids must make sure their aids

have been programmed for use with the ‘T’ setting.

This neckloop can be used with telephones equipped with a 2.5mm

microphone/headset socket (Geemarc products such as AMPLI

Dect, CL200, 400, 600, 1400 are good examples). It is also com-

patible with most mobile telephones (you may need to purchase a

connector if your cellular telephone does not have a suitable 2.5mm

headset socket).

Its is important that you read the instructions below in order to use

your Geemarc t-LOOP to its full potential. Keep this user guide in a

safe place for future reference.

INTRODUCTION

Unpacking the Geemarc t-LOOP

When unpacking the Geemarc t-LOOP, you should ﬁnd the follow-

ing in the box:

• 1 Neckloop and neckloop unit

• 2.5mm telephone connector plug

• 2 AAA 1.5V alkaline batteries

• 2.5mm to 3.5mm adapter

• 1 User Guide

INSTALLATION

Setting Up

NOTE: Ensure your telephone equipment is UL/ETL approved

before connecting the Geemarc t-LOOP. Please refer to your tele-

phone user guide.

Open the battery compartment found on the back of the Geemarc t-

LOOP. Insert the 2 supplied alkaline batteries (AAA size, 1.5V type)

into the battery compartment. Check the battery polarity diagrams

in the battery compartment when inserting the batteries. Replace

the battery cover.

Note: The Geemarc t-LOOP must not be connected to the telephone

when installing the batteries.

Do not use rechargeable batteries. Do not put batteries into the

household rubbish, pay attention to battery regulations regarding

battery disposal.

Low Batteries

The low battery indicator will turn red to indicate the batteries should

be changed. The indicator will only turn red while in use. Replace

the batteries as soon as possible.

USING THE GEEMARC t-LOOP

Making and Receiving Calls

Place the wire around your neck. Insert the round connector plug

into the Neckloop Quick Disconnect plug; this forms a loop around

your neck. Ensure you have double clicked the connection.

Connect the 2.5mm plug of the Geemarc t-LOOP into the telephone’s

2.5 mm headset jack

Switch your hearing aid to T (or MT) mode.

Press the ON/OFF button; you are ready to speak through your

Geemarc t-LOOP. The green light will turn on.

Make and receive calls as normal (refer to telephone user guide)

The volume of the Geemarc t-LOOP can be adjusted by using the

volume control knob found on the bottom of the Geemarc t-LOOP.

This gives up to 30 dB gain.

Press the ON/OFF button when the call is ﬁnished. The green light will turn off.

Reset your hearing aid if necessary.

Do not forget to turn OFF your Geemarc t-LOOP at the end of

the call. Failure to do this will drain the batteries after about 30

hours.

Note: The Geemarc t-LOOP has a built in microphone hence you

do not need to hold the telephone to your ear. Instead, you can use

it with a belt clip or place it on a ﬂat surface such as a table.

If your telephone does not have a 2.5mm jack, you may need an

adapter. Check with the telephone manufacturer.

USING THE GEEMARC t-LOOP

Using as a Personal Audio Neckloop

The Geemarc t-LOOP can be converted easily to a 3.5mm ampliﬁed

Audio Neckloop. Simply plug the 2.5mm end of Geemarc t-LOOP

into the 2.5mm to 3.5mm adapter provided, then insert the adapter

into your device with a 3.5mm audio jack e.g. a CD player, MP3 or

any device that has an 8-16 Ohm audio output through a 3.5mm

jack.

Note: Only use the adapter supplied when connnecting the Gee-

marc t-LOOP to an audio device.

The Geemarc t-LOOP is compatible with cell phones that provide

stereo music. In order for the Geemarc t-LOOP to work, you must

use an adapter that converts the 2.5mm connector on the cell

phone to function as standard mono connector. You can get these

adapters from your cell phone manufacturer. You will need to need

to check that the 2.5mm connector on the cell phone will work with a

standard mono hands-free headset such as the Geemarc t-LOOP.

The LED is Red

• Change the batteries

There is no sound from my Geemarc t-LOOP

• Ensure the headset is securely plugged in

• Ensure the volume is correctly adjusted

• Ensure the batteries are not flat

• Ensure the batteries are inserted correctly

• Ensure the Geemarc t-LOOP is switched on

• Ensure the telephone is switched on

There is a weak sound from my Geemarc t-LOOP

• The batteries may be running out

• Turn up the volume on the Geemarc t-LOOP

• Turn up the volume on the telephone

• Check your hearing aid

TROUBLESHOOTING

General

Do not open the unit. Contact the helpline for all repairs.

Avoid dropping the unit.

Keep the Geemarc t-LOOP out of small children’s reach.

Cleaning

Clean the Geemarc t-LOOP with a soft cloth. Never use polishes

or cleaning agents - they could damage the ﬁnish or the electrics

inside.

Environmental

Do not expose to direct sunlight.

Always ensure there is a free ﬂow of air over the surfaces of the

Geemarc t-LOOP

Do not place any part of your product in water and do not use it in

damp or humid conditions e.g. bathrooms.

Do not expose your product to ﬁre or other hazardous conditions.

If the Geemarc t-LOOP is not in use do not store it with batteries

installed for an extended length of time.

Avoid using the telephone during electrical storms as there is a

remote risk of receiving an electric shock from lightning.

If you suspect a gas leak in the area do not use the telephone. The phone’s

electrical contacts could create a spark, which could ignite leaking gas.

SAFETY INFORMATION

Sonic Alert warrants the device against any defect in materials or

workmanship for the period of one year from the date of purchase.

Should you experience a problem, contact our customer service

department

Be sure to save your sales receipt as proof of purchase date should

you need warranty service.

Within a period of one year from purchase date, Sonic Alert will

repair or replace (our discretion) your device at no cost, if a defect

in materials or workmanship is found. If we elect to replace your

device , we may replace it with a new or reconditioned product of

the same or similar design.

Repair or replacement will be warranted for a period of 90 days or

the original time on the original warranty, whichever is longer.

The warranty does not cover accidents, negligence or breakage to

any parts. This includes shipping damage, failure to follow instruc-

tions, misuse, ﬁre, ﬂoods, use of incompatible accessories, Acts

of God or failure in your device service carrier’s line service. The

product must not be tampered with or taken apart by anyone who

is not an authorized

Sonic Alert representative. Tampering with the phone will void ant

written or implied warranties

Sonic Alert shall not be responsible for loss of time, inconvenience

, property damage caused by your device or any other accidental

or consequential damages

Warranty service is available only with proof of purchase

GUARANTEE
