Garmin GPSMAP 800 Series Instrucciones de instalación y funcionamiento

400/500 Series

GTS 8XX Interface

Pilot’s Guide Addendum

This manual reﬂects the operation of Software version 5.03 or later for 4XX series products and

6.03 for 5XX series products. Some differences in operation may be observed when comparing

the information in this manual to earlier or later software versions.

Garmin International, Inc., 1200 East 151st Street, Olathe, Kansas 66062, U.S.A.

Toll free: 800/800.1020 or 866/739.5687 Tel: 913/397.8200 Fax: 913/397.8282

Garmin AT, Inc., 2345 Turner Road SE, Salem, OR 97302, U.S.A.

Tel: 503/391.3411 Fax 503/364.2138

Garmin (Europe) Ltd, Liberty House, Bulls Copse Road, Hounsdown Business Park,

Southampton, SO40 9RB, U.K.

Tel: 44/0870.8501241 Fax: 44/0870.8501251

Garmin Corporation, No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan

Tel: 886/02.2642.9199 Fax: 886/02.2642.9099

Web Site Address: www.garmin.com

Except as expressly provided herein, no part of this manual may be reproduced, copied,

transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without

the express written permission of Garmin. Garmin hereby grants permission to download a

single copy of this manual and of any revision to this manual onto a hard drive or other electronic

storage medium to be viewed for personal use, provided that such electronic or printed copy

of this manual or revision must contain the complete text of this copyright notice and provided

further that any unauthorized commercial distribution of this manual or any revision hereto is

strictly prohibited.

Garmin

is a registered trademark of Garmin Ltd. or its subsidiaries, and may not be used without

the express permission of Garmin.

January 2010 190-00140-78 Rev. A Printed in the U.S.A.

WARNING: The altitude calculated by 4XX/5XX GPS receivers is geometric

height above Mean Sea Level and could vary signiﬁcantly from the altitude

displayed by pressure altimeters in aircraft. GPS altitude should never be used

for vertical navigation. Always use pressure altitude displayed by pressure

altimeters in the aircraft.

WARNING: The Jeppesen database used in the 4XX/5XX system must be

updated regularly in order to ensure that its information remains current.

Updates are released every 28 days. A database information packet is included

in the 4XX/5XX package. Pilots using an outdated database do so entirely

at their own risk.

WARNING: The basemap (land and water data) must not be used for

navigation, but rather only for non-navigational situational awareness. Any

basemap indication should be compared with other navigation sources.

WARNING: For safety reasons, 4XX/5XX operational procedures must be

learned on the ground.

WARNING: The United States government operates the Global Positioning

System and is solely responsible for its accuracy and maintenance. The GPS

system is subject to changes which could affect the accuracy and performance

of all GPS equipment. Portions of the Garmin 4XX/5XX units utilize GPS as a

precision electronic NAVigationAID (NAVAID). Therefore, as with all NAVAIDs,

information presented by the 4XX/5XX units can be misused or misinterpreted

and, therefore, become unsafe.

WARNING: The GTS 8XX interface is intended for advisory use only to aid

the pilot in visually acquiring trafﬁc. No avoidance maneuvers should be

based solely upon TAS or TCAS trafﬁc information. It is the responsibility of

the pilot in command to see and manuever to avoid trafﬁc.

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A

Warnings, Cautions, & Notes

NOTE: Unless otherwise speciﬁed within this manual, the term ‘4XX/5XX’

applies to all the following models: GPS 400, GNC 420(A), GNS 430(A),

GPS 500, GNS 530(A).

NOTE: References to the GTS 8XX throughout this document refer equally

to the GTS 800, GTS 820, and GTS 850 unless otherwise noted.

NOTE: All visual depictions contained within this document, including screen

images of the 4XX/5XX panel and displays, are subject to change and may

not reﬂect the most current 4XX/5XX system. Depictions of equipment may

differ slightly from the actual equipment.

NOTE: This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

NOTE: This product, its packaging, and its components contain chemicals

known to the State of California to cause cancer, birth defects, or reproductive

harm. This notice is being provided in accordance with California’s Proposition

65. If you have any questions or would like additional information, please

refer to our website at www.garmin.com/prop65.

NOTE: This section assumes the user has experience operating the 4XX/5XX

units and the GTS 8XX.

NOTE: TIS is disabled when a GTS 8XX unit is installed.

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A

Warnings, Cautions, & Notes

GTS 8XX Interface Overview ..........................................................................................1

1.0 System Description.................................................................................................1

1.1 TCAS I Surveillance Volume....................................................................................1

1.2 Trafﬁc Symbology ...................................................................................................2

1.3 TA Alerting Conditions............................................................................................2

1.4 Aural Alerts..............................................................................................................4

1.5 Self-Test ...................................................................................................................4

1.6 User-Initiated Test...................................................................................................5

1.7 Switching Between Standby and Operating Modes............................................6

1.8 Trafﬁc Page ..............................................................................................................7

1.9 Trafﬁc Page Display Range.....................................................................................7

1.10 Altitude Display Mode............................................................................................8

1.11 Trafﬁc Warning Window........................................................................................10

1.12 Map Page Trafﬁc Banner ......................................................................................10

1.13 Conﬁguring Trafﬁc Data on the Map Page .........................................................11

1.14 Thumbnail Trafﬁc on Map Page ...........................................................................12

1.15 Highlighting Trafﬁc Data Using Map Panning ....................................................13

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A

Table of Contents

iii

GTS 8XX INTERFACE OVERVIEW

All information in this addendum pertains to the display and control of the Garmin

4XX/5XX Series units using a GTS 8XX interface. This addendum does not replace or

supercede the 4XX/5XX Pilot’s Guides. Refer to the 400/500 Series Display Interfaces

Pilot’s Guide Addendum (190-00140-10) when interfacing with non-Garmin

products

1.0 SYSTEM DESCRIPTION

The 4XX/5XX provides an optional display interface for the GTS 8XX Trafﬁc

Advisory (TAS) and Trafﬁc Collision Avoidance (TCAS I) Systems. The GTS 800

and GTS 820 are TAS systems, the GTS 850 is a TSO-Certiﬁed TCAS I system. The

GTS 8XX uses active interrogations of Mode A/C/S (GTS 820 and GTS 850 only) and

Mode A/C transponders to provide Trafﬁc Advisories to the 4XX/5XX.

The GTS 8XX is an active trafﬁc advisory system that operates as an aircraft-to-

aircraft interrogation device. The GTS 8XX monitors the airspace surrounding an

aircraft, and advises the ﬂight crew where to look for transponder-equipped aircraft that

may pose a collision threat. When the GTS 8XX receives replies to its interrrogations,

it computes the responding aircraft’s range, bearing, relative altitude, and closure rate.

The GTS 8XX then determines the advisory status of the target and sends the location

information and alert status to the 4XX/5XX for display.

The GTS 800 is capable of tracking up to 45 Mode A/C/S intruders. The

GTS 820/850 is capable of tracking up to 45 Mode A/C plus 30 Mode S intruders. Up

to 30 of the most threatening targets are displayed.

Pilots should be aware of TAS/TCAS system limitations. If an intruder transponder

does not respond to interrogations due to antenna shading or marginal transponder

performance, it will not be displayed, or display may be intermittent. Pilots should

remain vigilant for trafﬁc at all times when using TAS/TCAS systems for non-

transponder equipped airplanes or unresponsive airplanes.

1.1 TCAS I SURVEILLANCE VOLUME

Top and bottom mounted antennas allow an active surveillance range of up to

12 nm (GTS 800) or 40 nm (GTS 820/850) in the forward direction, and somewhat

reduced ranges to the sides and aft of own aircraft due to the directional interrogation

patterns. Interference limiting in GTS 820/850 units may automatically reduce range

in high density trafﬁc areas.

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A 1

GTS 8XX Interface

1.2 TRAFFIC SYMBOLOGY

Trafﬁc information from the GTS 8XX is displayed on the 4XX/5XX unit using TAS/

TCAS symbology (Table 1) on a dedicated Trafﬁc page, and on the moving Map Page.

The displayed trafﬁc information generally includes the relative range, bearing, and

altitude of intruder aircraft. The GTS 8XX also generates aural announcements heard

on the cockpit audio system. Proximity Advisories and Other Trafﬁc symbols normally

displayed in white may be displayed in cyan if conﬁgured for alternate trafﬁc color (see

the applicable 4XX/5XX installation manual).

Symbol Trafﬁc Type Description

Trafﬁc

Advisory (TA)

A TA (Trafﬁc Advisory) is generated when the GTS 8XX

predicts that an intruder aircraft may pose a collision

threat. A solid yellow circle represents an intruder aircraft

that meets the TA criteria as described in the TA Alerting

Conditions section. A TA consists of the trafﬁc symbol and

an aural alert (e.g., “trafﬁc, 12 o’clock, high, 3 miles”).

Out-of-

Range Trafﬁc

Advisory

This solid yellow half circle appears (on the outer range ring)

under the same conditions and has the same urgency as a

TA. Its appearance differs from the TA only to signify that

the intruder is outside of the current range of the Trafﬁc

Page.

Proximity

Advisory (PA)

Proximity Advisories (PA) are displayed as solid white (may

be conﬁgured as cyan) diamonds. PAs are deﬁned as

trafﬁc within the 6.0-nm range, within ±1200 ft. of altitude

separation, and are not a trafﬁc advisory (TA).

Other Trafﬁc

Symbol

The hollow white (may be conﬁgured as cyan) diamond

represents trafﬁc detected within the selected display range

that does not meet the criteria for a TA or a PA and does

not pose an immediate collision threat.

Table 1 TAS/TCAS Symbology

1.3 TA ALERTING CONDITIONS

The GTS 8XX automatically adjusts its TA sensitivity level (Table 2) to reduce

the likelihood of nuisance TA alerting during ﬂight phases likely to be near airports.

Level A (less sensitivity) TA sensitivity is used when the aircraft’s radar altimeter (if

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A

GTS 8XX Interface

equipped) indicates own altitude is less than 2000 feet AGL. If no radar altimeter is

present, Sensitivity Level A is active when the landing gear is extended. Level A is also

active when groundspeed is less than 120 knots with no radar altimeter present in a

ﬁxed gear aircraft. In all other conditions, Level B (greater sensitivity) TA sensitivity is

used to assess TA threats.

Sensitivity

Level

Intruder

Altitude

Available TA Alerting Conditions

AYes

Intruder closing rate provides less than 20 seconds of

vertical and horizontal separation.

Or:

Intruder range is within 0.2 nm and vertical separation is

within 600 feet.

A No Intruder closing rate is less than 15 seconds.

BYes

Intruder closing rate provides less than 30 seconds of

vertical and horizontal separation.

Or:

Intruder range is within 0.55 nm and vertical separation is

within 800 feet.

B No Intruder closing rate is less than 20 seconds.

Table 2 TA Sensitivity Level and TA Alerting Criteria

Target altitude relative to own aircraft altitude (relative altitude) is displayed (in

hundreds of feet) for each target symbol (Figure 1). If trafﬁc is above own aircraft

altitude the relative altitude is shown above the target next to a ‘+’ symbol. If trafﬁc

is below own aircraft altitude the relative altitude is shown below the target next to a

‘-’ symbol.

Altitude trend (Figure 1) is displayed as an up arrow (≥+500 fpm), down arrow

(≤-500 fpm), or no symbol if less than 500 fpm rate in either direction.

Figure 1 Trafﬁc Symbol Components

Relative

Altitude

Trend

Trafﬁc

Type

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A 3

GTS 8XX Interface

1.4 AURAL ALERTS

A TA consists of a displayed trafﬁc symbol (solid yellow circle) and an aural alert.

The aural alert announces “trafﬁc”, followed by the intruder aircraft’s position, altitude

relative to own aircraft (“high”, “low”, or “same altitude”), and distance from own

aircraft; e.g. “trafﬁc, 12 o’clock, high, 3 miles”.

1.5 SELF-TEST

The GTS 8XX automatically performs a self-test upon power up. The self-test

checks internal parameters and calibrates components of the GTS 8XX. The self-test

can also be initiated by the user during normal operation.

Check for the following test criteria on the Trafﬁc Page during power-up:

• If the GTS 8XX passes the power-up test; and the aircraft both has a squat

switch and is on the ground, the Standby Screen is displayed (Figure 2).

• If the GTS 8XX passes the power-up test and the aircraft both has a squat

switch and is airborne, the Trafﬁc Page is displayed on the 6-nm display range

and in the normal altitude display mode.

• If the GTS 8XX passes the power-up test and the aircraft does not have a squat

switch, the Standby Screen is displayed (Figure 2).

• If the GTS 8XX fails the power-up test (as indicated by a FAILED screen),

the GTS 8XX is inoperable, see the GTS 8XX Installation Manual for detailed

information on Failure Response.

NOTE: The FAILED message is displayed when the system detects an error

that prohibits further trafﬁc display operation.

NOTE: When the system is in standby, the GTS 8XX does not transmit,

interrogate, or track intruder aircraft.

400/500 Pilot’s Guide Addendum for GTS 8XX Interface

190-00140-78 Rev. A

GTS 8XX Interface

Otros manuales para GPSMAP 800 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Pantalla aviónica de Garmin

Garmin

Garmin G3X Touch Manual de usuario

Garmin

Garmin Cessna Caravan G1000 Manual

Garmin

Garmin G3000 Manual del propietario

Garmin

Garmin GTS 8000 Manual de usuario

Garmin

Garmin G3X Touch Manual de usuario

Garmin

Garmin GTN 625 Manual

Garmin

Garmin GSU 75 Series Manual de usuario

Garmin

Garmin Cessna Caravan G1000 Manual

Garmin

Garmin Cessna Caravan G1000 Manual de usuario

Garmin

Garmin GTS 8 Series Manual de usuario

Garmin

Garmin Approach G5 - GPS-Enabled Golf Handheld Manual de usuario

Garmin

Garmin GI 275 Manual de usuario

Garmin

Garmin GI 275 Guía de referencia

Garmin

Garmin GI 275 Manual

Garmin

Garmin GNC 420 Manual de usuario

Garmin

Garmin Mobile 20 Manual de usuario

Garmin

Garmin GNC 420 Manual de usuario

Garmin

Garmin AOA System Manual de usuario

Garmin

Garmin Cessna Caravan G1000 Manual de usuario

Garmin

Garmin G500 Manual de usuario

Garmin

Garmin Cessna Caravan G1000 Manual de usuario

Garmin

Garmin Cessna Caravan G1000 Guía de configuración

Garmin

Garmin G3000 Manual de usuario

Garmin

Garmin Cessna Caravan G1000 Manual

Manuales populares de Pantalla aviónica de otras marcas

Smart Avionics

Smart Avionics PB-4 Manual de usuario

Midcontinent

Midcontinent SAM MD302 Manual

MGL Avionics

MGL Avionics Stratomaster Maxi Single FF-3 Manual de usuario

Mid-Continent Instruments

Mid-Continent Instruments 4300 Series Manual

Avidyne

Avidyne 700-00182 Series Manual de servicio

Flybox

Flybox Oblo Manual de usuario

SANDIA aerospace

SANDIA aerospace SAFE 328 Manual de usuario

Lynx

Lynx Micro System Manual de usuario

SAC

SAC SA100 Manual de usuario

Avidyne

Avidyne Entegra Manual

Dynon

Dynon SkyView HDX System Documento técnico

Barco

Barco MDU-254 Manual de usuario

PROXALERT

PROXALERT R5 Manual

Aspen

Aspen Evolution EFD 1000 FDF Manual de usuario

Avidyne

Avidyne IFD550 Manual

Aspen Avionics

Aspen Avionics Evolution 1000 Pro/VFR PFD Manual

uAvionix

uAvionix SkyEcho Manual de usuario

Triadis

Triadis TR-DVS Manual
