Fujitsu FTP-622MCL101 Guía de instalación

FTP-622MCL101/102/353/354

■OVERVIEW

New 2-color printer (blue/black or red/black) joins FTP-602

Series. The series consists of 24V battery drive compact thermal

printers which can print at high speed.

This series is suitable as built-in printer for a variety of

applications, such as portable terminals, POS terminals, ticket

machines, coupon machines, label printers, banking machines,

measuring devices, medical equipment, etc.

■HIGHLIGHTS

• 2 Color printing

It can print 2 colors: blue/ black or red/black

• High speed printing

It can print at 100 mm/s (800 dotlines/s) by using Fujitsu

Components' unique head drive control (at monochromatic

printing).

Speed of 2-color printing: - blue and red: 80 mm/s (460

dotlines/s) maximum

- monochromatic print: 40mm/s

maximum

• Auto Cutter

Printer with auto cutter (full cut/ partial cut) is available.

• Paper auto loading function

Thermal paper can be loaded without head-up lever

operation.

• Easy head access

It is designed for easy head cleaning and head replace-

ment.

• Two paper paths

Front and bottom paper insertion is available.

24V DRIVE, 2-COLOR THERMAL PRINTER

2” TYPE MECHANISM

FTP-622MCL101

FTP-622MCL101/102/353/354 FTP-632MCL101/102/353/354

■PART NUMBERS

■GENERAL SPECIFICATIONS

*1: FTP-622DCL411 is ANK supported only

*2: FTP-622DSL438 has FLASH memory and can print high speed images

*3: Supports Kanji and parallel and serial interfaces

emaNrebmuNtraP

msinahceMretnirP )noitresnirepaptnorf(101LCM226-PTF

)noitresnirepapmottob(201LCM226-PTF

rettuChtiwmsinahceMretnirP )noitresnirepaptnorf(353LCM226-PTF

)noitresnirepapmottob(453LCM226-PTF

draoBecafretnI

lellaraP*114LCD226-PTF

laireS*834LSD226-PTF

)ijnaK,cihtoG(

)UCM(ISL*102UC226-PTF

elbaCecafretnI

lellaraP

)scinortneC(

102Y144-PTF

)C232-SR(laireS103Y226-PTF

elbaC

rewoP104Y226-PTF

daeH)msinahcemotdelbmessaerpCFF(108Y226-PTF

(Continued)

Part number FTP-622MCL101/102/353/354

Printing method Thermal-sensitive line dot method

Dot structure 432 dots/line

Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density

Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch

Effective printing area 54 mm

Number of columns

ANK 36 columns (12X24 dot font max.)

Paper width 58mm±60mm±

Paper thickness 60 to 100 µm (there may be exceptions)

Printing speed 100mm/s (800 dotlines/s maximum at black-white image batch printing

Character types Alphanumeric KANA :159

International :195

JIS Kanji (Kanji CG loaded board) :approx. 6800

36 columns

18 columns

54 columns

27 columns

Interface Centronics / RS-232C standard

SpecificationsItem

Character,

dimensions(H×W),

number of

characters

12×24 dots,(1.5×3.0mm)

24×24 dots,(3.0×3.0mm)

8×16 dots,(1.0×2.0mm)

16×16 dots,(2.0×2.0mm)

FTP-622MCL101/102/353/354 FTP-632MCL101/102/353/354

For head 24 VDC ±5% 1.1 (1.7A)

(24V Rav1500Ω, 25% printing ratio)

For printer motor 24VDC±5% 1A maximum

For cutter motor 24VDC±5% 1A maximum

For logic 5VDC±5% 0.5 A maximum

Printer Mechanism 82 (W) ×48 (D) ×20 (H) mm

Dimensions Mechanism with cutter 97 (W) ×57 (D) ×38(H) mm

Interface board 131 (W) ×89 (D) ×24 (H) mm

Weight Printer Mechanism Approximately 81g

Mechanism with cutter Approximately 280g

Life Head Pulse durability: 1 ×108pulse/dot (using Fujitsu Components' standard

driving method)

Wear resistance: 50 km (at 25% print ratio)

Cutter 3x103times minimum 5x105 times minimum

Operating temperature +5 to +40°C (Guarantee, but can operate between 0°C to +50°C)

Operating humidity 20 to 85% RH (no condensation)

Storage temperature –20 to +60°C (excluding paper)

Storage humidity 5 to 95% RH (no condensation)

Head temperature By thermistor

Detection Paper out/Mark detect By photointerrupter

Head release By slide switch

2 color paper (blue/black) PB770 (Mitsubishi paper)

(red/black) PB670 (Mitsubishi paper)

High sensitivity paper TF50KS-E4 (Nippon paper)

Standard paper TF60KS-E (Nippon paper), FTP-020P0104 (58mm)

PD150R (Oji paper), FTP-020P020P0701 (58mm)

Medium term paper TP60KS-F1 (Nippon paper),FTP-020P0102(58mm)

PD170R (Oji paper)

P220VBB-1 (Mitsubishi paper)

PD160R-N (Oji paper)

Long term paper AFP-235 (Mitsubishi paper)

TP50KJ-R (Nippon paper)

HA220AA (Nippon paper)

SpecificationsItem

(Continued)

Power

supply

Environmental

conditions

Part number FTP-622MCL101/102/353/354

Recommended

thermal sensitive

paper

FTP-622MCL101/102/353/354 FTP-632MCL101/102/353/354

■DIMENSIONS

1. Printer mechanism

Unit: mm

FTP-622MCL101/102

2. Printer mechanism with cutter

Unit: mm

FTP-622MCL353/354

*2)

310

à”íç

ênÇ…êGÇÁÇ»Ç¢Ç≈â∫Ç≥Ç¢ÅB

CAUTION

3-2orless

(96.7)47.8

Å}1

48.9

APAN

JAPAN

241

(MOTOR CABLE)

13.3

37.20.5

14.241.9 316

2.5MAX

(OUTER LENGTH

FOMOVABLE CUTTER)

12.1

(FFC)

(SENSOR CABLE)

226

MCL354

MCL303

(73.1)

FTP-622MCL101/102/353/354 FTP-632MCL101/102/353/354

Interface board

Unit: mm

15.0max

5.0max

1.6

4-Ø3.6±0.1

(39.4) (39.4)

5.1 5.178.7

5.1120.75.1 105.4

86.4

33.2

105.4

87.6

41.8

21.8

CN8

4114

CN7

CN5

CN3

2930

21CN1

CN2

CN9

Height of devices side

Height of solderside

FTP-622MCL101/102/353/354 FTP-632MCL101/102/353/354

■CONNECTOR FOR THERMAL HEAD

Head side : IL-FPC-28CLIP (JAE)

Board side : 52045 (Molex) or equivalent

2. Motor connectors

Motor side : PHR-4 (J.S.T.) or equivalent

Board side : B4B-PH-K-S (J.S.T.) or equivalent

*1: Symbol: " " means a negative logic signal

1, 2, 3, ......................................15, 16

Motor Thermal head heat sink Head up level

Connector Pin No.

3. Sensor connectors

Sensor : PHR-5 (J.S.T.) or equivalent

Board side : B5B-PH-K-S (J.S.T.) or equivalent

.oNlangiStnemmoC

1B BgnivirdrotomesluP

2B BgnivirdrotomesluP

3A AgnivirdrotomesluP

4A AgnivirdrotomesluP

.oNlangiStnemmoC

1NESVrosnesrepaprofrewoP

2EHProttimeretpurretniotohP

3KHPedohtacretpurretniotohP

41WS1hctiwstcetedpudaeH

52WS2hctiwstcetedpudaeH

FTP-622MCL101/102/353/354 FTP-632MCL101/102/353/354

■FUNCTION

ITEM ITEM

1. Test printing 8. Motor power save

2. Paper-out detection 9. Mark detection

3. Paper near end detection 10. MCU trouble detection

4. Head-up detection 11. Power on/off sequence protection

5. Abnormal temp. of thermal head detection 12. Motor protection

6. Blown fuse detection 13. Hardware timer

7. Abnormal voltage detection of head
