JB905SH/TH/KH/BH – GE Profile

™

30" Free-Standing CleanDesign Electric Range

Specification Revised 9/04

221098

Dimensions (in inches)

2-1/2

7-1/2

29-7/8

25-3/8

47-5/8

46-7/8

2-1/2

Acceptable electrical

outlet area

Preferred electrical

outlet area

Roughed-in dimensions

Electrical outlet locat ABC.eps

†

Note:

Check local codes for required breaker size.

Effective January 1, 1996, the National Electrical Code requires that new construction (not existing)

utilize a 4-conductor connection to an electric range.

Receptacle Locations

Locally approved flexible service cord or conduit must be used because terminals are not accessible

after range installation. See shaded area in drawing for location of electrical outlet box. Recommended

outlet locations allow range to be installed directly against wall.

Note:

30" ranges conform to U.L. requirements for 0" spacing from adjacent walls below countertops.

To reduce possibility of scorching walls, engineering recommends a minimum of 1-1/2" spacing to

allow for possible extended, high-heat, no-load heating element operation.

Installation Information:

Before installing, consult installation instructions packed with product for

current dimensional data.

*Dimension from wall to front of closed door handle is 27-3/8

46-1/2

KW Rating

240V

11.6

208V

Breaker Size

40 Amps

†

Listed by

Underwriters

Laboratories

For answers to your Monogram

GE Profile

™

appliance questions, visit our website at

.com or call GE Answer Center

service,

800.626.2000.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

JB905SH/TH/KH/BH – GE Profile

™

30" Free-Standing CleanDesign Electric Range

Specification Revised 9/04

221098

JB905SH

Features and Benefits

• Self-Cleaning Oven – Conveniently cleans the oven cavity without the need for scrubbing.

• Super Large Oven Capacity – Provides an impressively large oven interior for cooking more

dishes and large meals at one time.

• TrueTemp

™

System – Delivers even heat distribution and maximum oven control.

• QuickSet VI Glass Touch Oven Controls – Features an easy to use design that allows you

to set precise cooking temperatures.

• Dual Size Ribbon Element – Offers a convenient choice of using a 6" or 9" heating element,

depending on the size of the pan.

• Warming Zone – Provides low heat capability for foods, making meal coordination simple.

• Ceramic Glass Cooktop – A smooth cooktop surface makes cleaning quick and easy.

• Model JB905SHSS – Stainless steel with black accents

• Model JB905THWW – True white (white door and true white cooktop)

• Model JB905KHCC – True bisque (bisque door and true bisque cooktop)

• Model JB905BHBB – Black on black (black door and black patterned cooktop)
