Frigidaire FEF389CFBJ Manual de usuario

FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF389CFBJ FEF389CF BLACK/BLACK USA

FEF389CFSJ FEF389CF WHITE/WHITE USA

Publication No.

5995322970

990512

-EN/SERVICE /SBR

369

WIRING DIAGRAM # - 316002645

OWNER’S GUIDE # - 316000284

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF389CFBJ

FEF389CFSJ

06/98 2

Publication number

5995322970 FEF389CFBJ, FEF389CFSJ

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF389CFBJ, FEF389CFSJ 5995322970

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF389CF (FEF389CFBJ)

B = FEF389CF (FEF389CFSJ)

POS. NO PART NO DESCRIPTION

* 316000284 A B Owner’s Manual

* 316002645 A B Wiring diagram

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

* 316085600 A B Insulator-shield thermostt

* 316112500 A B Template, Anti-tip bracket

* 5303292005 A B Screw-switch/handle,8-32 x 5/32

1 316081601 A B Shield-backguard,rear wall

2 316015905 A B Shield-backguard,inner

3 3131275 A B Lamp-fluorescent,backguard

4 3051222 A B Receptacle-lamp,RH

4A 3051223 A B Receptacle-lamp,LH

5 # 316053200 A B Receptacle-starter

6 # 3206218 A B Starter-lamp

10 # 316099800 A B Ballast-lamp

13A# 316095500 A B Switch-warmer, infinite , drawer/zone

14 316022504 A B Light-indicator,250v

14A 316022500 A B Light/Lamp, warmer, indicator ,

drawer/zone, 125 V

15 316049104 A B Support-backguard,RH

15A 316049105 A B Support-backguard,LH

18 316026900 A - End Cap,black ,RH

18 316026904 - B End Cap,white ,RH

18A 316026901 A - End Cap,black ,LH

18A 316026905 - B End Cap,white ,LH

19 316024538 - B Panel-control,white

19 316024540 A - Panel-control,black

20 # 316080010 A B Clock/Timer,EOC

20 # 5303935116 - B Clock/Timer,EOC ,white

20 # 5303935118 A - Clock/Timer,EOC ,black

21 316024900 A - Trim-canopy/shield,black

21 316024902 - B Trim-canopy/shield,white

22 316059901 A B Support-receptacle

23 316060002 A B Bracket-clock mtg

24 # 316005607 - B Switch-rocker,oven light ,white

24 # 316005612 A - Switch-rocker,oven light ,gray

24B# 316086900 A - Switch-rocker,dual element ,gray

24B# 316086901 - B Switch-rocker,dual element ,white

31A 316095600 A - Knob-warmer,black

31A 316095601 - B Knob-warmer,white

36 316025105 A - Knob-control,infinite sw ,gray ,(4)

36 316025106 - B Knob-control,infinite sw ,white

40 316025800 A - Panel-manifold

40 316025808 - B Panel-manifold,white

46 316040201 A B Lens-light/lamp,indicator ,red

54 # 316021500 A B Switch-infinite, 6" element

54B# 316049800 A B Switch, infinite , dual element

60 316021101 A - Screw-8-18 ½ #5HD Black

60 316021116 - B Screw-8-18 ½ HD #5 White

64 316062400 A B Retainer plate

06/98 4

Publication number

5995322970 FEF389CFBJ, FEF389CFSJ

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 06/98

Publication number

FEF389CFBJ, FEF389CFSJ 5995322970

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF389CF (FEF389CFBJ)

B = FEF389CF (FEF389CFSJ)

POS. NO PART NO DESCRIPTION

* 3203550 A B Plug-button

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316045000 A B Clip-wire,harness ,main top

* 5303051099 A B Nut,hex ,#10-32

* # 316001352 A B Harness-wiring,main

1 316080804 A B Back-main, short,dipped ,black

3 316081034 - B Panel-bodyside, white ,RH

3 316081035 - B Panel-bodyside, white , LH

3 316081038 A - Penel-bodyside, black, RH, textured

3 316081039 A - Panel-bodyside, black, LH, textured

5 316107300 A B Screw-leveling

6 316067902 A B Rack-oven

6A 316085400 A B Rack,broiler pan

7 316007002 A B Hinge-oven door,(2)

8 3203540 A B Panel-oven bottom

9 316073800 A B Pan-broiler

10 3205234 A B Insert-broiler pan

12 # 316027701 A B Switch-oven light

13 316026800 A B Rod-light switch /door

14 316116400 A B Socket-light

15 5303013071 A B Light Bulb/Lamp

16 08011086 A B Lens-light/lamp, glass , oven

17 316087500 A B Retainer-lens

18 # 316036300 A B Latch-door

21 3014099 A B Spacer-bodyside, (8)

25A 316092400 A B Shield-warmer,upper

28 3011813 A B Clip-wire, bodyside

30 5303283574 A B Bracket-hinge,main top RH

30A 5303283575 A B Bracket-hinge,main top LH

33A 316095301 A B Shield-rear wall,lower

37 # 316111202 A B Probe-oven temp

41 3131570 A B Cover-hinge cutout

44 3131903 A B Bumper-door/drawer, rubber

45 316066100 A B Shield-wire, s/t vent

57 316081101 A B Cover-access

58 3200847 A B Insulation,oven bottom

58A 316047707 A B Insulation, 1" ,oven wrapper

58A 316047708 A B Insulation, 2" ,oven wrapper

58B 316054201 A B Insulation,oven back

58B 316054202 A B Insulation, 1" ,oven back

59 316073602 A B Tube-oven vent

59A 316023601 A B Tube-oven vent,upper

59B 316040100 A B Bracket-mounting,vent tube

62 # 5303935061 A B Terminal Block

63 5301145190 A B Plate-ground strap

66 # 5303051140 A B Element-broil

67 # 316075102 A B Element-bake,lower oven

68 316075300 A B Support-element, broil

71 316015805 A B Shield-rear wall

72 5303285692 A B Cover-light/switch rod

77 316105500 A B Glide-warmer, outer/RH & LH , (2)

82 5303289913 A B Shield-insulation

87 316081200 A B Bracket-cable mtg

88 316026400 A B Rod-latch,auto

06/98 6

Publication number

5995322970 FEF389CFBJ, FEF389CFSJ

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 7 06/98

Publication number

FEF389CFBJ, FEF389CFSJ 5995322970

CAUTION: Use the part number on all orders, not the position number.

BODY

89 # 316028107 A B Motor-latch/lock

106 316026600 A B Bracket-motor mtg

107 316026701 A B Cover-fan

108* 316021111 A B Screw,8-18 x 1.500

108# 316090500 A B Motor-fan

109 316090600 A B Fan Blade

110 316090700 A B Washer,fan motor

111 316090800 A B Nut-fan retainer

112 316082700 A B Relay,oven door lock

155 316095201 A B Shield-drawer, front warmer

170 316107200 A B Anti-tip bracket

170* 316116000 A B Screw-Anti tip, 1.75" concrete

06/98 8

Publication number

5995322970 FEF389CFBJ, FEF389CFSJ

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 9 06/98

Publication number

FEF389CFBJ, FEF389CFSJ 5995322970

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

A = FEF389CF (FEF389CFBJ)

B = FEF389CF (FEF389CFSJ)

POS. NO PART NO DESCRIPTION

* 316001917 A B Harness-warmer drawer

* 316001918 A B Harness-main, warmer drawer

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

* 316021112 - B Screw-8-18x1/2 Tr Sqd White

* 316045000 A B Clip-wire,harness ,main top

* 316112101 A B Cleaner-cooktop

* 5303280311 A B Screw, waf hd sdr , 10-32 x 5/16 , (2)

* # 316001745 A B Harness-top elements

1 316115901 A B Drawer-warmer

2 316092901 A B Liner, drawer

4 316056201 - B Panel-drawer,white

4 316056203 A - Panel-drawer,black

13 316105602 A B Glide-warmer,inner RH

13A 316105601 A B Glide-drawer, inner, LH

14 3206216 A B Plug-button, glide

15A# 316010203 A B Element-surface,radiant , small/6 inch ,

1200W,limit sw incl

15B# 316049703 A B Element-surface,radiant ,dual ,

2100W/1000W,limit sw incl

15C# 316098200 A B Element-warmer,120V/100W

15D# 316049702 A B Element-surface,radiant ,9" ,dual ,

2100W/700W,limit sw. incl.

16 316098120 - B Main Top,glass ,white

16 316098122 A - Main Top,glass ,black

18 5303273062 A B Hinge-main top,RH

18A 5303273063 A B Hinge-main top,LH

26 316099101 A B Channel-support, element , (2)

26A 316099201 A B Bracket-support, chassis

39 316026105 A - Handle-drawer,black

39 316026106 - B Handle-drawer,white

48 316100200 A B Shield-wire,main top

51 316105200 A B Light-indicator,hot surface ,assy ,(1)

52 316099400 A B Clip-spring, element mtg,(8)

80 316109700 A B Seal-door, warmer drawer

81 # 316093100 A B Element, warmer drawer

82 316093200 A B Bracket-mounting, warmer element

83 316093300 A B Shield-terminal, warmer drawer

84 316093500 A B Thermo disc, warmer drawer

85 316093600 A B Rack, warmer drawer

86 316095800 A B Clip-hold down, warmer element

87 316091900 A B Base-warmer

88 316099500 A B Pin-guide, (2)

96 316122000 A B Clip-lock, warmer drawer

97 316003802 A B Screw-Hex HD 3/16",6x3/8

06/98 10

Publication number

5995322970 FEF389CFBJ, FEF389CFSJ

CAUTION: Use the part number on all orders, not the position number.

DOOR
