Gator GHDVR370 Manual de usuario

Resolution

1080P

Full

Screen Size

2.3”

120

Wide Angle Super

Capacitor

G Sensor Suction

Mount

Manual

GHDVR370

FULL HD 1080P

DaSH cam +

GPS TRaCKING

Introduction

Product features

Product overview

FULL HD 1920 x 1080 @ 30FPS

2.3" 4:3 High-resolution LCD screen

120 Degree HD wide angle lens

GPS Tracking (Windows OS Software included)

Super capacitor works in extreme temperature &

saves last recording once power is disconnected

Suction car mount with 360 degree rotation

G-Sensor function

12Vin-car USB charger

8GB Micro SD card included

Supports Micro SD card class10 up to 32GB

Mini USB interface

Seamless cycle loop recording

Thank you for purchasing the Gator GHDVR370 FULL HD 1080P Dash

Cam. Please ensure that you have read the product manual and

instructions in full, prior to installation and use. Failure to do so may

result in product failure/damage or incorrect operation and therefore

impact the product performance.

The Gator GHDVR370 Dash Cam has been designed to provide high

definition recordings of your trips for security and evidence in the case

of an accident. The built in GPS allows for recording position, route

taken and speed.

The Dash Cam simply mounts to the windscreen and records footage

onto a Micro SD memory card.It has a G-sensor with adjustable

sensitivity and loop recording functionality.

Table of Contents

Introduction 2

Package components 4

Product structure 5

Installation of Dash Cam 6

Indicator lights 7

Dash Cam menu

Video Menu Settings

Resetting Dash Cam

Product specifications

Infringement of copyright warning

Product overview

Product features

Table of contents

Video/Photo playback

Formatting the SD Card

Safety information & warnings

Technical assistance

Fixing the Dash Cam

Tools Menu Settings 11

Photo Menu Settings 12

13Locking Footage (SOS)

13Microphone Recording

13Connecting to a PC

14GPS Player

17Trouble shooting guide

Video and photo operation

Powering your Dash Cam

Package components

GHDVR370 Mounting

Bracket

USB to Mini USB Car Charger

GHDVR370

User Manual

Micro SD

Card

INCLUDED

8GB

Product structure

4 7

1) Mounting Slot

2) Power Indicators

3) LCD Screen

4) Menu/Return

5) Up

6) Down

7) OK Button

8) Lens

9) GPS Antenna

10) Mic

11) Speaker

12) Reset

13) Mini USB port

14) HDMI port

15) Power/Lock Button

16) Micro SD Card Slot

5 6 10 11

Installation of Dash Cam

1. Ensure windscreen is clean and free of debris. Attach suction cup to

the windscreen and lock into position with the lever.

2. Fix where the vision is not blocked (Place close to rear-view mirror

is recommended). Don't install device on airbag or within its working

range.

3. Insert Micro SD card into the Dash Cam

4. Insert Mini USB end of the 12V power adapter into the Mini USB

interface/ charging point of the Dash Cam. Connect socket end of the

adapter into the into 12V power socket of vehicle.

5. Adjust the mounting bracket and rotate the camera direction to get

the best view. Ensure of the vehicles bonnet is visible from the

bottom of the screen for alignment.

6. Turn vehicles ignition to accessories, and the Dash Cam will power

ON and start recording automatically, you will hear an audible tone

once powered.

7. The blue power indicator LED will show when the Dash Cam is

receiving power.

8. A red circle on screen will start flashing when recording has started.

9. For the Dash Cam to work it must receive power from the charging

adapter. Once power is removed or turned off the Dash Cam will save

the current file and turn off.

ATTENTION:

The Dash Cam must be connected to power when in use. The super

capacitor only holds date and time settings. The Dash Cam has no

internal battery.

Suggested

Indicator lights

Fixing the Dash Cam

1. The blue power indicator LED lights up and the charge symbol on

screen flashes when the Dash Cam is receiving power.

2. One of the blue indicators flashes when the Dash Cam is recording.

Press the power button to turn the Dash Cam on. It will automatically

start recording once it receives power. When power is turned off

manually or power is removed, the Dash Cam will save the current file

and turn off.

Powering your Dash Cam

Video time

SOS locked leHDR mode

Video mode

Microphone

Exposure

Compensation

Loop rec time Resolution

SD Card

Battery

Camera Shake

TimeDate

There is a camera icon at the top left corner of the LCD to signify you are

on video mode. When the Dash Cam is recording, a red circle indicator

appears and flashes on the top left corner of the screen. To stop the

recording, simply press the OK button. To resume press recording press

OK button. Press/Unpress Menu/Return button to Lock/Unlock recorded

video.

Press the power button to switch the Dash Cam to photo mode. There is a

camera icon at the top left corner of the LCD to signify you are on photo

mode. To take a photo, press the OK button. The screen will flash and

make a camera sound when a picture is taken.

Video Mode

Photo Mode

Photos remainingCamera mode

ISO

White Balance

Exposure

Compensation Image resolution

SD Card

Battery

Video and photo operation

Playback mode

icon

Playback mode

icon

Press the power button until you see the playback icon on the top left

of the screen. Using the arrow buttons, you can choose between all

your recorded videos or photos. The protected files have a lock icon

meaning they cannot be deleted until unlocked. Press the OK button

to select a file for playback. Pressing the return button once will give

the option to delete, protect or unlock the file. Pressing the return

button twice will open video/photo settings. Press OK button to initiate

changes. Press the return button again to exit and return to playback

mode screen.

Video Playback Screen

Photo Playback Screen

Video/Photo playback

Menu Settings

In video mode press the Menu (Return) button to get into the menu

settings when not recording. Press once for Video settings, twice for

Tool settings. You can navigate the settings menu by using the Up/Down

buttons. To change or edit a selected setting, press the OK button.

Press the menu button again to exit the menu settings.

Video Menu Settings

Resolution:

Resolutions are 1296P 1728x1296, 1080 FULL HD 1920x1080 or 720P

1280 x 720. The recommended resolution should be set at ‘1080 FULL

HD 1920x1080.

Loop Recording:

This feature allows you to set the size of the files your Dash Cam will

record before saving and creating a new file. It allows the Dash Cam to

record over the oldest recorded files once the card is full. This can be

turned OFF, or record 1,3 & 5 minute video files. If you want to keep any

of the files it is best to upload them to your computer. We recommend

the Dash Cam to be set to ‘3’ minute files

HDR:

High Dynamic Range is used to achieve greater exposure to dynamic

range than normal digital image technology and make video and pictures

look better.

Exposure:

This feature will change the light and dark balance of your photos. We

recommend it always be set at ‘0’.

Record Audio:

This Feature will allow you to turn the Dash Cam’s recording sound on

or off. If you want to stop the Dash Cam recording sound in the cab of

your vehicle, set this feature to ‘off’.

DASH CAM Menu
