Furuno MU-201C Manual de usuario

MULTI-PURPOSE LCD DISPLAY

MU-201C

IMPORTANT NOTICE

• No part of this manual may be copied or reproduced without written permission.

• If this manual is lost or worn, contact your dealer about replacement.

• The contents of this manual and equipment specifications are subject to change without

notice.

• The example screens (or illustrations) shown in this manual may not match the screens

you see on your display. The screen you see depends on your system configuration and

equipment settings.

• This manual is intended for use by native speakers of English.

• FURUNO will assume no responsibility for the damage caused by improper use or

modification of the equipment or claims of loss of profit by a third party.

• Please carefully read and follow the operation and maintenance procedures set forth in

this manual.

• Store this manual in a convenient place for further reference.

SAFETY INSTRUCTIONS

WARNING

To avoid electrical shock, do not

remove cover. No user-serviceable

parts inside.

WARNING

CAUTION

MU-201C

Standard Steering

compass compass

0.55 m 0.30 m

The TFT LCD is constructed using the

latest LCD techniques, and displays

99.99% of its pixels. The remaining 0.01%

of the pixels may drop out or blink, how-

ever this is not an indication of malfunc-

tion.

Name: Warning Label (1)

Type: 86-003-1011-1

Code No.: 100-236-231

Do not open the equipment.

Only qualified personnel should

work inside the equipment.

Do not disassemble or modify the

equipment.

Fire, electrical shock or serious injury can

result.

Use the proper fuse.

Fuse rating is shown on the equipment.

Use of a wrong fuse can result in damage

to the equipment.

Immediately turn off the power at the

switchboard if the equipment is emitting

smoke or fire.

Continued use of the equipment can cause

fire or electrical shock. Contact a FURUNO

agent for service.

Safety Instructions for the Operator Safety Instructions for the Installer

Do not open the cover unless

totally familiar with electrical

circuits and service manual.

Improper handling can result in

electrical shock.

Turn off the power at the switchboard

before beginning the installation.

Fire or electrical shock can result if the

power is left on.

Do not install the equipment where it may

get

wet

from

rain

water

splash.

Water in the equipment can result in fire,

electrical shock or damage to the

equipment.

Ground the equipment to

prevent mutual interference.

A warning label is attached to the

equipment. Do not remove the label.

If the label is missing or damaged,

contact a FURUNO agent or dealer.

About the TFT LCD

Observe the following compass safe

distances to prevent interference to a

magnetic compass:

The face of the LCD monitor is made of

glass. Handle it with care.

TABLE OF CONTENTS

FOREWORD ........................................................................................................iii

SYSTEM CONFIGURATION................................................................................ iv

EQUIPMENT LISTS.............................................................................................. v

1 MOUNTING ......................................................................................................1

1.1 Display Unit ...................................................................................................................1

2 WIRING.............................................................................................................4

2.1 Wiring............................................................................................................................4

3 ADJUSTMENTS...............................................................................................6

3.1 OSD Settings ................................................................................................................6

4 OPERATION...................................................................................................10

5 MAINTENANCE, TROUBLESHOOTING.......................................................12

5.1 Maintenance................................................................................................................12

5.2 Troubleshooting...........................................................................................................13

SPECIFICATIONS...........................................................................................SP-1

OUTLINE DRAWINGS...................................................................................... D-1

INTERCONNECTION DIAGRAM ......................................................................S-1

iii

FOREWORD

A Word to the Owner of the MU-201C

FURUNO Electric Company thanks you for purchasing the MU-201C 20.1” Multi-Purpose

LCD Display. We are confident you will discover why the FURUNO name has become

synonymous with quality and reliability.

For over 50 years FURUNO Electric Company has enjoyed an enviable reputation for

quality and reliability throughout the world. This dedication to excellence is furthered by our

extensive global network of agents and dealers.

Your equipment is designed and constructed to meet the rigorous demands of the marine

environment. However, no machine can perform its intended function unless properly

installed and maintained. Please carefully read and follow the operation, installation and

maintenance procedures set forth in this manual.

We would appreciate feedback from you, the end-user, about whether we are achieving our

purposes.

Thank you for considering and purchasing FURUNO.

Features

• Main or remote display for radars, video sounders, sonars. Compatible equipment:

FCV-1200L, CH-250, FAR-2107/2807, GD-280/380/680, etc.

• High resolution display of 1280x1024 dot (SXGA), 1024x768 dot (XGA), 640x480 dot

(VGA)

• Wide viewing angle for observation by more than one person

• DVI and analog RGB connectors are employed.

SYSTEM CONFIGURATION

100-230 VAC

NMEA

0183

RGB

DVI Radar

(FAR-2117/2817 series)

IF-

8000

Video Plotter, Video Sounder,

Scanning Sonar, Radar, etc.

Navigator (GPS, etc.)

Control unit of

Video Sounder or

Scanning Sonar*

Multi-purpose LCD display MU-201C

*: When connecting the FCV-1200L or

CH-250 as the main display unit,

connect it to the interface unit (IF-8000).

Processor unit of

Video Sounder,

Transceiver unit of

Scanning Sonar*

Connectable equipment

Equipment Resolution* Image output

-30 SXGA, XGA RGB

-24/30 SXGA RGB

-1200L VGA RGB

FR-2105 SXGA RGB

FAR-2117/2817 series SXGA DVI

GD-280/380/680 VGA RGB

CH-250/270/300 VGA RGB

CI-68/88 VGA RGB

*: SXGA: 1280x1024 dot, XGA: 1024x768 dot, VGA: 640x480 dot

Note1: Portrait orientation equipment cannot be connected to the MU-201C.

Note2: Non-VESAequipment cannot be connected to the MU-201C.

Note3: When inputted signal differs in resolution, characters and lines are not shown

clearly.

Note4: Missing dot, limited viewing angle and display flicker are inherent characteristics of

the LCD color display.

Note5: It takes about five seconds to switch the signal between RGB and DVI.

EQUIPMENT LISTS

Standard supply

Name Type Code No. Qty Remarks

LCD Display Unit MU-201C 000-083-166 1 AC specification

Spare Parts SP03-14401 008-535-990 1 set Fuse FGMB (2A, 2 pcs.)

Installation

Materials CP19-00301 008-546-780 1 set Crimp-on lug, FV2-4

(2 pcs.)

Accessories FP03-09810 008-536-010 1 set

Cosmetic cap (4 pcs.),

Panel hook (2 pcs.),

Self-tapping screw (6x30,

4 pcs.)

Option

Name Type Code No. Qty Remarks

Interface Unit IF-8000 000-068-495 1 Required connecting

FCV-1200L or CH-250/270

DVI-D/D

SINGLELINK 5M 000-149-054 1 For DVI

cable length: 5 m

3COX-2P-6C 5M 000-146-500 1 For RGB

cable length: 5 m

Cable Assy

3COX-2P-6C 10M 000-146-501 1 For RGB

cable length: 10 m

Bracket Kit FP03-09820 008-535-560 1 See page 2.

Handgrip Assy FP03-09840 008-535-570 1

Handgrip (2 pcs.),

Oval countersunk head screw

(M6x20, 4 pcs.),

Rosette washer (M6, 4 pcs.),

Wave washer (WW-6, 4 pcs.)

Dust Cover 03-163-1201 100-307-260 1

1. MOUNTING

Refer to the outline drawing of this manual for mounting dimensions.

Note: The face of the LCD monitor is made of glass. Handle it with care.

1.1 Display Unit

The display unit may be mounted on a desktop or flush mounted in a panel.

When selecting a mounting location, keep in mind the following points:

• Locate the unit out of direct sunlight.

• Select a location where the display can be easily viewed and the controls can be easily

operated.

• Leave sufficient space around the unit for servicing and maintenance. See the outline

drawing for minimum servicing space.

• Be sure the mounting location is strong enough to support the weight of the unit.

• Locate the unit away from areas subject to water splash and rain (the unit is not

waterproof).

Flush mounting

1. Make a cutout in the mounting location, referring to the outline drawing of this manual.

2. Set the display unit to the cutout, and fasten it with four self-tapping screws (6x30,

supplied as accessories).

Note: Hex head bolts may also be used to fasten the display unit. However, their lengths

must be 10 mm longer than the wall thickness.

Cosmetic cap Non-waterproofness: IPX0

Non-waterproofness: IPX0

Flush mounting

3. Attach the cosmetic cap (supplied as accessories) to the display unit at the locations

shown in the drawing on page 1.

Note: If necessary, fill gap between the mounting panel and the display unit chassis with

sealing material.

Desktop mounting

The display unit can be mounted on a desktop, using the optional bracket kit (Type:

FP03-09820, Code No.: 008-535-560).

Contents of bracket kit

Name Type Code No. Qty

Hanger L (20) 03-163-1111 100-305-141 1

Hanger R (20) 03-163-1112 100-305-181 1

Hanger stay (20) 03-163-1113 100-305-191 1

Hole plug CP-30-HP-13 000-147-143 2

Plastic rivet For KB-13, black button 000-570-276 4

Hex bolt M6x25 000-802-771 4

Hex bolt M10x30 000-802-182 2

Spring washer M10 000-864-261 2

Flat washer M10 000-864-131 2

1. Assemble two hangers and hanger stay with two hex bolts (M10x30), spring washers

and flat washers and cover each hex bolt with hole plug.

2. Fix the above assembly to the mounting location with four hex bolts (M10, dockyard

supply).

3. Fasten the display unit to the bracket with four hex bolts (M6x25, supplied).

4. Cover each hex bolt with cosmetic cap.

5. Cover each hole for handle on the hanger with plastic rivet.

Cosmetic cap

Hex bolt

(M6x25)

Hanger L

M10 bolts for fixing

(Dockyard supply)

Hanger stay Hanger R

Flat washer (M10)

Spring washer (M10)

Hex bolt

(M10x30)

Hole plug

Plastic rivet

To remove this, insert fingernail in groove.

Desktop mounting

The optional handgrip assy. (Type: FP03-09840, Code No.: 008-535-570) is available for

the desktop mount display unit.

Handgrip

Wave washer

Rosette washer

Oval countersunk head screw

Otros manuales para MU-201C

Tabla de contenidos

Otros manuales de Monitor de Furuno

Furuno

Furuno NAVNET 3D MFDBB Manual de usuario

Furuno

Furuno FEA-2107-BB Manual de usuario

Furuno

Furuno NAVNET TZTOUCH2 TZTL15F Manual de usuario

Furuno

Furuno MU-190 Manual

Furuno

Furuno MU-150C Manual de usuario

Furuno

Furuno Mu-190HD Manual de usuario

Furuno

Furuno NAVNET TZTOUCH2 TZTL15F Guía de instalación

Furuno

Furuno NAVNET TZTOUCH2 TZTL15F Manual de usuario

Furuno

Furuno MU-150HD Manual de usuario

Furuno

Furuno RD-50 Manual de usuario

Furuno

Furuno FMD3100 Manual de usuario

Furuno

Furuno FMD1920C Manual de usuario

Furuno

Furuno MU-155C Manual

Furuno

Furuno PM30 Manual de usuario

Furuno

Furuno MU-151C Manual de usuario

Furuno

Furuno TZT9 Manual de usuario

Furuno

Furuno Multi Instrument FI-504 Manual de usuario

Furuno

Furuno MU-155C Manual

Furuno

Furuno FI-70 Manual de instrucciones

Furuno

Furuno FMD3100 Manual de usuario

Furuno

Furuno FMD-3200-BB Manual

Furuno

Furuno MFD8 Manual

Furuno

Furuno FMD-8010 Manual de usuario

Furuno

Furuno TZTL12F Manual

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

LG M1950D-PZ Manual de usuario
