GE SpacemakerXL JVM1340AW Guía del usuario

GE Appliances

JVM1340AW—GE SpacemakerXL Microwave Oven

Dimensions (in inches)

Revised 3/96

R

Listed by

Underwriters

Laboratories

Note: Requires 120V grounded outlet. Electrical receptacle must be

located in cabinet above SpacemakerXL microwave oven. No additional

wiring, venting or cabinet rebuilding necessary in many cases. Complete

detailed, easy-to-follow installation instructions and convenient full-size

templates are packed with the SpacemakerXL microwave oven.

Important Information: When installing the SpacemakerXL

microwave oven over a range, allow minimum of 2" from bottom of

SpacemakerXL microwave oven to top of range backguard to allow

for removal of light covers.

Ventilation Options: The SpacemakerXL microwave ovens are designed

for adaptation to the following three types of ventilation:

• Outside exhaust (vertical—as shown)

• Outside exhaust (horizontal)

• Recirculating (non-vented ductless—see Filter Kit drawing)

Installation Information: This information is not intended to be used for

installing unit described. Before installing, consult installation instructions

packed with product/kit for current dimensional data.

21-3/4"

Door open

16-1/2

66" MIN.

Mounting

height

from

floor

30"

MIN.

width 

required

MAX.

Exhaust outlet

connects to

3-1/4" X 10" duct

12"



16-1/4

For answers to your GE Monogram,™GE Profile,™

GE, Hotpoint and RCA appliance questions, call

GE Answer Center®service, 800.626.2000.

GE Appliances

Revised 3/96

JVM1340AW—GE SpacemakerXL Microwave Oven

Optional Accessories (Available at additional cost)

R

Listed by

Underwriters

Laboratories

Filler Panel Kits

JX40AL—Almond

When replacing a

36" or 42" range

hood, this kit fills in

the additional width to

provide a custom,

built-in appearance. For

installation between cabinets

only; not for end-of-cabinet

installation. Each kit contains

two, 3"-wide filler panels.

Two kits are needed

for a 42" opening.

Filter Kits

JX81A—Recirculating Charcoal Filter Kit

To be used when the SpacemakerXL

microwave oven cannot be vented to

the outside.

JX22SS—Stainless Steel Decorative

Panel Kit

When replacing a Hi/Low range with a

SpacemakerXL microwave oven over a

range model, this panel kit fills in the

area between the microwave and

range left by the Hi/Low model.

Optional Accessories

Recirculating Charcoal Filter Kit JX81A

Filler Panel Kit JX40AL

Decorative Panel Kit JX22SS

For answers to your GE Monogram,™GE Profile,™

GE, Hotpoint and RCA appliance questions, call

GE Answer Center®service, 800.626.2000.

Revised 3/96

JVM1340AW—GE SpacemakerXL Microwave Oven

Features and Benefits

•Almond on almond Model

•1.3 cu. ft. Oven Cavity

•900 Watts*

•CircuWave™Plus Cooking System

•Turntable On/Off

•SmartControl System With Interactive Display

•Help Pad

•Convenience Cooking Controls For Popcorn, Beverage,

Reheat, Snacks and Cook Pads

• Dual Rack

•Temp Cook/Roast

•Micro Cook I & II

•Auto Defrost/Time Defrost

•Express Cook

•Add 30 Seconds

•Instant On Controls

•Timer On/Off

•Child Lock Out

•Beeper Volume Control

•Programmable Nite Light

•Also Available In Black on black as Model JVM1340BW

and White on white as Model JVM1340WW

*IEC-705 Test Procedure

GE Appliances
