eTrex®

quick start manual

for use with models 20 and 30

2 eTrex20/30QuickStartManual



‹



See the Important Safety and Product

Information guide in the product

box for product warnings and other

important information.

When using your device the rst time,

you should complete these tasks to set

up the device and get to know the basic

features.

1. Install the batteries (page 3).

2. Turn on the device (page 4).

3. Register the device (page 4).

4. Acquire satellites (page 4).

5. Calibrate the compass (page 5).

6. Mark a waypoint (page 6).

7. Create a route (page 7).

8. Record a track (page 7).

9. Navigate to a destination (page 8).



➊

➎

➍➌

➋

➊

Zoom keys

➋

Back key

➌

Thumb Stick

™

➍

Menu key

➎

Power and backlight key

eTrex20/30QuickStartManual 3

➏

➒

➑

➐

➏

Mini-USB port (under weather cap)

➐

Battery cover

➑

Battery cover locking ring

➒

Mounting spine



‹



The temperature rating for the device

(-4°F to 158°F, or -20°C to 70°C)

may exceed the usable range of some

batteries. Alkaline batteries can rupture

at high temperatures.

notice

Alkaline batteries lose a signicant

amount of their capacity as temperature

decreases. Therefore, use lithium

batteries when operating the device in

below-freezing conditions.

The device operates on two AA

batteries.



You can use alkaline, NiMH, or

lithium batteries. Use NiMH or lithium

batteries for best results.

1. Turn the D-ring counter-clockwise,

and pull up to remove the cover.

4 eTrex20/30QuickStartManual

2. Insert the batteries, observing

polarity.

3. Replace the battery cover, and turn

the D-ring clockwise.

4. Hold (page 2).

5. Select  >  > 

.

6. Select , , or

.





Hold (page 2).



• Go to http://my.garmin.com.

• Keep the original sales receipt, or a

photocopy, in a safe place.



After the device is turned on, it begins

acquiring satellite signals. The device

may need a clear view of the sky to

acquire satellite signals. When the GPS

bars on the backlight page (page 4) are

solid green, your device has acquired

satellite signals. The time and date are

set automatically based on the GPS

position.

For more information about GPS, go to

www.garmin.com/aboutGPS.



: The backlight brightness may

be limited when the remaining capacity

in the batteries is low.

Extensive use of screen backlighting

eTrex20/30QuickStartManual 5

can signicantly reduce battery life.

1. While the device is on, press .

2. Move the Thumb Stick left and

right to adjust the brightness level.



notice

Calibrate the electronic compass

outdoors. To improve heading

accuracy, do not stand near objects that

inuence magnetic elds, such as cars,

buildings, or overhead power lines.

The eTrex 30 has a 3-axis, electronic

compass.

You should calibrate the compass after

moving long distances, experiencing

temperature changes, or changing the

batteries.

1. Select .

2. Select .

3. Select  > .

4. Follow the on-screen instructions.



Proles are a collection of settings that

optimize your device based on how

you are using it. For example, your

settings and views can be different

when you are using the device for

geocaching and for navigating on

water.

1. Select .

2. Select a prole.



Waypoints are locations you record and

store in the device.

6 eTrex20/30QuickStartManual



You can save your current location as

a waypoint.

1. Select .

2. Select an option:

• To save the waypoint without

changes, select .

• To make changes to the

waypoint, select an attribute,

make changes to the attribute,

and select .



1. Select  > .

2. Select a waypoint.

3. Select .





Waypoint averaging allows you to

increase the accuracy of a waypoint

location by collecting multiple samples

of the waypoint location.

1. Select .

2. Select a waypoint.

3. Move to the location.

4. Select .

5. When the Sample Condence status

bar reaches 100%, select .

For best results, collect four to

eight samples for the waypoint,

waiting at least 90 minutes between

samples.



You can use the Where To? menu to

nd a destination to navigate to. Not all

Where To? categories are available in

all areas and maps.



Depending on the maps loaded on

your device, you can search for cities,

geographic points, and various points

of interest (POIs), such as restaurants,

hotels, and auto services.

eTrex20/30QuickStartManual 7

1. Select .

2. Select .

3. Enter the name or part of the name.

4. Select .



A route is a sequence of waypoints that

leads you to your nal destination.

1. Select   > 

 > .

2. Select a category.

3. Select the rst point in the route.

4. Select .

5. Repeat steps 2–4 until the route is

complete.

6. Select  to save the route.



A track is a recording of your path.

The track log contains information

about points along the recorded path,

including time, location, and elevation

for each point.



1. Select  >  > 

.

2. Select ,  or

, .

If you select , 

, a line on the map indicates

your track.

3. Select .

4. Select an option:

• To record tracks at a variable

rate that creates an optimum

representation of your tracks,

select .

• To record tracks at a specied

distance, select .

• To record tracks at a specied

time, select .

5. Select  .

8 eTrex20/30QuickStartManual

6. Complete an action:

• Select an option to record tracks

more or less often.

: Using the 

interval provides the most track

detail, but lls up the device

memory quicker.

• Enter a time or distance, and

select .

As you move with the device turned

on, a track log is created.





You can navigate to a destination using

the map or compass.

1. Select .

2. Select a category.

3. Select a destination.

4. Select .

The map page opens with your

route marked with a magenta line.

5. Navigate using the map (page 8) or

compass (page 8).



1. Select .

The position icon represents your

location on the map. As you travel,

the position icon moves.

2. Complete one or more actions:

• Use the Thumb Stick to move

the map to different areas.

• Select ▲ and ▼ to zoom in and

out of the map.

: To customize the map view, select

 > , and adjust the

settings.





The eTrex 30 has a 3-axis, electronic

compass.

eTrex20/30QuickStartManual 9

When navigating to a destination,

the bearing pointer points to your

destination, regardless of the direction

you are moving.

1. Begin navigation to a destination

(page 8).

2. Select .

3. Turn until points toward the

top of the compass, and continue

moving in that direction to the

destination.





1. Connect the USB cable to a USB

port on your computer.

2. Pull up the weather cap from the

mini-USB port.

3. Plug the small end of the USB

cable into the mini-USB port.

Your device and memory card

(optional) appear as removable

drives in My Computer on Windows

computers and as mounted volumes on

Mac computers.



1. Connect your device to a computer

(page 9).

2. Go to www.opencaching.com.

3. If necessary, create an account.

4. Sign in.

5. Follow the on-screen instructions

to nd and download geocaches to

your device.





If the device stops responding, you can

reset the device.

1. Remove the batteries.

2. Reinstall the batteries (page 3).

: This does not erase any of your

data or settings.

10 eTrex20/30QuickStartManual





1. Connect your device to a computer

(page 9).

2. Pull up the weather cap

from the

mini-USB port.

3. Plug the small end of the USB

cable into the mini-USB port.

4. Open the “Garmin” drive or

volume.

5. Open the \

folder or volume.

6. Double-click ..



Optional accessories, such as mounts,

maps, tness accessories, and

replacement parts, are available at

http://buy.garmin.com or from your

Garmin dealer.





• Go to www.garmin.com/support

and click  for

in-country support information.

• In the USA, call (913) 397.8200 or

(800) 800.1020.

• In the UK, call 0808 2380000.

• In Europe, call +44 (0)

870.8501241.
