GE CWLSWDMBWF1 Manual de usuario

™

Wire-Free

Smart Switch

Installation Guide

Models

CWLSWDMBWF1

CWLSWCCBWF1

Download

the C by GE app

Install

your Smart

Switch

Add

your Wire-Free

Smart Switch to the

C by GE app

Simple DIY Setup

Compatibility Requirements

Works with C by GE Smart Lights, Plugs, Switches, and Sensors.

Not compatible with non-C by GE Smart devices.

NOTE: Switch and other C by GE lights, plugs, and

switches must be grouped in the same Room/Space in

the C by GE app to enable full room control.

Let’s Do It

INCLUDED

YOU’LL

NEED

OPTIONAL

Switch

Wall Plate 4 Phillips

Mounting Screws

Drywall

Anchors

Adhesive

Tape

Phillips Screwdriver

Drill w/ 7/32 bit Level

Tape Measure

You Got This!

And we’re here to help.

For in-depth instructional videos

and a guided tour through the installation,

go to cbyge.com/wirefree-support.

BEFORE YOU DO ANYTHING: Step 1

Location & Mounting Type

Decide how you want to mount your switch

This switch can be mounted to the wall in two ways, by screws or adhesive tape.

Once you determine which install method is best for you, select one of

the following setup methods.

IMPORTANT

Start by removing the clear plastic tab

from the back of the switch.

1. Identify where you want to mount your Wire-Free Switch (switches are

typically located 48-52” from the ﬂoor to the top of the switch).

2. Prior to installation, be sure that the surface is smooth and degreased.

3. Apply adhesive tape to the middle back of the switch. Adhesive tab

should stick out from the side of the switch. This will be covered by

the wallplate and allows removeal if needed in the future.

4. Mount switch to the wall.

5. Screw on the faceplate bracket, then snap the faceplate cover

onto the bracket.

STEP 2 - Mounting with adhesive tape

Installing Your Switch

STEPS 1 & 2

STEPS 3, 4 & 5

IMPORTANT

Start by removing the clear plastic tab

from the back of the switch.

1. Identify where you want to mount your Wire-Free Switch (switches are

typically located 48-52” from the ﬂoor to the top of the switch).

2. Mark the location for holes to be drilled. We suggest using the

mounting holes on the switch housing as a guide. Use the level (optional)

to ensure the switch is level before drilling holes.

3. Using 7/32” bit, drill holes in wall for mounting screws.

Insert drywall anchors.

4. Secure the switch to the wall until level and ﬂush.

5. Screw on the faceplate bracket, then snap the faceplate cover

onto the bracket.

STEP 2 - Mounting with screws/single-gang wallplate

Installing Your Switch

STEPS 1 & 2 STEPS 3

STEPS 4 & 5
