Frigidaire FRS26TS6D Manual de usuario

Product No. FRS26TS6DW1 FRS26TS6DW2

Series R134a Gallery R134a Gallery

Color white white

Volts 115 115

Wiring Diagram 241526901 241526901

Owner's Guide 241572800 241572800

Market North America North America

Energy Guide 241538776 241538776

Service Data Sheet 240389618 240389618

N58L00001.eps N58FCCBBB2.eps N58RCCBBB13.eps N58BAAAAB1.eps

N58SJCIBD1.eps N58TAAAAB4.eps N58CAAAAC0.eps N58XBAAAB0.eps

N58YDAAACO.eps n58I115T.eps W241526901A.eps S241526901A.eps

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995416160

04/09/10

(EN/SERVICE/KHB)

357

SIDE-BY-SIDE

REFRIGERATOR

Model No.

FRS26TS6D

Publication No: 5995416160 FRS26TS6D

09/04 2

FREEZER DOOR

21C

22C

13A

22A

21A

N58FCCBBB2

FRS26TS6D Publication No: 5995416160

# Functional Parts 3 09/04

* Non-Illustrated Parts

FREEZER DOOR

Model Index: AFRS26TS6D (FRS26TS6DW1)

BFRS26TS6D (FRS26TS6DW2)

POS. NO PART NO. DESCRIPTION

1 # 240390602 A B Gasket-frzr door, white, magnetic

4A 240334201 A B Bin-door, frzr-upper

4B 240351601 A B Bin-door

11 240554212 A B Door-frzr, white, complete assy

13A 240537102 A B Door Stop, white, frzr

18 240359106 A B Handle-door, white

21 218781100 A B Screw, pan head, 8-18 x 0.625

21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

21C 240521302 A B Screw, #8-18 x 3/4

22A 240328202 A B Bearing-hinge(frz), closer

22C 240328402 A B Bearing-hinge, upper

37 240359201 A B Trim-handle, 30.13", white, lower

68 241525101 A B Chute-ice

72 240421701 A B Button-handle mtg, dovetail

73 218396700 A B Block-handle mtg, dovetail

74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

* 240352102 A B Connector-water, straight

* 240552102 A B Harness-wiring, door

* 240470401 A B Connector-amp

* 5303918256 A B Dispenser heater kit

Publication No: 5995416160 FRS26TS6D

09/04 4

REFRIGERATOR DOOR

21C

21A

22B

N58RCCBBB13

FRS26TS6D Publication No: 5995416160

# Functional Parts 5 09/04

* Non-Illustrated Parts

REFRIGERATOR DOOR

Model Index: AFRS26TS6D (FRS26TS6DW1)

BFRS26TS6D (FRS26TS6DW2)

POS. NO PART NO. DESCRIPTION

2 # 240390601 A B Gasket-refr door, white, magnetic

4 240323002 A B Bin-door, pseudo, bottom

7 240326203 A B Door-dairy

12 240572601 A B Label-nameplate

13 240537101 A B Door Stop, white, ref

15 240451968 A B Door-refr, white, complete assy

18 240359101 A B Handle-door, white

21 218781100 A B Screw, pan head, 8-18 x 0.625

21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

21C 240521302 A B Screw, #8-18 x 3/4

22 240328201 A B Bearing-hinge(ref), closer

22B 240328401 A B Bearing-hinge(ref), upper

37 240359201 A B Trim-handle, 30.13", white, lower

49 240356402 A B Bin-door, gallon

72 240421701 A B Button-handle mtg, dovetail

73 218396700 A B Block-handle mtg, dovetail

74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995416160 FRS26TS6D

09/04 6

CABINET

40 66

14A

100

21C

30A

10A

N58BAAAAB1

150

FRS26TS6D Publication No: 5995416160

# Functional Parts 7 09/04

* Non-Illustrated Parts

CABINET

Model Index: AFRS26TS6D (FRS26TS6DW1)

BFRS26TS6D (FRS26TS6DW2)

POS. NO PART NO. DESCRIPTION

10 240435908 A B Cover-air duct

10A 240475907 A B Cover-evap coil, lower

11 5303208309 A B Plug-hole, factory test

14 # 240505801 A B Switch, light/lamp

14A# 215486600 A B Switch-light/lamp

21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500

22 240457701 A B Plate-door closer

23 240402701 A B Screw-#10-32 x 1/4 flat hd

28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special

30 240419101 A B Bracket-lower hinge, ref

30A 240419102 A B Bracket-lower hinge

37 240337601 A B Trim-cabinet corner, white, (2)

38 240327201 A B Bracket-upper hinge

40 240327005 A B Cover-upper hinge, white

41 241550801 A B Grommet-shelf mtg, 1.40" long

41* 241550701 A B Grommet-shelf mtg, .96" long

42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8

43 240335003 A B Roller Assy, front, (2)

45 241500301 A B Screw, hex washer head, 8-18AB x 0.500

47 240349402 A B Channel-shelf mtg, side, (2)

58 218781100 A B Screw, pan head, 8-18 x 0.625

66 5304424968 A B Damper Cover Assy

66* 240518802 A B Pin-push, push-in, plastic

72 240324402 A B Grille/Kickplate, white

81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

82 5304418225 A B Roller, compressor base, rear, (2)

83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin

89 240326104 A - Cover, access, system compt, with label

89 241574602 - B Cover access

90 218249808 A B Seal-coil cover

91 240380101 A B Duct-ice maker

92 216850900 A B Screw, hex washer hd, 1/4 x 7/8, hinge mtg

100 240423701 A B Support, crisper cover, front, (4)

100* 240350802 A B Support, crisper cover, rear, (4)

150 240368701 A B Guide-control bulb

* 240396801 A B Clamp, tube/wiring, nylon, black/natural

* 240479601 A B Plug, button, cab liner holes, (2)

* 240481601 A B Shim-lower hinge

* 5303305324 A B Paint, touch-up, white

Publication No: 5995416160 FRS26TS6D

09/04 8

SHELVES

42A

123

11B

11A

126

39B

100

24A

24B

25A

47A

101

26A

N58SJCIBD1

140

26A

120

122

121

141

142 140A

109 15A

16A

11C

FRS26TS6D Publication No: 5995416160

# Functional Parts 9 09/04

* Non-Illustrated Parts

SHELVES

Model Index: AFRS26TS6D (FRS26TS6DW1)

BFRS26TS6D (FRS26TS6DW2)

POS. NO PART NO. DESCRIPTION

11 240338802 A B Shelf-freezer, flip-up

11A 240338702 A B Shelf-freezer, fixed wire

11B 240338704 A B Shelf-freezer, fixed wire

11C 240324101 A B Shelf-pizza

15 241552801 A B Light Bulb

15A 241555401 A B Light Bulb

16 240590401 A B Socket-light

16A# 241513901 A B Socket-light

16A* 241537502 A B Harness-wiring

24 240355207 A B Shelf-"Spill-Safe", cantilever, half width, fixed

24A 240350108 A B Shelf-"Spill-Safe", cantilever, sliding

24B 240355208 A B Shelf-"Spill-Safe", fixed

25 240350702 A B Cover-crisper pan, upper

25* 240362101 A B Clip-slide, cover-crisper

25A 240350902 A B Cover-crisper pan, lower

26 240351005 A B Pan-crisper, upper

26* 240349801 A B Clip-slide, pan-crisper

26A 240362201 A B Control-humidity

27 240351205 A B Pan-crisper, lower

39 240430702 A B Trim-shelf, 12.39", front

39B 240430706 A B Trim-shelf, 11.21", front

42 240356501 A B Track, meat pan hanger, RH

42A 240349701 A B Hanger-meat pan, LH

42A* 240349901 A B Block-meat pan rail, LH

42A* 240350001 A B Spring-meat pan rail

42A* 240356702 A B Seal-meat pan

47 240350633 A B Insert-pan cover, glass

47A 240350603 A B Insert-pan cover, glass

49 240564401 A B Basket-sliding

51 240343002 A B Hanger-basket, RH

52 240343102 A B Hanger-basket, LH

62 240342805 A B Pan-meat

81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

97 240545303 A B Water Tank Assy, coiled tubing, front filter

100 240326302 A B Cover-water tank

101 218493100 A B Screw, hex washer head, 8-18AB x 1-3/4

109 240351301 A B Base-crisper light socket

120 241559001 A B Shelf-ice cream

121 241561001 A B Rail-ice cream shelf, LH

122 241561201 A B Rail-ice cream shelf, RH

123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438

126 218867405 A B Channel, auger mtg, LH

126 218867406 A B Channel, auger mtg, RH

140 240430501 A B Channel, wtr tube cover

140A 240430503 A B Channel, wtr tube cover

141 240585404 A B Bracket-light socket

142 240582701 A B Shield-light, deli pan

* 240427201 A B Heater-freezer control

Publication No: 5995416160 FRS26TS6D

09/04 10

CONTROLS
