Replacing the Gateway 450ROG Keyboard

www.gateway.com

Replacing the Gateway 450ROG

Keyboard

This package includes a replacement keyboard for your Gateway 450ROG

notebook and these printed instructions.

Tools you need

You need a small Phillips and a small flat-blade screwdriver to replace the

keyboard.

Preventing static electricity discharge

The components inside your notebook are extremely sensitive to static

electricity, also known as electrostatic discharge (ESD).

Warning ESD can permanently damage electrostatic

discharge-sensitive components in your notebook. Prevent

ESD damage by following ESD guidelines every time you

replace the keyboard.

Warning To avoid exposure to dangerous electrical voltages and

moving parts, turn off your notebook and unplug the power

cord and modem and network cables before opening the

case.

2www.gateway.com

Before replacing the keyboard, follow these guidelines:

■Turn off your notebook.

■Wear a grounding wrist strap (available at most electronics stores) and

attach it to a bare metal part of your workbench or other grounded

connection.

■Touch a bare metal surface on your workbench or other grounded object.

■Unplug the power cord and the modem and network cables.

■Remove the main and optional secondary batteries. For more information,

see “Changing batteries” in your user guide.

■Disconnect all peripheral devices and remove any PC Cards.

Before working with notebook components, follow these guidelines:

■Avoid static-causing surfaces such as carpeted floors, plastic, and packing

foam.

■Remove components from their antistatic bags only when you are ready

to use them. Do not lay components on the outside of antistatic bags

because only the inside of the bags provide electrostatic protection.

■Always hold components by their edges. Avoid touching the edge

connectors. Never slide components over any surface.

Warning To prevent risk of electric shock, do not insert any object

into the vent holes of the notebook.

Replacing the Gateway 450ROG Keyboard

www.gateway.com

Removing the keyboard

To remove the keyboard:

1Follow the instructions under “Preventing static electricity discharge” on

page 1.

2Turn off your notebook.

3Disconnect the AC adapter and modem and network cables.

4Turn your notebook over so the bottom is facing up.

5Remove the main and optional secondary batteries.

6Turn your notebook over so the top is facing up.

7Open the LCD panel to the normal viewing position.

4www.gateway.com

8Insert the small flat-blade screwdriver under the bottom right corner of

the keyboard bezel and gently pry it up.

9Pull the bezel off your notebook. You will hear small snapping sounds as

the bezel comes away from your notebook. Be careful not to break off the

tabs found on the left end of the bezel.

Important Inserting a piece of cloth between the screwdriver and

keyboard and notebook case will help prevent damage to

your notebook.

Replacing the Gateway 450ROG Keyboard

www.gateway.com

10 With a small Phillips screwdriver, remove the four keyboard screws and

put them in a safe place.

Screws

6www.gateway.com

11 Raise the back edge of the keyboard, then slowly rotate it toward you so

it lies keys-down on top of your notebook. Be careful not to damage the

LCD panel.

Replacing the Gateway 450ROG Keyboard

www.gateway.com

12 Lift the keyboard connector using two fingers. Be careful not to touch or

damage any other components.

8www.gateway.com

Installing the keyboard

To install the keyboard:

1Place the new keyboard keys-down on your notebook with the space bar

away from you.

2Insert the keyboard plug, on the end of the keyboard cable, onto the

keyboard connector.

3Rotate the keyboard toward the LCD panel until the keyboard is

almost face-up.

Important The outside of the keyboard plug goes around the

keyboard connector. The plug is correctly oriented if the

cable is not twisted.

Replacing the Gateway 450ROG Keyboard

www.gateway.com

4Insert the tabs on the front of the keyboard under the palm rest.

5Gently press the keyboard down until it is flat all the way across. The

keyboard should easily fall into place. Be careful not to damage the

LCD panel.

6Replace the four keyboard screws.

Ta b s

Screws

10 www.gateway.com

7Slide the two tabs on the left end of the bezel under your notebook frame.

8Press down on the bezel in several places until it clicks in place.

The bezel is correctly mounted when you can run you finger along the

bezel and find no loose spots. The bezel should be flat all the way across.

9Replace the main and optional secondary batteries.

10 Connect the power adapter and modem and network cables, then turn on

your notebook.

Technical Support

See your user’s guide for Gateway Technical Support information.

Safety, Regulatory, and Legal Information

See your user’s guide for important safety, regulatory, and legal information.

black-and-white spot design are trademarks or registered trademarks of Gateway, Inc. in the United States and

other countries. All other brands and product names are trademarks or registered trademarks of their respective

companies.

Warning If the bezel is not correctly replaced, your notebook could

be damaged when you try to close the LCD panel.
