FYC JK1609A Manual de usuario
Electric Folding
Treadmill
1609A
JK
Thank you very much for purchasing our product. Please read
this manual carefully before useing it
and keep the manual at the proper place.
As shoppers, we're always trying to find the
perfect balance between quality & value. We
believe we've achieved that. Our diverse
catalog of everyday essentials is tailored
especially to our customers & guaranteed to hit
that sweet spot of high quality & low price.
Always
1
ŸFor safety purpose, do not stand on running belt while start.
ŸPlease stop immediately if you experience any kind pain, including but not limited to
chest pains,nausea, dizziness, or cramp.
ŸPlease speed up slowly if needed.
ŸAdjustment of belt is prohibited during using.
ŸIt is suggested to wear sports shoes and gym suit while using this equipment.
ŸChildren, the elder, the pregnant, and patients are prohibited from using this treadmill.
ŸPlease clip the safety key on your clothing during using.
ŸPlease firmly hold the handle bars during using.
Ÿ
To avoid injury please read this manual carefully before operating this machine
ŸPlease put the treadmill on flat ground. It is unsuitable to put the treadmill at following
places:
ŸThe proper power for the treadmill is A.C 110V.
ŸError may appear on display if the power is not stable. Please do not use the same
socket together with computer, air conditioner etc.
ŸIt is suggested to wear sports shoes and gym suit while use the treadmill.
ŸPlease speed up or speed down slowly.
ŸMake sure no child or other object is near while folding or unfolding the treadmill.
ŸThe treadmill should not be located near water or wet object. Error or damage may be
caused if water or other liquids drop into the equipment.
1
SAFETY NOTICE
CAUTION
1
2Slant ground or slant places on balcony.
3Sunlight area or near heater.
4Noisy places.
Outdoors. (The treadmill is specially designed for indoor use only)
2
ŸIf you do not feel well before using, please consult your doctor or coach.
ŸPlease unplug the equipment when not in use.
ŸPlease unplug the treadmill before cleaning, moving or change parts for the treadmill.
ŸChildren, the elder and the pregnant are prohibited from using the treadmill. Patients
should consult their doctor before starting any exercise routine.
ŸPlease place the treadmill on a level flat surface. There should be 2M of clearance
behind thetreadmill.
ŸDo not start the treadmill when it is folded.
ŸKeep all electrical components, especially motor, power cord and plug, away from
water or other liquids.
ŸDo not wear clothes like long dress, which might catch on any part of the treadmill while
using.
ŸDo not place the treadmill in an area that will block any vent or air openings.
ŸDo not put any objects on the treadmill.
ŸPut away the plug from heated place or fire seat.
ŸPlease switch off all functions and unplug after using.
ŸDo not stand on the belt while you're preparing to use the treadmill.
ŸDo not disassemble the treadmill without consulting professional technicians.
ŸPlease make sure the running belt is fastened before using.
CAUTION DURING USE
Keep both the machine and power cord away from heated surfaces.
TOOLS REQUIRED
ALLEN WRENCH
(PROVIDED)
SILICONE OIL
(PROVIDED)
HARDWARE
Short Bolt
Lock Knob Stretch Knob End Cap
PRODUCTS MAIN PARTS
Cup Holder
Console
2、
Safety Key
3、
Heart Inductor
4、
Upright Tube
5、
Motor Cover
6、
Running Belt
7、
Side Rail
8、
Wheel
9、
3
1、
6 PCS
1 PCS 1 PCS 2 PCS
265
SAPNNER
(PROVIDED)
Safety Key Round Washer Arc Washers
1 PCS 2 PCS 4 PCS
123
6
45 7
1
2
3
4
5
6
7
8
93-Level Incline
10、
10
End-Cap
11、
11
4
PARTS
HEADER RUNNINGDECK
PARTS
PARTSPRODUCT ASSEMBLY
1
First, remove the pre-install bolts & nuts at the top of the upright tubes.
Then lift the left and right poles respectively, and use the removed bolts & nuts to
fix the tubes with control panel.
5
PARTSPRODUCT ASSEMBLY
2
Lift up the whole control panel with tubes.
Use Short Bolt (part 6 ) & Arc Washer (part 3) to fix the back of tubes with base.
Repeatedly the step to fix the right tubes.
Then connect the wire from control panel and right tube and put the control panel
back in the horizontal position.
NOTE: Please pay attention to the wire, do not let the control panel press it in case
of being damaged/broken.
Use Short Bolt (part 6) & Round Washer (part 2) to fix the left side of tubes with base;
6
PARTS
END CAPS ASSEMBLY
1.
Lift up the running deck and fix it with stretch knob.
Remove the pre-installed screws both left & right side
at the end of frame.
2.
Put the end caps both left & right side at the end of
frame and secure with screws removed.
3.
After the end caps assembly finished,
lay down the running deck.
3
7
PARTSPRODUCT ASSEMBLY
4
Use Short Bolt (Part 6) and Arc Washers (Part 3) to fix the panel to the tubes
Put Lock knob (Part 4) and Stretch Knob (Part 5) to the treadmill.
Put the safety key to the panel. Assembly finished.
PARTS
FOLDING UP AND SETTING DOWN
FOLD:
1. Turn off the machine completely.
Unscrew the Lock knob (part 4) on the base frame and pull out the stretch knob (part 5). 2.
Lift the base frame to the place where the Lock knob (part 4) can put in to fix the base frame.3.
FOLDING UP AND SETTING DOWN
Product name JK1609A
Voltage 110V
Frequency 50-60Hz
Speed 0.5-7.5MPH
4
8
5
BLUETOOTH SETUP
BT-MUSIC
BT-MUSIC
