Fujitsu PRIMERGY TX2540 M1 Manual de usuario

Operating Manual - English

FUJITSU Server PRIMERGY TX2540 M1

Operating manual

Edition February 2014

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]su.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any without the prior written permission of

Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

TX2540 M1

Operating Manual

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the

product is used in a hot environment. The customer shall bear the cost of

replacing replaceable components which have exceeded their operating life.

Note that these are only guidelines, and do not constitute a guarantee of

trouble-free operation during the maintenance support period.

High safety use

This product has been designed and manufactured to be used in commercial

and/or industrial areas as a server.

When used as visual display workplace, it must not be placed in the direct field

of view to avoid incommoding reflections (applies only to TX server systems).

The device has not been designed or manufactured for uses which demand an

extremely high level of safety and carry a direct and serious risk of life or body

if such safety cannot be assured.

Operating Manual

TX2540 M1

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance

control in weapons systems (hereafter, "high safety use"). Customers should

not use this product for high safety use unless measures are in place for

ensuring the level of safety demanded of such use. Please consult the sales

staff of Fujitsu if intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market:

About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://jp.fujitsu.com/platform/server/primergy/harddisk/

TX2540 M1

Operating Manual

Only for the Japanese market:

IAlthough described in this manual, some sections do not apply to the

Japanese market. These options include:

– CSS (Customer Self Service)

Operating Manual

TX2540 M1

Operating Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.1 Documentation overview . . . . . . . . . . . . . . . . . . . 12

1.2 Concept and target groups for this manual . . . . . . . . . 13

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 13

2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 15

2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 26

3 Installation steps, overview . . . . . . . . . . . . . . . . . . 35

4 Important information . . . . . . . . . . . . . . . . . . . . . 37

4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 37

4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 45

4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 46

4.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 47

4.5 Notes on installing the server in the rack . . . . . . . . . . . 48

4.6 Environmental protection . . . . . . . . . . . . . . . . . . . 49

5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 51

5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 52

5.2 Setting up the floorstand model . . . . . . . . . . . . . . . . 53

5.2.1 Mounting the anti-tilt bracket . . . . . . . . . . . . . . . . . . . 53

5.3 Installing/removing the rack model . . . . . . . . . . . . . . 54

5.4 Connecting devices to the server . . . . . . . . . . . . . . . 56

Operating Manual

TX2540 M1

Contents

5.5 Connecting the server to the mains . . . . . . . . . . . . . . 58

5.5.1 Using cable ties . . . . . . . . . . . . . . . . . . . . . . . . . . 59

5.6 Notes on connecting/disconnecting cables . . . . . . . . . . 60

6 Starting up and operation . . . . . . . . . . . . . . . . . . . . 63

6.1 Access to the drives (floorstand model) . . . . . . . . . . . . 63

6.1.1 Enabling access to the accessible drives . . . . . . . . . . . . . 63

6.1.2 Access to the HDD modules (floorstand model) . . . . . . . . . 65

6.2 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 66

6.2.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 66

6.2.1.1 ID card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

6.2.1.2 Control elements . . . . . . . . . . . . . . . . . . . . . . . 68

6.2.1.3 Indicators on the control panel . . . . . . . . . . . . . . . . 69

– . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

6.2.1.4 Indicators on the drives . . . . . . . . . . . . . . . . . . . . 71

6.2.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

6.3 Switching the server on and off . . . . . . . . . . . . . . . . 77

6.4 Configuring the server . . . . . . . . . . . . . . . . . . . . . 80

6.4.1 Configuring the onboard SAS/SATA controller . . . . . . . . . . 80

6.4.2 Configuring the SAS/SATA RAID controller . . . . . . . . . . . . 81

6.4.3 Configuring the server and installing the operating system

with the ServerView Installation Manager . . . . . . . . . . . . . 82

6.4.4 Configuring the server and installing the operating system

without the ServerView Installation Manager . . . . . . . . . . . 83

6.5 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 84

7 Property and data protection . . . . . . . . . . . . . . . . . . 85

7.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 85

8 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 87

8.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 87

8.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 88

8.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 88

TX2540 M1

Operating Manual

Contents

8.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 89

8.5 No screen display or display drifts . . . . . . . . . . . . . . 89

8.6 No mouse pointer displayed on screen . . . . . . . . . . . . 89

8.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . 90

8.8 Hard disk drive error messages at system boot . . . . . . . 90

8.9 Added drive reported as defective . . . . . . . . . . . . . . 91

8.10 Error message on screen . . . . . . . . . . . . . . . . . . . 91

8.11 Expansion cards or onboard devices not recognized . . . . 91

8.12 Temperature warning . . . . . . . . . . . . . . . . . . . . . . 92

8.13 No effect of keyboard or mouse . . . . . . . . . . . . . . . . 92

8.14 Optical drive cannot read data . . . . . . . . . . . . . . . . 92

Operating Manual

TX2540 M1

Contents
