Replacing GTS 8000 on Citation M2

Garmin G3000 Software Version 10

Caution: Before starting the software or configuration loading process, certain

items may be required to be recorded first, to prevent loss of

information or settings. See Section 1 for details.

Caution: Make certain that all SD cards are available before starting. These are

usually located in a blue pouch onboard the aircraft (usually in AFM).

Caution: Follow all steps in a given section for specific loadings. Failure to do so

will result in probable rework.

Caution: Ensure that power is available through a GPU so that power is not

interrupted during the loading process.

Note: This document is to supplement, not replace, the Cessna Citation M2

MM, and Garmin G3000 LMM.

Note: Reference latest revision of the Garmin G3000 LMM 190-01668-00.

Table of Contents

Introduction G3000 System Familiarization

Section 1 References Prior to Certain Software and Configuration Loading

Section 2 Software and Configuration Loading

Section 3 Aircraft Configuration

Section 4 Final Verification / Return to Service

Section 5 Troubleshooting

Appendix A Determining Options Installed

Appendix B Configuration ID / CRC Numbers

Version 1.0

Introduction G3000 System Familiarization

When in configuration mode, select GDU controls on left side of GTC 1. Ensure that PFD 1 is

selected on the screen. The dual concentric knobs on the lower right bezel will be utilized, and

throughout this document will be referred to as the FMS small and large knob. The Enter

button will be in the lower right part of the screen.

As an alternative, you can use the dual concentric knobs (labeled PFD) and Enter button on the

GCU-275 controller mounted above PFD 1.

Version 1.0

Section 1 References Prior to Certain Software and Configuration Loading

When replacing the GTS 8000 the following steps must be completed first:

Note: This is with the G3000 powered up in normal mode.

Radar Trim Settings

•Go into the left GTC:

oUse Back button and select Aircraft Systems.

oSelect Maintenance.

oEnter CACCDMS for password.

oSelect Radar Trim.

Record Pitch Trim Value= ____________

Record Roll Trim Value= ____________

oIf the Radar trims were not both at zero originally:

Select Restore Defaults.

oSelect Home.

Select Utilities.

Select Setup.

Select Avionics Status.

Select the Airframe Tab on the left side.

Record the Config ID now that the radar trims are zero= ____________

•This is for reference in case it is needed later.

Version 1.0

Section 2 Software and Configuration Loading

This section will provide the steps necessary to target load the software and configuration into

GTS 8000 after replacement.

Note: Anytime that software or configurations are being loaded, all three displays, and both

touch controllers must be in configuration mode.

Note: Ensure that you have completed the steps contained in Section 1.

•GTS 8000 (TCAS I or TCAS II Processor)

Note that TCAS II functions are through an unlock card. See section 4.

•When the GTS 8000 is replaced, then software and configuration loading is required.

1) Pull the following circuit breakers:

L PFD

MFD

R PFD

L Touch Control

R Touch Control

2) Insert the 010-01121-10 software loader card into the upper slot of PFD 1.

3) Turn on aircraft power.

4) Press and hold the right knob on the left GTC and push the L Touch Control circuit

breaker in.
