7Attach the suction cup to the side of your boat.
8Align the transducer parallel with the water line.
Connecting and Stowing the Cables
CAUTION
Ensure that you connect the correct connector to the correct battery terminal.
Damage to the battery, device, or bodily harm may occur if the device is
improperly connected to the battery.
1Using the cables you inserted through the pass-through holes on the
portable mount, compare the divot on the cable connector to the keying on
the echo device ports to identify the correct port.
2Push the cable connector into the correct port until the connector is fully
seated.
3Repeat steps 1 and 2 until all of the cables are connected to the device.
4Slide the positive (red) connector onto the positive (red) terminal on the
battery.
5Slide the negative (black) connector onto the negative (black) terminal on
the battery.
6If necessary, wrap excess power cable around the open section on the
underside of the portable mount.
7If necessary, wrap excess transducer cable around the hooks on the side
of the handle on the portable mount.
Installing the Device
1Connect the power and transducer cables to the device.
2With the locking arm À in the upward position, place the echo device Á
into the swivel mount Â.
3Tilt the mount for the preferred viewing angle and press down on the
locking arm.
Placing the Portable Kit in the Bag
After you have assembled the portable kit mount, you can place it in the bag,
which makes it easier to carry and protects it from the elements. The bag
contains hooks that allow you to tether the bag to a seat on your boat.
1Place the battery in the open space behind the swivel mount.
2Slide two of the included hook and loop straps through the narrow slots
near the battery.
3Pull the straps under and around the bottom of the portable mount, and
wrap them tightly around the battery.
4Place the transducer into the open space next to the swivel mount.
5Place the portable kit in the bag.
6Wrap the flap of nylon found inside the bag around the handle of the
portable base and secure it to the opening flap.
7Pull the opening flap over the handle.
8Zip up the opening flap to close the bag.
Battery Information
Battery Warnings
Your GPS device uses a user-replaceable sealed lead acid battery. If these
guidelines are not followed, the battery may experience a shortened life span
or may present a risk of damage to the device, fire, chemical burn, electrolyte
leak, and/or bodily injury.
WARNING
• When storing the battery for an extended time, store within the following
temperature range: from 5° F to 104°F (from -15° C to 40° C).
• Do not operate the battery outside of the following temperature range:
from 5° F to 122° F (from -15° C to 50° C).
• Do not place the battery near objects that may cause sparks, flames, or
heat.
• Do not incinerate the battery.
• Keep the battery tightly closed.
• Do not use a sharp object to remove the battery.
• Do not disassemble, puncture, or damage the battery.
• Do not swallow, touch, or inhale the contents of an open battery. Avoid
contact with internal acid. Contact with internal acid may cause irritation or
severe burns. Irritation may occur to the eyes, respiratory system, and
skin. Flush with water at once if contact is made with acid.
• Do not submerge the battery and avoid contact with water.
• Do not short the battery terminals.
• Do not drop or throw the battery.
• Keep the battery away from children.
• Only replace the battery with the correct replacement battery. Using
another battery presents a risk of fire or explosion of the device or charger.
• Only charge the battery with the included charger.
• Do not charge the battery in an unventilated area.
• Store in a cool, dry, and well-ventilated area.
• Do not charge the battery in a gas-tight container.
• Do not leave the device exposed to a heat source or in a high-temperature
location, such as in the sun in an unattended vehicle. To prevent damage,
remove the device from the vehicle or store it out of direct sunlight.
• Do not use organic solvents or other cleaners other than recommended
chemical cleaners on the battery.
• Contact your local waste disposal department to dispose of the battery in
accordance with applicable local laws and regulations.
Charging the Battery
CAUTION
Ensure that you connect the correct connector to the correct battery terminal.
Damage to the battery, device, or bodily harm may occur if the device is
improperly connected to the battery.
Before you can charge the battery using the charger, you must disconnect the
echo device power cable from the positive and negative terminals on the
battery.
The battery is rechargeable and can be charged by connecting the battery to a
wall charger.
1Connect the positive connector on the wall charger onto the positive
terminal on the battery.
2Slide the negative connector on the wall charger onto the negative
terminal on the battery.
3Connect the wall charger to the wall outlet.
Battery Tips
• The life expectancy of a sealed lead acid battery can be extended by
recharging often and not completely discharging the battery.
• Sealed lead acid batteries slowly lose their charge while in storage. For
best results, charge the battery prior to use.
