Frigidaire FGF324BH Manual de usuario

PRODUCT NO. BASE MODEL NO. SERIES COLOR MARKET

FGF324BHDB FGF324BH Frigidaire almond USA

FGF324BHDC FGF324BH Frigidaire almond USA

FGF324BHWB FGF324BH Frigidaire white USA

FGF324BHWC FGF324BH Frigidaire white USA

Publication No.

5995345344

001020

-EN/SERVICE/KHB

369

GAS

RANGE

Model No.

FGF324BH

FACTORY PARTS CATALOG

RANGE

WIRING DIAGRAM - #316002174

OWNER’S GUIDE - # 316135908

ELECTROLUX HOME PRODUCTS NORTH AMERICA

P.O. BOX 212378, Augusta, GA 30917

01/01 2

Publication No. FGF324BH

5995345344

BACKGUARD

# = Fast-moving Parts 3 01/01

* = Non-Illustrated Parts

FGF324BH Publication No.

5995345344

A = FGF324BH (FGF324BHDB)

B = FGF324BH (FGF324BHDC)

C = FGF324BH (FGF324BHWB)

D = FGF324BH (FGF324BHWC)

POS. NO PART NO DESCRIPTION

1 316028700 A B C D Shield-backguard,galv ,rear wall

11 316061856 A B C D Trim-wrapper,black ,textured

12 # 316032404 A B C D Thermostat

12* 316097602 A B C D Insulator

15 316023108 A B C D Support-backguard,RH

15A 316023109 A B C D Support-backguard,LH

19 316082652 A B C D Panel-control,metal ,19

20# 316113200 A B C D Clock-timer

23 316079002 A B C D Bracket-clock mtg

24 # 316118100 A B C D Switch-oven light,rocker ,black

28 5303272306 A B C D Push Button,clock set ,black ,(2)

29 5303272305 A B C D Button-selector,clock/timer ,black

32 316109506 A B C D Knob thermostat,black

36 316109507 A B C D Knob-top valve,black ,(4)

40 316062325 A B C D Panel-manifold

42 316083300 A B C D Trim-vent

50 316096900 A B C D Bezel-nameplate,black

51 316095420 A B C D Nameplate,Frigidaire ,black

56 316074907 A B C D Deflector-flue, black

* 316021105 A B C D Screw,hex head cup pt ,8-18 x 0.375, blk,back/bodyside

* 316021108 A B C D Screw,cup pt,8-18 x 0.375,chrom, hing,ind lgt,manifold pnl

* 316021110 A B C D Screw,8-18 x 0.500 ,black

BACKGUARD

01/01 4

Publication No. FGF324BH

5995345344

BURNER

# = Fast-moving Parts 5 01/01

* = Non-Illustrated Parts

FGF324BH Publication No.

5995345344

BURNER

A = FGF324BH (FGF324BHDB)

B = FGF324BH (FGF324BHDC)

C = FGF324BH (FGF324BHWB)

D = FGF324BH (FGF324BHWC)

POS. NO PART NO DESCRIPTION

1 316113500 A - C - Manifold Pipe

1 # 316134400 - B - D Manifold Pipe

2 # 316098600 A - C - Valve-top burner,2-position ,(4)

2* 316048200 A - C - Screw-,hex wshr hd,1/4-20 x 0.31, valve mount,w/gasket

2 # 316134200 - B - D Valve-top burner,natural gas, 2 position,(4)

2* 316134300 - B - D Screw,10-24 ,valve mounting

3 316001828 A B C D Wiring Harness,ignitor ,with switches

8 # 5303912606 A - C - Spark Module

8 # 316135700 - B - D Spark Module

10 # 316039002 A - C - Burner-top,front

10 # 316103800 - B - D Burner-top,venturi ring

10A# 316039003 A - C - Burner-top,rear

10A# 316103801 - B - D Burner-top,venturi ring

11 # 316081700 A - C - Ignitor-top burner,33"

11 # 316081702 - B - D Ignitor-top burner,33"

11A# 316081701 A - C - Ignitor-top burner,50"

11A# 316081703 - B - D Ignitor-top burner

12 3016993 A B C D Retainer-ignitor

14 # 316082900 A B C D Regulator-pressure

14* 316021104 A B C D Screw-regulator/brkt, hex, 8-18 x 3/8, nick, 3

17 # 3203459 A B C D Valve-safety

18 # 316114300 A B C D Burner-oven

19 # 5303935066 A B C D Ignitor-oven,kit ,w/nut & instr

20 3203265 A B C D Baffle-oven burner

21 5303013272 A B C D Nut,hex head sems

36 316083000 A B C D Tubing,3/8 ,alum

48 3018603 A B C D Bracket-support,oven burner

49 3131438 A B C D Bracket,safety valve

* 5303271648 A B C D Screw,wafer hd sq dr ,8-18AB x 0.500, burner box

01/01 6

Publication No. FGF324BH

5995345344

BODY

# = Fast-moving Parts 7 01/01

* = Non-Illustrated Parts

FGF324BH Publication No.

5995345344

BODY

A = FGF324BH (FGF324BHDB)

B = FGF324BH (FGF324BHDC)

C = FGF324BH (FGF324BHWB)

D = FGF324BH (FGF324BHWC)

POS. NO PART NO DESCRIPTION

1 316029416 A B C D Back-main,1

3 316081036 A B - - Panel-bodyside,almond ,RH

3 316081037 A B - - Panel-bodyside,almond ,LH

3 316081034 - - C D Panel-bodyside,white ,RH

3 316081035 - - C D Panel-bodyside,white ,LH

4 316067206 A B C D Burner Box

4* 316130300 - B - D Spacer-burner box

5 316129200 A B C D Screw-leveling,plastic ,with stop

6 316067902 A B C D Rack-oven

7 316007001 A B C D Hinge-oven door,(2)

8 5303300701 A B C D Panel-oven bottom

8* 316064600 A B C D Support-oven bottom

14 316116400 A B C D Socket-light/lamp,oven

15 5303013071 A B C D Light Bulb/Lamp

21 3014099 A B C D Spacer-bodyside, (8)

27 5303284616 A B C D Clip-thermo bulb

28 3011813 A B C D Clip-wire, bodyside

32 316107501 A B C D Channel-burner supt

32* 5303289684 A B C D Fastener,tanden wire ,(2)

33 316055601 A B C D Shield-spark module

34 3018607 A B C D Cover Plate

35 316116600 A B C D Gasket-flue

36 316133001 A B C D Flue,36

39 3202006 A B C D Cord-electric power

41 3131570 A B C D Cover-hinge cutout

43 3131732 A B C D Screw-oven bottom, 8-18 x 1.438

44 3131903 A B C D Bumper-door/drawer, rubber

54 5303271606 A B C D Housing-oven light

55 5303289358 A B C D Shield-flue

58A 3017142 A B C D Insulation,oven wrapper

58B 3203541 A B C D Insulation,oven back

60 5303015372 A B C D Cover-oven front

73 316109902 A B C D Base-low broil

93 316110000 A B C D Shield,metal ,galvanized ,ignitor

170 5303935180 A B C D Anti-tip Kit,w/bracket,screw

170* 316107200 A B C D Bracket,anti-tip

170* 316112500 A B C D Template, Anti-tip bracket

170* 316116000 A B C D Screw,concrete tpg ,1.75 inch, anti-tip brkt

185 316112900 A B C D Shield-thermo bulb

* 316021105 A B C D Screw, hex head cup pt, 8-18 x 0.375, blk,back/bodyside

* 316021108 A B C D Screw,cup pt,8-18 x 0.375,chrom, hing,ind lgt,manifold pnl

01/01 8

Publication No. FGF324BH

5995345344

TOP/DRAWER

# = Fast-moving Parts 9 01/01

* = Non-Illustrated Parts

FGF324BH Publication No.

5995345344

TOP/DRAWER

A = FGF324BH (FGF324BHDB)

B = FGF324BH (FGF324BHDC)

C = FGF324BH (FGF324BHWB)

D = FGF324BH (FGF324BHWC)

POS. NO PART NO DESCRIPTION

1 316110201 A B C D Carriage, broiler

2 316110101 A B C D Liner-low broil

2A 316110800 A B C D Shield-broiler

4 316056206 A B - - Panel-drawer,almond

4 316056205 - - C D Panel-drawer,white

4* 316021113 A B - - Screw,8-18 x 0.500 ,almond

4* 316021112 - - C D Screw,8-18 x 0.500 ,white

5 316129100 A B C D Fastener-spacer,push-in nut ,nylon

9 316081900 A B C D Pan-broiler

10 316082000 A B C D Insert-broiler pan

13 316111502 A B C D Glide-low broil,inner

13A 316111600 A B C D Glide-low broil,inner

13B 316111501 A B C D Glide-low broil,outer

16 5303285572 A B - - Main Top,almond

16 5303285552 - - C D Main Top,white

17 316057601 A B C D Rod-maintop support

18 5303273062 A B C D Hinge-main top,RH

18A 5303273063 A B C D Hinge-main top,LH

20 # 316088900 A B C D Grate,black ,(4)

30 316111400 A B C D Insulation,broiler drawer

39 3201268 A B C D Handle-drawer,brushed chrome

39* 5303280308 A B C D Screw-handle mtg, wafer hd sq dr, 10-24T x 2.00

85 316115600 A B C D Rack-Low Broil

* 316021105 A B C D Screw, hex hd cup pt, 8-18 x 0.375, blk,back/bodyside

* 316021108 A B C D Screw, cup pt,8-18 x 0.375,chrom,hing,ind lgt,manifld pnl

* 316021110 A B C D Screw, 8-18 x 0.500 ,black

* 316021120 A B C D Screw, shoulder head, 8-18 x 5/8, (2), square drive

* 5303280311 A B C D Screw, wafer hd sq dr, 10-32 x 0.312, (2)

01/01 10

Publication No. FGF324BH

5995345344

DOOR
