For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

PD900DP

GE Profile™ 30" Drop-In Electric Range

Note: Cabinets installed adjacent to slide-in ranges must have an

adhesion spec of at least 194° temperature rating.

Note: To reduce possibility of scorching the side walls above the

countertop when no load is present on burners, it is recommended

that a minimum of 6" spacing from adjacent side wall be allowed for

possible extended, high-heat, element operation.

IMPORTANT:

30" DROP-IN RANGES ARE DESIGNED TO HANG

FROM THE COUNTERTOP. IT DOES NOT REST ON THE FLOOR.

FOR INSTALLATION ALTERNATIVES, REFER TO INSTALLATION

INSTRUCTIONS PACKED WITH PRODUCT.

Optional Kits For Drop-In Electric Ranges (Available At Additional Cost)

Installation information: Before installing, consult installation

instructions packed with product for current dimensional data.

Accessory Backguards

(Attaches to the back of range

as a backguard when unit is installed

in 30" free-standing cutout)

JXS32SS (Stainless) - 4" High

JXS32WW (White) - 4" High

JXS32BB (Black) - 4" High

JXS37WW (White) - 5-1/4" High

JXS37CC (Bisque) - 5-1/4" High

JXS37BB (Black) - 5-1/4" High

Rear Filler Strip

WB07T10680 - Black Filler Strip Assembly

WB07T10681 - White Filler Strip Assembly

WB07T10682 - Bisque Filler Strip Assembly

Specification Created 5/09 220804

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Listed by

Underwriters

Laboratories

Dimensions and Installation Information (in inches)

KW Rating

240V 11.6

208V 8.7

Breaker Size

240V 40 Amps

208V 40 Amps

Acceptable Electrical Outlet

Area Also In Adjacent

Cabinet Or Under Floor

Conduit is 40" long

30" Min.

15" Min.

6" Min.

from walls

7-1/2

2-7/8"

To Front Surface

of Countertop

27-1/2 25

23-3/16

If necessary,

build upsides

to 1-1/4" thick

to provide

countertop

support

20-5/8" Door

Clearance

From Front

Surface of

Countertop

31-1/4

A/B*

Accessory

Backguard

26-1/2** *JXS37 is 5-1/4" and JXS32 is 4"

(excluding handle)

**Total depth from wall to

front of closed oven door

including handle is 29-1/2.

Acceptable Electrical Outlet

Area Also In Adjacent

Cabinet Or Under Floor

Conduit is 40" long

30" Min.

15" Min.

6" Min.

from walls

7-1/2

2-7/8"

To Front Surface

of Countertop

27-1/2 25

23-3/16

If necessary,

build upsides

to 1-1/4" thick

to provide

countertop

support

20-5/8" Door

Clearance

From Front

Surface of

Countertop

31-1/4

A/B*

Accessory

Backguard

26-1/2** *JXS37 is 5-1/4" and JXS32 is 4"

(excluding handle)

**Total depth from wall to

front of closed oven door

including handle is 29-1/2.

PD900DP

GE Profile™ 30" Drop-In Electric Range

Features and Benefits

• Self-cleanOven-Self-cleanallowsyoutospareyourselffromthetroubleand

effort it takes to scrub the oven interior. The oven does all the work!

• ElectronicOvenControls-Electronicpadsonthecontrolpanelareeasyto

operate with just a touch

• PowerBoil™Element - Accommodates various-size pots or pans and 3,000 watts

of power speeds the broiling process

• Extra-largeOvenCapacity-Enoughroomtocookanentiremealatonce

•  T r u e T e m p ™Oven System - This feature helps ensure the temperature you set is

the temperature you get, with less variance, to give you the baking and broiling

performance you desire

• RibbonHeatingElements-Powerfulheatbeneaththesmoothsurfaceprovides

high-speed warm-up and even heating

• CeramicGlassCooktop-Asmoothcooktopsurfacemakescleaningquick

and easy

• Six-passBakeElement-Onecontinuousheatingelementdeliversevenheating,

unparalleled baking and evenly cooked food

• WarmMode-Helpskeepjust-cookedfoodswarmandattheideal

serving temperature

• ProofMode-Gentlycirculate100˚Fairallowsdoughtorisequicklyandefficiently

• ModelPD900DPWW-Whiteonwhite(whitedoorandpatternedblackcooktop)

• ModelPD900DPCC-Bisqueonbisque(bisquedoorandpatternedblackcooktop)

• ModelPD900DPBB-Blackonblack(blackdoorandblackpatternedcooktop)

Specification Created 5/09 220804
