Fujitsu ScanSnap iScanner fi-6010N Guía de configuración









Ultrasonic

Sensor

Glass

Pad Assy.





Eject Rollers

Pick Roller

Feed Rollers



Ultrasonic Sensor

Clean lightly.

Cleaning Instructions for

fi-6010N Network ADF Scanner

It is recommended that these items be

cleaned EVERY 1,000 SCANS

Consumables Part Number

Consumable Kit CON-3289-003A

Cleaning Kit SC-CLE-WGD

Using F1 Impregnated Cleaning Wipes



Pad Assy

Wipe downwards. When cleaning take care to prevent the wipe from catching on the metal

parts.





Turn the Scanner OFF while cleaning the following locations

ADF Glass Surfaces x 2

Located on the ADF cover and opposite side. Clean lightly.

Pick Roller

Clean lightly taking care not to scratch the surface.

P.T.O.



Eject Rollers x 4

Clean lightly taking care not to roughen the surface.

ADF

Cover

ADF Release

Button

BEFORE CLEANING

Push the ADF release button,

hold both sides of the top cover

and lift open

Feed Rollers x 2

For further information please refer to the

fi-6010N Scanner Operators Guide

which can be found on our Website:

http://www.fujitsu.com/emea/products/

January 2010

Using F1 Impregnated Cleaning Wipes

Turn the Scanner ON while cleaning the following locations

PFU Imaging Solutions Europe Ltd Cleaning Instructions for fi-6010N Scanner



On the “Main Menu” screen press the “Maintenance

”button. The Maintenance screen appears. Press “Roller

Cleaning” to access this screen.

Open the top cover. Clean lightly taking care not to

roughen the surface.

Press the “c” key on the keyboard to advance the feed

rollers. Press seven times for one complete revolution.









Ultrasonic

Sensor

Glass

Pad Assy.





Eject Rollers

Pick Roller

Feed Rollers

Touch Panel and Keyboard

The LCD Touch Panel and

Keyboard should be cleaned

with a soft, dry cloth.

Keyboard

LCD Touch

Panel
