Fujitsu FTP-607 Series Manual de usuario

FTP-627MCL401/601

nOverview

The FTP-627 MCL Series are 24V driven high-speed printers

with a ultra low prole auto cutter and long life.

The FTP-627 MCL Series can be used for a variety of

applications, such as POS terminals, ticket vending machines,

label printers, banking terminals, and measurement and

medical equipment.

nHiGHLiGHTS

• Ultralowprole

Height 21.8 mm, width 81.2 mm, depth 42.2 mm

• Highspeedprinting

It can print at 100/150 mm/s (800 dotlines/s) maximum by

using Fujitsu's unique head drive control.

• AutoCutter

Long life and high reliable guilotine with dedicated motor.

• Easypapersetting

Our lever platen release mechanism allows a

wide paper route, so paper can be easily inserted.

Conventional auto loading is also available.

• Multifunctionaldie-castframe

Wide operating temperature range, long continuous

printing, high ESD absorbtion and discharge of static

electricity vibration and shock resistant.

• RoHScompliant

24v driveN, FTP-607 Series

2” HiGH SPeed THerMaL PriNTer

FTP-627MCL401/601

FTP-627DSL291R

FTP-627DSL601R

FTP-627MCL401/601

nParT NuMberS

nSPeCiFiCaTiONS

Part Number

Easy Load Model with low prole cutter FTP-627MCL401

FTP-627MCL601

LSI for driving MCL401 FTP-627CU301R

MCL601 FTP-627CU601R

Interface

board for

Mech/Cutter

Cutter

supported

MCL401 FTP-627DSL291R Parallel (Centronics) /Serial (RS-232C)

MCL601 FTP-627DSL601R, Serial (RS-232C) / USB

MCL401 FTP-627DSL603R (USB)

FTP-627DSL605R Serial (RS-232C)

MCL601 FTP-627DSL613 R (USB)

FTP-627DSL615 R Serial (RS-232C)

Interface

cables

Parallel (Centronics) FTP-628Y202

Serial (RS232C) FTP-628Y302

USB FTP-629Y301

Power

cables

Logic FTP-629Y401

Head, motor FTP-629Y601

Part number FTP-627MCL401/601

Printing method Thermal-line dot method

Dot structure 432 dots/line

Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density

Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch

Effective printing area 54 mm

Number of columns ANK 36 columns/line

(maximum 12/24 dot font)

Paper width 58 mm

Paper thickness 60 to 85 µm (some paper in this range may not be

used because of paper characteristics)

Printing Speed Maximum 100mm/sec. (800 dot line/sec.)

Maximum 150mm/sec. (1,200 dot line/sec.)

Alphanumeric, kana: 159 types

International characters: 195 types

JIS Kanji (Kanji CG loaded board): about 6800 types

12 × 24 dots, (1.5 × 3.0 mm), 36 columns: ANK

24 × 24 dots, (3.0 × 3.0 mm), 18 columns: ANK

8 × 16 dots, (1.0 × 2.0 mm), 54 columns: ANK

16 × 16 dots, (2.0 × 2.0 mm), 27 columns: ANK

SpecicationsItem

Character types

Character, dimensions (W×H), number

of columns

MCL401

MCL601

FTP-627MCL401/601

*+5˚C to +40˚C printing density assurance rance.

Item Specication

Iterface Conforms to RS232C/Centronics / USB

Power supply For print head MCL401 24 VDC average current, 0.5A (0.9 A peak)

(print ratio: 12.5%, print speed 100mm/sec.)

MCL601 24 VDC average current 1.0 A (1.9 A peak)

For motor MCL401 24 VDC ±5%, 1 A maximum

MCL601 24 VDC ±5%, 1.1 A maximum

For cutter MCL401 24 VDC ±5%, 1 A maximum

MCL601 24 VDC ±5%, 1.3 A maximum

For logic 3.3 to 5.25 VDC, 0.1 A maximum

Dimensions Mechanism with cutter 81.2 x 42.2 x 21.8 mm (WxDxH)

Interface

board

DSL291 70 x 60 x 12 mm (WxDxH)

DSL6xx 95 x 70 x 21.6 mm (WxDxH)

Weight Mechanism with cutter Approximately 100g

Interface board Approximately 50g

Life Head Pulse resistance: 50 million pulses/dot (print ratio: 25%).

MCL401 Abrasion resistance: paper traveling distance 50km

MCL601 Abrasion resistance: paper traveling distance 100km

Cutter MCL401 500,000 cuts

MCL601 1,000,000 cuts

Platen 5,000 times (open/close)

Operating

environment

Operating temperature* 0ºC to +50ºC

Operating humidity 20 to 85% RH (no condensation)

Storage temperature -20ºC to +60ºC (paper not included)

Storage humidity 5 to 95% RH (no condensation)

Detection

function

Head temperature

detection

Detected by thermistor

Paper out/mark

detection

Detected by photo-interruptor

Platen release Detected by sliding switch

Recommended thermal sensitive paper High sensitive paper TF50KS-E4 (Nippon paper)

Standard paper TF60KS-E (Nippon paper),

FTP-020PU001 (58mm)

PD150R (Oji paper)

FTP-020PU701 (58mm)

Medium life storage

paper

TF60KS-F1 (Nippon paper)

FTP-020P0102 (58mm)

PD170R (Oji paper)

P220VBB-1 (Mitsubishi paper)

Long life storage

paper

PD160R (Oji paper)

AFP-235 (Mitsubishi paper)

TP50KJ-R (Nippon paper)

HA220AA (Nippon paper)

nSPeCiFiCaTiONS

FTP-627MCL401/601

7.5

5.4

10.7

28.3 (29.3MAX.) 13.9 (14.4 MAX.)

22.1

13.1

81.2

1.6 27.7

Ø1.4

11°

(50~200)

21.8

68.4

nFuNCTiON OF iNTerFaCe bOard

ndiMeNSiONS

1.Printermechanism

Unit: mm

Note: 1. Dimensions are nominal value (tolerance ±5 unless otherwise specied).

2. Platen unit (lever, platen, etc) moves by approximately 0.7mm toward paper insertion direction when platen is

open.

FTP-627MCL401/601

Item Item

1. Test print function 8. Cutter trouble detect

2. Paper out detection 9. Motor power saving function

3. Paper near end detection 10. Mark detection function

4. Paten open detection 11. MCU operation abnormality detection

5. Thermal head temperature abnormality

detection 12. Power ON/OFF sequence protection

6. Blow-out fuse detection 13. Motor over-current protection

7. Head voltage abnormality detection 14. Hardware timer

FTP-627MCL401/601

1.Connector(FPC)specication(CN3/CN10)

(1) Connector

Mechanical unit side: FPC connector

Remote side (housing site): 52610-2471 (made by Molex)

(2) Pin assignment on the mechanical side

M I

oN langiS O/I stnetnoC

1 KHP — )edohtaC(retpurretniotohP

2 NESV I rosnesrepaprofylppusrewopdnuorG

3 EHP O )rottimE(retpurretniotohP

4 HV I rewopevirddaeH

5 ID I tupniataD

6 2BTS I 2langiselbanetnirP

7 3BTS I 3langiselbanetnirP

8 DDV I rewoPcigoL

9 DNG — dnuorgdaeH

01 DNG — dnuorgdaeH

11 DNG — dnuorgdaeH

21 HT O rotsimrehT

31 1BTS I 1langiselbanetnirP

41 TAL I hctaLataD

51 KLC I kcolC

61 HV I rewopevirddaeH

71 HV I rewopevirddaeH

81 WS — hctiwsneponetalP

91 WS — hctiwsneponetalP

02 AT AlangiseticxerotoM

12 AT AlangiseticxerotoM

22 BT BlangiseticxerotoM

32 BT BlangiseticxerotoM

42 CN — detcennoctoN

FTP-627MCL401

FTP-627MCL401/601

No. Symbol Signal Name

1PHK Cathode for photo interrupter

2VSEN Paper sensor power

3PHE Emitter for photo interrupter

4 VH Head drive power

5VH Head drive power

6 VH Head drive power

7DI Data in

8 STB2 Strobe 2

9 STB3 Strobe 3

10 Vdd Logic power

11 GND Head ground

12 GND Head ground

13 GND Head ground

14 GND Head ground

15 GND Head ground

16 GND Head ground

17 TM Thermistor

18 NC NC

19 STB1 Strobe 1

20 LAT Data latch

21 CLK Clock

22 VH Head drive power

23 VH Head drive power

24 VH Head drive power

25 SW Platen switch

26 SW Platen switch

27 MT A Excitation signal A

28 MT A Excitation signal A

29 MT B Excitation signal B

30 MT B Excitation signal B

1.Connector(FPC)specication(CN4)

(1) Connector

Mechanical unit side: FPC connector

Remote side (housing site): 52610-3071 (made by Molex)

(2) Pin assignment on the mechanical side

FTP-627MCL601

FTP-627MCL401/601

Platen unit

Thermal head

Motor

Sensor (Photo-

interruptor)

24, 23, .....................2,1

Connector No

(FPC pin numbers)

FPC

Connect terminal:

surface side

2.Cutter(CN4/CN5)

Connector on control circuit side: 52610-0871 Molex or equivalent

M I

.oN langiS O/I stnetnoC .oN langiS O/I stnetnoC

1 NESV I rewoprosnesrepaP 2 EHP O )rottime(rotpurretniotohP

3 KHP O )edohtac(rotpurretniotohP 4 AT AlangiseticxerotoM

5 AT AlangiseticxerotoM 6 BT BlangiseticxerotoM

7 BT BlangiseticxerotoM 8 CN — detcennoctoN

Japan

Fujitsu Component Limited

Gotanda-Chuo Building

3-5, Higashigotanda 2-chome, Shinagawa-ku

Tokyo 141 8630, Japan

Tel: (81-3) 5449-7010

Fax: (81-3) 5449-2626

Email: [email protected]

Web: www.fcl.fujitsu.com

NorthandSouthAmerica

Fujitsu Components America, Inc.

250 E. Caribbean Drive

Sunnyvale, CA 94089 U.S.A.

Tel: (1-408) 745-4900

Fax: (1-408) 745-4970

Email: [email protected]

Web: http://us.fujitsu.com/components/

Europe

Fujitsu Components Europe B.V.

Diamantlaan 25

2132 WV Hoofddorp

Netherlands

Tel: (31-23) 5560910

Fax: (31-23) 5560950

Email: [email protected]

Web: emea.fujitsu.com/components/

AsiaPacic

Fujitsu Components Asia Ltd.

102E Pasir Panjang Road

#01-01 Citilink Warehouse Complex

Singapore 118529

Tel: (65) 6375-8560

Fax: (65) 6273-3021

Email: [email protected]

Web: http://www.fujitsu.com/sg/services/micro/components/

FujitsuComponentsInternationalHeadquarterOfces

owners.

Fujitsu Components America or its afliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our

products Fujitsu Components America, Inc. or its afliates reserve the right to change specications/datasheets without prior notice.

Rev. February 26, 2009.
