Fuji Xerox DocuPrint M225 z Manual de usuario

Unpack the machine and check the components

Read the Safety Guide first, then read this Quick Setup Guide for the correct installation

procedure.

NOTE:

• The components included in the box and the AC power plug may differ depending on your

country.

• The illustrations in this Quick Setup Guide are based on the DocuPrint M225 z.

• The USB cable is a standard accessory.

Network cable

Use a straight-through Category 5 (or greater) twisted-pair cable for 10BASE-T or

100BASE-TX Fast Ethernet Network.

Remove the packing materials and install the toner cartridge

Load paper in the paper tray

Connect the machine to your computer/mobile device

Connect the power cord and turn on the machine

Select your language (If needed)

(Only for certain models)

Drum Unit

(Pre-installed)

AC Power Cord

(only for certain

models)

Quick Setup Guide CD‑ROM

USB Interface Cable Inbox Toner

Cartridge

Telephone Line Cord Safety Guide Basic User's Guide

1. (DocuPrint M225 dw)

a. Press Menu.

b. Press ▲ or ▼ to display General Setup, and then press OK.

c. Press ▲ or ▼ to display Local Language, and then press OK.

(DocuPrint M225 z) Press Menu, 0, 0.

2. Press ▲ or ▼ to select your language, and then press OK.

3. Press Stop/Exit.

• Windows®PC with a CD-ROM drive, go to step 6A

• Windows®PC without a CD-ROM drive, go to step 6B

• Macintosh, go to step 6B

• Mobile device users with a WPS/AOSS™-supported access point/router, go to step 6C

Back Front

Select your country/language

(Initial setup only)

After turning on the machine, you may be required to set your

country or language (depending on your machine).

If required, follow the on-screen instructions.

Remove the orange part. Remove the orange part.

Adjust the paper guides.

Quick Setup Guide

DocuPrint M225 dw / DocuPrint M225 z

LEV122001-00

604E 77670 MB3555E2-1 (Edition 1)

October 2014

Fuji Xerox Co., Ltd. Printed in Vietnam

Configuration using the CD-ROM (Windows®)

Follow the on-screen

instructions until the

Connection Type screen

appears.

Finish

Download the full driver and software package by visiting the Fuji Xerox website at http://www.fujixeroxprinters.com/.

After you download the driver and software package, follow the on-screen instructions until the Connection Type screen appears. Refer to 6A Configuration using the CD-ROM

(Windows®).

If your wireless LAN access point/router supports automatic wireless (one-push) setup (WPS/AOSS™), you can set up your machine without using a computer.

Connection Type

For USB Connection

For Wired Network Connection

Connect a network cable first.

For Wireless Network Connection

We recommend preparing a USB cable

to use temporarily during the wireless

setup.

Follow the on-screen

instructions to continue

installation.

NOTE:

If connection is unsuccessful, repeat this step.

One-push wireless setup for mobile devices (Wireless models only)

Wireless Network Connection

[Recommended]

Select this option if you have a USB cable to

use temporarily for wireless setup.

Select this option if you do not have a USB cable.

Follow the on-screen

instructions to continue

installation.

NOTE:

If connection is unsuccessful, repeat this step.

Configuration without using the CD-ROM (Windows®without CD-ROM drive or Macintosh)

Finish

Press the WPS or AOSS™ button on your

wireless LAN access point/router.

Press the WiFi button on your machine.

Wireless setup is now complete.

NOTE:

If the Fuji Xerox screen does not appear automatically, go to Computer.

(For Windows®8: click the (File Explorer) icon on the taskbar, and then go to Computer.)

Double-click the CD-ROM icon, and then double-click start.exe.

604E 77670 MB3555E2-1 LEV122001-00
