Frigidaire FEF305PHDB Manual de usuario

FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF305PHDB FEF305PH ALMOND USA

FEF305PHWB FEF305PH WHITE USA

FEF305PHSA FEF305PH WHITE/WHITE USA

FEF305PHSB FEF305PH WHITE/WHITE USA

FEF305PHTA FEF305PH ALMOND/ALMOND USA

FEF305PHTB FEF305PH ALMOND/ALMOND USA

Publication No.

5995341509

000721

-EN/SERVICE /CML

369

WIRING DIAGRAM # - 316002675

OWNER’S GUIDE # - 316000629

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF305PHDB

FEF305PHWB

FEF305PHSA

FEF305PHSB

FEF305PHTA

FEF305PHTB

07/00 2

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB 5995341509

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021105 A B C D E F Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B C D E F Screw,cup pt ,8-18 x 0.375 ,hinge,ind lght brkt,manifold pnl

* 316021110 A B C D E F Screw,semi gim ,8-18 X 1/2 ,black

* 5303272555 A B C D E F Clip-backguard

1 3131123 A B C D E F Shield-backguard,rear wall

9 316133501 - B C - - F Trim-splasher,white

9 316133502 A - - D E - Trim-splasher,almond

11 316057002 A ----F Trim-wrapper

12 # 316032408 A - C - E F Thermostat-oven

12 # 5303212745 - B - D - - Thermostat-oven

14 3201726 A B C D E F Light/Lamp,indicator ,blue ,250 V

16 316042602 A B C D E F Plate,instrument mtg

19 316034120 A ----F Panel-control,black

19 316034128 - B C - - - Panel-control,white

19 316034129 ---DE- Panel-control,almond

30A 316064300 A B C D E F Nut,nylon

32 316123306 - - C - - - Knob-thermostat, white

32 316123307 A ----F Knob-thermostat,black

32 316123308 ----E- Knob-thermostat,almond

32 316123300 - B ---- Knob-thermostat,white

32 316123302 ---D-- Knob-thermostat,almond

36 316123303 A ----F Knob-infinite switch, black

36 316123304 - B C - - - Knob-infinite switch, white

36 316123305 ---DE- Knob-infinite switch, almond

40 316064009 A ----F Panel-manifold,black

40 316064015 ---DE- Panel-manifold,almond

40 316064030 - B C - - - Panel-manifold,white

44 3131468 A B C D E F Bracket,backguard

45A 316056902 A ----F Bolt-fastener,nylon

45A 316056903 ---DE- Bolt-fastener,nylon ,white

45A 316056904 - B C - - - Bolt-fastener,nylon ,almond ,(2)

46 316065801 A B C D E F Lens-light/lamp,indicator ,red

50 316096900 A ----F Bezel-nameplate,black

51 316095420 A ----F Nameplate, black

54 # 5303285142 A B C D E F Switch-6" element

54A# 5303285143 A B C D E F Switch-8" element

07/00 4

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 07/00

Publication number

FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB 5995341509

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021105 A B C D E F Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B C D E F Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl

* 5303051099 A B C D E F Nut,hex ,#10-32

* 5308014215 A B C D E F Screw

*# 316001559 A B C D E F Harness-main

* 3131903 A B C D E F Bumper-door/drawer

* 3203550 A B C D E F Plug-button

* 3051367 A B C D E F Clip-wire

1 316080804 A B C D E F Back-main

3 316081034 - B C - - F Panel-bodyside,white ,RH

3 316081036 A - - D E - Panel bodyside,almond ,RH

3* 316081035 - B C - - F Panel-bodyside,white ,LH

3A 316081037 A - - D E - Panel-body side,almond ,LH

4 5303271756 A B C D E F Burner Box

5 316129200 A B C D E F Screw-leveling,plastic ,with stop

6 316067902 A B C D E F Rack-oven

7 316007007 A B C D E F Hinge-oven door,(2)

8 3203540 A B C D E F Panel-oven bottom

9 316081900 A B C D E F Pan-broiler

10 316082000 A B C D E F Insert-broiler pan

21 3014099 A B C D E F Spacer-bodyside, (8)

27 5303284616 A B C D E F Clip-thermo bulb

29 3051162 A B C D E F Glide-drawer,front

41 3131570 A B C D E F Cover-hinge cutout

57 316081101 A B C D E F Cover-access

58 3200847 A B C D E F Insulation,oven bottom

58A 316047707 A B C D E F Insulation, 1" ,oven wrapper

58B 316054202 A B C D E F Insulation, 1" ,oven back

59 316073601 A B C D E F Tube-oven vent

62 # 5303935061 A B C D E F Terminal Block

63 5301145190 A B C D E F Plate-ground strap

66 # 5303051140 A B C D E F Element-broil

67 # 316075103 A B C D E F Element-bake

68 316075300 A B C D E F Support-element, broil

69 3051218 A B C D E F Plate-oven light

71 316015805 A B C D E F Shield-rear wall

82 5303289913 A B C D E F Shield-insulation

87 316081200 A B C D E F Bracket-cable mtg

170 316107200 A B C D E F Anti-tip bracket

170* 316116000 A B C D E F Screw-Anti-tip,1.75” concrete

170* 5303935180 A B C D E F Kit-AntiTip bracket (complete w/template & screws)

07/00 6

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 07/00

Type your model numbers here

CAUTION: Use the Kenmore part number on all orders, not the position number.

TOP/DRAWER

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021105 A B C D E F Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B C D E F Screw,cup pt ,8-18 x 0.375 ,hinge,ind lght brkt,manifold pnl

* 316021112 - B C - - F Screw-8-18x1/2 Tr Sqd White

* 316021113 A - - D E - Screw-8-18x1/2 Tr Sqd Almond

* 316021110 A B C D E F Screw,semi gim ,8-18 X 1/2 ,black

* 316089600 A B C D E F Spacer-drawer,(2)

* 5303280311 A B C D E F Screw, waf hd sdr , 10-32 x 5/16 , (2)

* 5308014215 A B C D E F Screw

* # 316001731 A B C D E F Wiring Harness,surface element

1 316011501 A B C D E F Drawer-utility

2 3131975 A B C D E F Shield-panel

4 316084405 - B C - - F Panel-drawer,white

4 316084406 A - - D E - Panel-drawer,almond

,7 3051163 A B C D E F Glide-drawer,rear

15 # 3051450 A B C D E F Element-surface, 8" , large

15A# 3051449 A B C D E F Element-surface, small

16 3013512 A - - D E - Main Top,almond

16 5303013511 - B C - - F Main Top,white

17 316066900 A B C D E F Rod-maintop support

18 08067747 A B C D E F Bracket-hinge,main top RH

18A 08067746 A B C D E F Bracket-hinge,main top LH

19 # 316048413 A B C D E F Pan-surface element,chrome ,large/8 inch,(2)

19A# 316048414 A B C D E F Pan-surface element,chrome ,small/6 inch,(2)

27 # 5303912666 A B C D E F Terminal Block Kit,surface element

28 5303017715 A B C D E F Medallion,1 1/2"dia ,black ,surface element

07/00 8

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 07/00

Publication number

FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB 5995341509

CAUTION: Use the part number on all orders, not the position number.

DOOR

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021110 A B C D E F Screw,semi gim ,8-18 X 1/2 ,black

* 316102200 A B C D E F Foil-aluminum

* 5303212762 A - - D E - Screw,8-18 X ½,almond

* 316021112 - B C - - F Screw,8-18 X ½,white

* 5303271648 A B C D E F Screw- wafer hd sq dr , 8-18AB x 1/2

* 5303280311 A B C D E F Screw, waf hd sdr , 10-32 x 5/16 , (2)

9 316066611 A B C D E F Liner-oven door

10 5303281378 A B C D E F Screw-handle mtg,wafer head ,10-24F x 3

12 5303202011 A B C D E F Seal-oven door,non self-clean

13 3202315 - B C - - F Panel-oven door,white

13 3202316 A - - D E - Panel-oven door,almond

39 316020202 - B C - - - Handle-door, white , oven

39 316020204 A ----F Handle-door,black ,oven

39 316020205 ---DE- Handle-door, almond , oven

49 3016755 A ----F EndCap,black ,(2)

49 316020101 - B C - - - End Cap-handle, white , (2)

49 316020103 ---DE- EndCap-handle, almond , (2)

07/00 10

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
