WARNINGS
THE FOLLOWING INSTRUCTIONS ARE INTENDED FOR AUTHORIZED
GCOM SYSTEMS INSTALLERS ONLY.
PROFESSIONAL INSTALLATION BY AUTHORIZED GCOM RETAILER
REQUIRED TO BE COVERED UNDER WARRANTY.
Dropping your EV486ACT unit or subjecting it to excessive shock and vibrations
as this may cause it to malfunction and is not covered by warranty.
The EV486ACT unit IS NOT WATERPROOF. Avoid exposing it to rain or other
forms of excessive moisture. Water damage is not covered under the
warranty.
RED- Accessory
Black- Chassis Ground
Green- Not Used as Video On/Off Switching is Trigger by Video Signal Voltage
Temp. Sensor 1-Interior Temperature Sensor (8 feet)
Temp. Sensor 2-Exterior Temperature Sensor (14 feet)
VIDEO Camera RCA- Video input for camera (priority). The circuit switches
automatically when video is sensed by powering up the reverse camera
VIDEO IN RCA- AUX Video input (DVD, MP4 etc.) This circuit is secondary and so it will
be over written when Camera video is sensed.
Reassemble all above covers and make connections at knee bolster.
1) Connect the camera’s 12V and GND wire to reverse tail lamp.
2) Connect the camera’s RCA to the mirror’s Camera input
3) Connect the EV486ACT 12V+ wire to the vehicle’s ACC wire.
4) Connect the EV486ACT ground wire (BLACK) to chassis GND
1) Remove existing mirror from vehicle.
2) If existing mirror tab is D-tab style mount EV486ACT mirror to windshield and
go to step 3. If original mirror is not D-tab style or headliner mount go to step
2a.
2a) Locate the supplied D-tab and the rearview mirror adhesive and install on
windshield as per adhesive instructions.
Note: DO NOT ATTEMPT TO REMOVE THE EXISTING TAB AS DAMAGE TO THE
WINDSHIELD MAY OCCUR
3) Remove the knee bolster on the driver side as well as the A-pillar cover (it may
