Frontgate BORDEAUX DINING TABLE Manual de usuario

BORDEAUX DINING TABLE

F R O N T G A T E

BORDEAUX DINING TABLE

F R O N T G A T E

PART LIST BOX 1: HARDWARE ENCLOSED :

NUMBER OF PEOPLE TO INSTALL :ASSEMBLY TIME

RECOMMENDED 3 PEOPLE OR MORE UNDER 20 MINUTES

PRE ASSEMBLY INSTRUCTIONS :

1. Do not throw away packaging materials until the assembly is complete. Partsmight be

accidentally thrown away.

ASSEMBLY INSTRUCTION: TOOL REQUIRED (INCLUDED):

STEP 1 :

1. Open the table top (A) by unlocking the leaf-lock and pulling the table top open as shown figure 1,in

picture 1.

STEP 2 :

Part # Description QTY Part # Description QTY

A

.

Top

1 pc

C.

Pedestal

1 pc

B.

Extension

Leaf

1 pc

Part # Description QTY

D

.

Wooden Dowels

2 Pcs

Part # Description QTY

E

,F,G

.

4 Set

Picture.

1

Figure1

A

Figure 2

A

BORDEAUX DINING TABLE

F R O N T G A T E

2. Insert wooden dowels (D) into the holes on the pedestal (C).Place the table top (A) to the

pedestal (C), place spring washers (G), followed by flat washers (F) onto the hexagonal bolts

(E), then insert the hexagonal bolts (E,F&G) through the holes of the bridge(A) into the insert

nut in the pedestal (C). Tighten with wrench (H) as shown in fig 4, picture 2.

STEP 3 :

3a. If extension leaf is going to be used, please ensure to unlock the leaf-lock before opening the

table top. Grip both table ends and pull to open.

3b.Insert extension leaf (B) into position, make sure the leaf pins match with the corresponding

holes.

3c.Slide/close both ends simultaneously until leaves are securely in place. Lock the leaf-lock.

Figure

3

Picture.

2

Picture.

3

Figure

5

C

Figure 4

Page 4 of 4

F R O N T G A T E

BORDEAUX DINING TABLE

CARE &MAINTENANCE : Use mild detergent and water to clean. Always use a soft cloth to wipe

down and clean your table. Do not use any abrasive or acidic cleaners as this may mar or

damage the finish. For additional care and cleaning instructions, contact our Product Specialist

teams at 1-800-537-8484.

Please contact one of Our Product Specialists for assembly assistance orquestions at

1-800-537-8484 or email [email protected]. Specialists are available weekdays 8:00 a.m. to

8:00 p.m. EST or Saturday 9:30 a.m. to 6:00 p.m.
