Futech 150.12.TL Manual de usuario

1. Round vial

2. Reception eld

3. Orange LED indicator (too high)

4. Green LED indicator (center)

5. Red LED indicator (too low)

6. Center marking

7. Power On/Off button

8. Power indicator LED

9. Sound button

10. Buzzer

11. Long vial

12. Battery cover

13. Clamp

4 13

5 9

LINE TRACER RED/GREEN

laser receiver

HOW TO USE

Make sure your laserdevice is in laser receiver Mode. read the Manual of your

laserdevice to know how to do it.

· Open the battery cover (12) and place the battery. Pay attention to the polarity.

· Press the Power On/Off button (7) to turn on the device. The power indicator

LED (8) will light up.

· Use the soundbutton (9) to activate or de-activate the buzzer (10).

· Move with your detector to the laserline. When the laser hits the reception eld

(2), the related LED light (3, 4 or 5) and, if activated, the buzzer (10) will sound.

LOCATE HORIZONTAL LASERLINES:

· Hold the detector vertically.

· Move the detector up- or downwards while keeping the bubble in the middle

of the round vial (1).

– If the laserbeam hits the receptioneld (2) under the centermarking (6), the

upper orange LED indicator (3) will light up. (If activated, the buzzer (10)

makes a repeating sound.) Move the detector slowly downwards (in the direc-

tion of the arrow around the orange LED indicator (3)) to nd the center.

– If the laserbeam hits the receptioneld (2) above the centermarking (6), the

lower red LED indicator (5) will light up. (if activated, a te buzzer (10) makes

a fast repeating sound.) Move the detector upwards (in the direction of the

arrow around the red LED indicator (5)) to nd the center.

– If the leaserbeam hits the receptioneld (2) exactly in the center, on the cen-

termarking (6), the middle green LED indicator (4) will light up. (if activated,

the buzzer (9) makes a continious sound.) The centermarking is now exactly

alligned with the laser line. * description Made with the line tracer positioned with

the long vial on the bottoM side.

LOCATE VERTICAL LASERLINES(*):

(* NOTE: THIS DISCRIPTION IS MADE WITH THE LONG (11) VIAL ON THE BOTTOM SIDE)

· Hold the detector horizontally.

· Move the detector left or right while keeping the bubble in the middle of the

long vial (11).

– If the laserbeam hits the receptioneld (2) on the right side of the centermark-

ing (6), the left orange LED indicator (3) will light up. (If activated, the buzzer

(10) makes a repeating sound.) Move the detector slowly to the right (in the

direction of the arrow around the orange LED indicator (3)) to nd the center.

– If the laserbeam hits the receptioneld (2) on the left side of the centermark-

ing (6), the right red LED indicator (5) will light up and, if activated, a te buzzer

(10) makes a fast repeating sound. Move the detector to the left (in the direc-

tion of the arrow around the red LED indicator (5)) to nd the center.

– If the leaserbeam hits the receptioneld (2) exactly in the center, on the

centermarking (6), the middle green LED indicator (4) will light up and, if

activated, the buzzer (9) makes a continious sound. The centermarking is now

exactly alligned with the laser line.

ATTENTIONS

·this line tracer red/green is only coMpatible with red and green cross line

lasers, with a laserfrequency of 10khz in receiverModus

·this line tracer red/green is a precision instruMent. avoid storage or usage in

an environMent with high teMperature and/or high huMidity.

·please reMove the battery when you don’t use this device for a longer tiMe.

SPECIFICATIONS

Detection accurracy: < ±1mm

Max. receiving distance: 70m

Working temperature: -10°C ~+50°C

Power: DC 9V alkaline battery

Size of the receiving window: 20 x 21mm

Netto weight: 126g

Dimensions: 140 x 62 x 25mm

IP rate: IP54

Connection thread: 1/4”
