FRONIUS RC Panel Pro Manual de usuario

Fronius prints on elemental chlorine free paper (ECF) sourced from certified sustainable forests (FSC).

/ Perfect Charging / Perfect Welding / Solar Energy

RC Panel Pro

EN-US

Operating instructions

42,0426,0282,EA 003-22112021

General

Safety WARNING!

Incorrect operation and incorrectly performed work can cause serious injury and

damage to property.

All work listed in this document may only be performed by trained specialist personnel.

All functions described in this document may only be used by trained specialist person-

nel. All work and functions described may only be performed and used once the follow-

ing documents have been read and understood in full:

▶This Document

▶All Operating Instructions for system components, especially the safety rules

Device Concept The remote control has the same functionality as the power source’s control panel. A

precise description of the possible settings can be found in the power source's Operating

Instructions.

NOTE!

To be able to use the remote control, the welding system must have a TPS/i power

source.

NOTE!

Because of firmware updates, certain functions may be available that are not de-

scribed in these Operating Instructions or vice versa.

Scope of Supply

(1)

(2)

(3)

(1) Remote control

(2) TPS/i Key Card

(3) This document

Technical data Supply voltage + 24 V DC

Protection class IP 44

Marks of conformity CE, FCC

EN-US

Dimensions (l x w x h) 260 x 220 x 60 mm

10.24 x 8.66 x 2.36 in.

Notes on Radio

Certification

The device is equipped with a wireless module.

Wireless modules in the USA require FCC certification:

FCC

This device complies with Section 15 of the FCC Rules. Operation is subject to the fol-

lowing conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may cause

undesired operation of the device.

FCC ID: QKWSPB209A

Industry Canada RSS

This device complies with Industry Canada license-exempt RSS standards. Operation

is subject to the following conditions:

(1) This device may not cause interference; and

(2) This device must accept any interference, including interference that may cause

undesired operation of the device.

IC: 12270A-SPB209A

Unless otherwise expressly permitted by the manufacturer, changes or modifications to

the wireless module are not allowed and lead to a loss of the right of use of the device by

the user.

NOTE!

This device has been tested and meets the limit values for a Class A digital device

as per Section 15 of the FCC Rules.

These limit values are designed to provide adequate protection against harmful interfer-

ence when the device is operated in a commercial environment. This device generates,

uses and can emit high-frequency energy, and if it is not installed and used as per the

Operating Instructions, it may cause harmful interference to wireless communication. Op-

erating this device in a residential area may lead to harmful interference, which the user

must rectify at their own cost

Controls, connections and indicators

Keys and Sym-

bols

(1)

(2)

(3)

(4)

(1)

(5)

(6)

(7)

(1) Control dial with rotary/push button function

For selecting elements, setting values and scrolling through lists

(2) Special function button

For selecting special functions depending on configuration

(3) Gas-test button

For setting the required amount of gas on the gas pressure regulator.

After pressing the gas-test button, gas is emitted for 30 seconds. Pressing the

button again ends the process early

(4) Touch display

(5) Wire-threading button

For threading the wire electrode into the torch hosepack without gas or current

(6) Wire-return button

For retracting the wire electrode without gas or current

NOTE!

Only retract the wire electrode a small amount at a time, to avoid the wire elec-

trode becoming entangled during retraction.

(7) Reading zone for TPS/i Key Card and TPS/i Key Fob

For locking/unlocking the remote control using the TPS/i Key Card and TPS/i

Key Fob

EN-US

(8)

(9)

(8) Pivoting mounting and positioning bracket

(9) USB port

For connecting USB flash drives (service dongle, license key, etc.)

Installation and Startup

Mount Remote

Control on a

Handle Tube

CAUTION!

Danger of injury and damage to property due to falling remote control.

Always secure the remote control against falling.

Connect Remote

Control to Sys-

tem Components

EN-US

Fronius International GmbH

Froniusstraße 1

4643 Pettenbach

Austria

contact@fronius.com

www.fronius.com

Under www.fronius.com/contact you will find the adresses

of all Fronius Sales & Service Partners and locations.

spareparts.fronius.com

SPAREPARTS

ONLINE
