FTP-639MCL054/353/354-R

nOVERVIEW

The FTP-609MCL Series thermal printer (driven by 24VDC)

provides ultra-high speed printing (200mm/s) for 2-inch and 3-

inch wide paper.

This series is suitable for a variety of applications, such as POS/

ECR, kiosk terminals, ticket machines, label printers, banking

machines, measuring devices, medical equipment, etc.

nHIGHLIGHTS

• Ultra high speed printing

It can print at 200 mm/s (1600 dotlines/s) maximum by using

Fujitsu Components' unique head drive control.

• Rear paper insertion with lock type

Fujitsu Components' unique platen release mechanism allows

straight paper path and easy head maintenance.

• Auto Cutter

Printer with auto cutter (full cut/ partial cut) is available. It can

be mounted on top of the mechanism.

• Multi-featuring diecast frame

By application of multi-featuring diecast frame, continous print

by function of heat-sink, high ESD with stand by function of

earth frame and shock/vibration resistance by function of solid

frame are valid.

• Compact size

Depth: 40.5mm, width: 104.2mm, height: 20.5mm

• High resolution

8 dots/mm head provides clear print out.

• RoHS compliant

24V DRIVE, FTP-609 SERIES

ULTRA HIGH SPEED (200mm/s)

3" TYPE MECHANISM (Cutter option)

FTP-6x9MCL054R with

FTP-629DSL034R

FTP-639MCL054/353/354-R

nPART NUMBERS

*: Interface is selectable by DIP switch

nGENERAL SPECIFICATIONS

Item Specications

Part number FTP-639MCL054/074-R FTP-629MCL354/374-R

Printing method Thermal sensitive line dot method

Dot structure 576 dots/line

Dot pitch (horizontal) 0.125mm (8dots/mm) - Dot density

Dot pitch (vertical) 0.125mm (8dots/mm) - Line feed pitch

Effective printing area 72 mm

Number of columns ANK 48 columns/line (12 x 24 dot font), OCR 24 columns (24x40

Paper width 82.5 mm +0/-1

Paper thickness 60 to 150µm 60 to 100µm

Cutting type --- full or partial

Printing speed FTP-629DCL/DSL series FTP-629DSL100 series/

FTP-629DSL300 series

80mm/sec. (640 dot lines/sec.)

line mode

200mm/sec. (1600 dot lines/sec.)

image mode

125mm/sec. (1000 dot lines/sec.)

line mode

200mm/sec. (1600 dot lines/sec.)

page mode

Interface types FTP-629DCL/DSL series

FTP-629DCL/DSL100 series

FTP-629DSL300 series

Character

types

Alphanumeric, Kana:

International and special

OCRI

OCRIII

OCRIV

Extended numeric

JIS Kanji level 1, level 2, non-Kanji

159 types

195 types

about 6,800 types

159 types

195 types

103 types

23 types

103 types

11 types

about 6,800 types

Character, dimensions (WxH), number of

columns

(8x16 dots), 72 columns: ANK

(12x24 dots), 48 columns: ANK

(16x16 dots), 36 columns: ANK

(24x24 dots), 24 columns: ANK

(24 x 40 dots), 24 columns, OCRI

(24 x 48 dots), 24 columns, OCRII

(36 x 60 dots), 16 columns, OCRIV

(24 x 48 dots) 24 columns,

extended numeric

Interface standard Centronics, RS-232C, USB Serial /USB

Name Part Number

Printer mechanism bottom insertion FTP-639MCL054R FTP-639MCL074R FTP-639MCL054R

Mechanism with cutter front insertion FTP-639MCL353R TBA FTP-639MCL353R

bottom insertion FTP-639MCL354R FTP-639MCL374R FTP-639MCL354R

LSI FTP-629CU101R FTP-629SR201 FTP-629CU301R

Interface board Parallel FTP-629DCL014R FTP-629DSL181R*

Serial (RS232C) FTP-629DSL034R FTP-629DSL181R* FTP-629DSL301R

USB --- FTP-629DSL112R FTP-629DSL301R

Thermal head cable extension --- FTP-629Y001 ---

Interface cable Parallel FTP-628Y202 ---

Serial FTP-628Y302 FTP-629Y302

USB --- FTP-629Y301

Power supply cable Logic FTP-629Y401 ---

Head, motor FTP-629Y601 FTP-629Y602

FTP-639MCL054/353/354-R

For head 24 VDC ±5% 1.9A (4A, )

(24V , 25% printing ratio)

For printer motor 24VDC ±5% 1A maximum

For cutter motor --- 24VDC±5% 1.2A maximum

For logic 5VDC±5% 0.2 A maximum

Printer Mechanism 104.4 ×40.5 ×20.5mm ---

Dimensions

W x D x H Printer Mechanism with cutter --- 110.4 ×62.5 ×37.7mm

Interface board (DCL/DSL) 70 ×60 ×21.6 mm

Interface board (DSL100) 95 x 73.5 x 11.6mm

Interface board (DCL300) 77 x 50 x 21.5mm

Weight Printer Mechanism Approximately 125g ---

Printer Mechanism with cutter --- Approximately 320g

Interface board (standard) Approximately 25g

Interface board (med speed) Approximately 45g

Interface board (hi speed) Approximately 22g

Life Head Pulse durability: 100 million pulse/dot (using Fujitsu Components' standard driving method)

Wear resistance: 100 km (at 12.5% print ratio)

Cutter --- 500,000 cuts

Operating temperature -10°C to +60°C (Guarantee) 0˚C to +50°C (Guarantee)

Environmental

conditions Operating humidity 20 to 85% RH (no condensation)

Storage temperature –40°C to +70°C (excluding paper) –20°C to +60°C

Storage humidity 5 to 95% RH (no condensation)

Head temperature By thermistor

Detection Paper out/Mark detect By photointerrupter

Head release By slide switch

Cutter position By microswitch (inside cutter)

High sensitivity paper TF50KS-E4 (Nippon paper)

Standard paper TF60KS-E (Nippon paper), FTP-030P0104 (80mm),

PD150R (Oji paper), FTP-030P0701 (80mm)

Medium term paper TP60KS-F1 (Nippon paper), FTP-030P0102(80mm),

PD170R (Oji paper)

P220VBB-1 (Mitsubishi paper)

PD160R-N (Oji paper)

Long term paper AFP-235 (Mitsubishi paper)

TP50KJ-R (Nippon paper)

HA220AA (Nippon paper)

Label paper HW54T (Nippon paper)

Part number FTP-639MCL054/074-R FTP-639MCL354/374-R

SpecicationsItem

Power

supply

Recommended

thermal sensitive

paper

FTP-639MCL054/353/354-R

nFUNCTION

ITEM ITEM

1. Test printing 8. Cutter trouble detection

2. Paper-out detection 9. Motor power save

3. Paper near end detection 10. Mark detection

4. Head-up detection 11. MCU trouble detection

5. Abnormal temp. of thermal head detection 12. Power on/off sequence protection

6. Blown fuse detection 13. Motor protection

7. Abnormal voltage detection of head 14. Hardware timer

nDIMENSIONS

1. Printer mechanism

Unit: mm

FTP-639MCL054R

Center of platen Platen open lever

(paper end sensor)

FTP-639MCL054/353/354-R

Unit: mm

FTP-639MCL353/354-R

Printer with cutter

5.0 4.3

56.3 54.1

FUJITSU

JAPAN

F.T

(57.5)

27.5

45.0

51.6

28.5

29.9

23.0

32.6

25.5

15.5

34.0

24.3

25.3 (75.1)

3.0

3.5

90.0

CAUTION

Max2.5

Max0.5 37.2

15.0

Center of Platen

Paper Path

Center of Paper

Notes: 1. Nominal value (Tolerance +0.5, -0.5)

2. S is the base line of installing (Tolerance +0.5, -0.5)

FTP-639MCL054/353/354-R

oN langiS O/I stnetnoC oN langiS O/I stnetnoC

1 WS O hctiwsneponetalP 2 WS - hctiwsneponetalP

3 HV - daehlamrehtrofrewoP 4 HV - daehlamrehtrofrewoP

5 HV - daehlamrehtrofrewoP 6 HV - daehlamrehtrofrewoP

7 ID I niataD 8 3BTS I 3elbanetnirP

9 4BTS I 4elbanetnirP 01 DDV - cigolrofrewoP

11 MT - rotsimrehTdaeH 21 DNG - DNGdaeH

31 DNG - DNGdaeH 41 DNG - DNGdaeH

51 DNG - DNGdaeH 61 DNG - DNGdaeH

71 DNG - DNGdaeH 81 DNG - DNGdaeH

91 DNG - DNGdaeH 02 DNG - DNGdaeH

12 HT O rotsimrehT 22 1BTS I 1elbanetnirP

32 2BTS I 2elbanetnirP 42 TAL I hctalatadtnirP

52 KLC I kcolC 62 OD O tuoataD

72 HV - daehlamrehtrofrewoP 82 HV - daehlamrehtrofrewoP

92 HV - daehlamrehtrofrewoP 03 HV - daehlamrehtrofrewoP

nCONNECTOR PIN ASSIGNMENT OF PRINTER MECHANISM (FPC)

2. Motor, Sensor

Connector on circuit side : 52610-1071 (Molex) or equivalent

1. Thermal head control circuit side

Part number : 52610-3071 (Molex) or equivalent

3. Cutter

Connector type: B4B-PH-SM4-TB (J.S.T.) or equivalent

nINTERFACE COMMAND OPTIONS

Please refer to the FTP-629DCL/DSL or FTP-629DCL/DSL100/300 datasheet series datasheet.

C 4 IM

.oN langiS O/I stnetnoC .oN langiS O/I stnetnoC

1 1WS - hctiwsnoitisopemohrettuC 2 2WS O hctiwsnoitisopemohrettuC

3 +M O veirdrotomrettu - veirdrotomrettuC

.oN langiS O/I stnetnoC .oN langiS O/I stnetnoC

1 CN - detcennoctoN 2 MT O rosneserutarepmetrotoM

3 MT - rosneserutarepmetrotoM 4 ATM I /AnoitaticxeliocrotoM

5 T A I n A 6oitaticxeliocrotoM BTM I /BnoitaticxeliocrotoM

7 T B I n B 8oitaticxeliocrotoM KHP - edohtacrosnestuorepaP

9 NESV | rosnesrepaprofrewoP 01 EHP O rottimerosnestuorepaP

FTP-639MCL054/353/354-R

Japan

Fujitsu Component Limited

Gotanda-Chuo Building

3-5, Higashigotanda 2-chome, Shinagawa-ku

Tokyo 141 8630, Japan

Tel: (81-3) 5449-7010

Fax: (81-3) 5449-2626

Email: [email protected]

Web: www.fcl.fujitsu.com

North and South America

Fujitsu Components America, Inc.

250 E. Caribbean Drive

Sunnyvale, CA 94089 U.S.A.

Tel: (1-408) 745-4900

Fax: (1-408) 745-4970

Email: [email protected]

Web: http://us.fujitsu.com/components/

Europe

Fujitsu Components Europe B.V.

Diamantlaan 25

2132 WV Hoofddorp

Netherlands

Tel: (31-23) 5560910

Fax: (31-23) 5560950

Email: [email protected]

Web: emea.fujitsu.com/components/

Asia Pacic

Fujitsu Components Asia Ltd.

102E Pasir Panjang Road

#01-01 Citilink Warehouse Complex

Singapore 118529

Tel: (65) 6375-8560

Fax: (65) 6273-3021

Email: [email protected]

Web: http://www.fujitsu.com/sg/services/micro/components/

Fujitsu Components International Headquarter Ofces

owners.

Fujitsu Components America or its afliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our

products Fujitsu Components America, Inc. or its afliates reserve the right to change specications/datasheets without prior notice.

Rev. February 27, 2009.
