Furuno 82B-35R Manual de usuario

Operator’s Manual

TRANSDUCER 82B-35R

The 82B-35R is a new transducer with wide bandwidth of 65 kHz-110 kHz, and is useable

with FCV-291/292/1100L/1200L and ETR-30N. It is constructed to provide protection against

slamming.

WARNING

Be sure no water leaks in at the trans-

ducer mounting location.

Water leakage can sink the vessel. Also,

confirm that the transducer will not loosen

by ship's vibration. The installer of the

equipment is solely responsible for the

proper installation of the equipment.

FURUNO will assume no responsibility for

any damage associated with improper

installation.

Turn off the power at the

switchboard before

beginning the installation.

Electrical shock can

result if the power is left on.

CAUTION

The transducer cable must be

handled carefully, following the

guidelines below.

- Keep fuels and oils away from the

cable.

- Locate the cable where it will not be

damaged.

- The cable sheath is made of chloro-

phrene or polychloride vinyl, which

are easily by damaged plastic solvents

such as toulene. Locate the cable

well away from plastic solvents.

- Do not lift the transducer by its

cable. Wires in the transducer

may be cut.

DIspose of the equipment according to

appropriate regulations.

Do not install the transducer where

noise or air bubbles is present.

Performance will be affected.

Features

When the transducer is used with the FCV-1100L/1200L, sensitivity remains high even if the

frequency is shifted ±10% to suppress interference.

The transducer may be installed in the tank of the transducer 88B-10 and 100B-10R.

Installation

Install the transducer referring to the outline drawing and tank drawings at the back of this

manual.

Setting the echo sounder

Set the supply voltage or tap on the echo sounder referring to the installation manual.

Model Supply voltage Model Tap

FCV-1200L 90 FCV-1100L E

FCV-291/292 (88 kHz) E

ETR-30N E

Note

When retrofitting 88B-10, 68F-30H or 100B-10R, the directional pattern of sidelobe angle,

etc. will be different. Therefore the sounder image may differ from previous one.

Y.Hatai

D-1

88B-10(82B-35R)

(82B-35R)

C2001-275-B

MAY 25, '06

E. MIYOSHI

TAKAHASHI. T

BOW

Y. Hatai

D-2

(82B-35R)

88B-10(82B-35R)

C2001-277-D

TAKAHASHI. T

MAY 25, '06

E. MIYOSHI

BOW

Y. Hatai

D-3

(82B-35R)

88B-10(82B-35R)

C2001-475-C

TAKAHASHI. T

MAY 25, '06

E. MIYOSHI

BOW

Y. Hatai

D-4

88B-10(82B-35R)

(82B-35R)

C2001-476-D

TAKAHASHI. T

Mar. 20, '06

E. MIYOSHI

BOW

Y. Hatai

TAKAHASHI. T

MAY 25, '06

E. MIYOSHI

D-5

88B-10(82B-35R)

T-606-02-0

T-629-04-0

(82B-35R)

C2001-415-C

T-651-03-0

T-629-03-0

T-651-04-0

T-601-04-0

TAKAHASHI. T

MAY 25, '06

E. MIYOSHI

BOW

Y. Hatai

D-6

T-606-02-0

T-629-F-01-0

T-629-04-0

T-651-04-0

T-651-03-0

T-601-04-0

88B-10(82B-35R)

(82B-35R)

C2001-416-B

T-629-03-0

T-629-02-0

T-629-01-0

TAKAHASHI. T

MAY 25, '06

E. MIYOSHI

BOW

Y. Hatai

D-7

111スト

T-629-04-0

T-606-02-0

T-629-03-0

T-611-04-0

T-612-02-0

T-604-03-0

88B-10(82B-35R)

28F-18/88B-10

(50F-8G/88B-10)

(82B-35R)

C2001-424-D

T-636-01-0

T-629-01-0

TAKAHASHI. T

MAY 25, '06

E. MIYOSHI

BOW

Y. Hatai

D-8
